Shinwa Chemical Industries Ltd.
LC/GC Search / Application Note

Shinwa Chemical Industries
Application Search

Search result
"Ethanol" Filtered 116 Item.

Graph

GC

Samples
Ethyleneoxide , Propyleneoxide , Ethanol
Applications
Oxirane and propylene oxide in Ethanol (2)
Column
Flexol 8N8 25% Chromosorb W 60-80 (AW-DMCS)
Column Size
2.1m×3.2mm
Column temp.
50°C
Carrier gas
N2,50ml/min
Injection port temp.
200°C
Detector temp.
200°C(FID)

View detail


Graph

GC

Samples
Methanol , Ethanol , Water
Applications
Methanol and Ethanol in water
Column
PEG 1000 15% Shimalite F 20-80
Column Size
1.6m×3.2mm
Column temp.
70°C
Carrier gas
He,60ml/min
Injection port temp.
250°C
Detector temp.
230°C(TCD)

View detail


Graph

GC

Samples
Benzene , Toluene , Acetone , iso-Propanol , Ethanol , Isobutanol , Methanol
Applications
The impurity component in the carbinol
Column
Sorbitol 30% Shimalite 60-80 (NAW)
Column Size
6.1m×3.2mm
Column temp.
110°C
Carrier gas
N2,50ml/min
Injection port temp.
240°C
Detector temp.
240°C(FID)

View detail


Graph

GC

Samples
Ethanol , Isopropyl Alcohol , Methyl Ethyl Ketone
Applications
Lower alcohol in water and Ketones
Column
Sunpak-A
Column Size
2.1m×3.2mm
Column temp.
180°C
Carrier gas
N2,60ml/min
Injection port temp.
240°C
Detector temp.
240°C(FID)

View detail


Graph

GC

Samples
Mono Ethanolamine , Diethanolamine , Triethanolamine
Applications
Tri-, di-, monoethanolamine in water
Column
TENAX TA 60-80
Column Size
1.1m×3.2mm
Column temp.
160°C→270°C(10°C/min)
Carrier gas
N2,40ml/min
Injection port temp.
290°C
Detector temp.
290°C(FID)

View detail


Graph

GC

Samples
Ethanol , Acetonitrile , Isopropanol , n-Hexane
Applications
Lower alcohol in water and Hydrocarbon
Column
Thermon-1000 5% Sunpak-A
Column Size
2.1m×3.2mm
Column temp.
180°C
Carrier gas
N2,50ml/min
Injection port temp.
250°C
Detector temp.
230°C(FID)

View detail


Graph

GC

Samples
Methanol , Acetaldehyde , Ethanol , Isopropanol , n-Propanol , Ethyl Acetate , Isobutanol , n-Butanol , Isoamyl Alcohol
Applications
Lower alcohol in water
Column
Thermon-1000 5% Sunpak-A
Column Size
2.1m×3.2mm
Column temp.
180°C
Carrier gas
N2,50ml/min
Injection port temp.
240°C
Detector temp.
240°C(FID)

View detail


Graph

GC

Samples
Methanol , Acetaldehyde , Ethanol , Trimethylamine
Applications
Methanol Ethanol Acetaldehyde Trimethylamine in water
Column
Thermon-3000+KOH(5%+1%) Sunpak-A
Column Size
2.1m×3.2mm
Column temp.
120°C
Carrier gas
N2,50ml/min(headspace)
Injection port temp.
220°C
Detector temp.
220°C(FID)

View detail


Graph

GC

Samples
Formaldehyde , Methanol , Ethanol
Applications
Formalin and Ethanol (1)
Column
TSG-1 15% SHINCARBON A 60-80
Column Size
3.1m×3.2mm
Column temp.
90°C
Carrier gas
He,40ml/min
Injection port temp.
250°C
Detector temp.
230°C(TCD)

View detail


Graph

GC

Samples
Ethyleneoxide , Propyleneoxide , Ethanol
Applications
Oxirane and propylene oxide in Ethanol (1)
Column
TSG-1 15% SHINCARBON A 60-80
Column Size
3.1m×3.2mm
Column temp.
60°C
Carrier gas
N2,50ml/min
Injection port temp.
220°C
Detector temp.
220°C(FID)

View detail


Graph

GC

Samples
Formaldehyde , Methanol , Ethanol
Applications
Formalin and Ethanol (2)
Column
TSG-1 15% SHINCARBON A 60-80
Column Size
3.1m×3.2mm
Column temp.
90°C
Carrier gas
He,30ml/min
Injection port temp.
250°C
Detector temp.
230°C(TCD)

View detail


Graph

GC

Samples
Dimethyl Ether , Methanol , Isopropanol , Methyl Ethyl Ketone , Isopropyl Acetate , 2-Butanol , n-Propyl Acetate , Isobutanol , Dioxane , Methyl Cellosolve , Toluene , Ethyl Cellosolve , N,N-Dimethylformamide , Chlorobenzene , Cellosolve Acetate , Cyclohexanone , Cyclohexanol , 2-Methyl Cyclohexanone , 2-Methyl Cyclohexanol , o-Dichlorobenzene
Applications
Organic solvents (4)
Column
Ucon LB 550X 20% Chromosorb W 80-100 (AW)
Column Size
3.1m×3.2mm
Column temp.
100°C
Carrier gas
N2,50ml/min
Injection port temp.
230°C
Detector temp.
230°C(FID)

View detail


Graph

GC

Samples
Solvents
Applications
Solvents (5)
Column
ULBON HR-1
Column Size
50m×0.25mm(0.5μm)
Column temp.
60°C→120°C(2°C/min)
Carrier gas
He,0.93ml/min
Detector temp.
150°C(FID)
Injection volume
1μl

View detail


Graph

GC

Samples
Methanol , Ethyl Ether , Isopropanol , trans-1,2-Dichloroethylene , Ethyl Acetate , Chloroform , Isobutanol , Trichloroethylene , n-Butanol , 1,4-Dioxane , Toluene , Tetrachloroethylene , n-Butyl Acetate , Ethylbenzene , p-Xylene , Isoamyl Acetate , o-Xylene , n-Amyl Acetate , Cyclohexanol , Cyclohexanone , 2-Methylcyclohexanol , 2-Methylcyclohexanone , p-Dichlorobenzene , o-Dichlorobenzene , o-Cresol , m-Cresol
Applications
The work environment (2)
Column
ULBON HR-1701
Column Size
30m×0.53mm(5μm)
Column temp.
60°C→180°C(4°C/min)
Carrier gas
He,10ml/min
Detector temp.
200°C(FID)
Injection volume
1ml

View detail


Graph

GC

Samples
Methanol , Ethanol , Acetone , IPA , n-Propanol , Ethyl Acetate , MEK , Chloroform , Benzene , n-Butanol , Toluene , MIBK , Isobutyl Acetate , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cellosolve Acetate
Applications
Solvents (2)
Column
ULBON HR-1701
Column Size
25m×0.32mm(0.5μm)
Column temp.
40°C→90°C(2°C/min)
Carrier gas
He,0.83ml/min
Detector temp.
200°C(FID)
Injection volume
1μl

View detail


Graph

GC

Samples
Solvents (4)
Applications
Solvents (4)
Column
ULBON HR-1701
Column Size
50m×0.25mm(0.5μm)
Column temp.
60°C→180°C(4°C/min)
Carrier gas
He,1.4ml/min
Detector temp.
200°C(FID)
Injection volume
1μl

View detail


Graph

GC

Samples
Acetaldehyde , Ethyl Acetate , Ethanol , 1-Propanol , 3-Pentanol , 2-Methyl-1-Butanol , 3-Methyl-1-Butanol
Applications
Scotch whisky
Column
ULBON HR-20M
Column Size
50m×0.32mm(1.0μm)
Column temp.
60°C→240°C(5°C/min)
Carrier gas
He,4.0ml/min
Detector temp.
250°C(FID)
Injection volume
0.6μl

View detail


Graph

GC

Samples
n-Hexane , Ethyl Ether , Acetone , Methyl Acetate , trans-1,2-Dichloroethylene , Methanol , Isopropyl Acetate , Isopropanol , Dichloromethane , n-Propyl Acetate , cis-1,2-Dichloroethylene , Methyl Isobutyl Ketone , Chloroform , Toluene , 1,4-Dioxane , Isobutanol , Isoamyl Acetate , Ethylbenzene , p-Xylene , m-Xylene , Methyl Cellosolve , o-Xylene , Ethyl Cellosolve , Styrene , Cellosolve Acetate , N,N-Dimethylformamide , 4-Methylcyclohexanone , Butyl Cellosolve , cis-4-Methylcyclohexanol , m-Dichlorobenzene , p-Dichlorobenzene , trans-4-Methylcyclohexanol , o-Dichlorobenzene , o-Cresol , p-Cresol , m-Cresol
Applications
Solvents (6)
Column
ULBON HR-20M
Column Size
50m×0.25mm(0.5μm)
Column temp.
60°C→240°C(3°C/min)
Carrier gas
He,1.3ml/min
Detector temp.
250°C(FID)
Injection volume
1μl

View detail


Graph

GC

Samples
Methanol , Acetone , Dichloromethane , trans-1,2-Dichloroethylene , n-Hexane , Ethyl Acetate , Tetrahydrofuran , 1,1,1-Trichloroethane , Carbon Tetrachloride , Trichloroethylene , Methyl Isobutyl Ketone , Toluene , Methyl Butyl Ketone , Tetrachloroethylene , Chlorobenzene , Ethylbenzene , p-Xylene , Styrene , 1,1,2,2-Tetrachloroethane , 2-Methylcyclohexanone , 4-Methylcyclohexanone , m-Dichlorobenzene , p-Dichlorobenzene , o-Cresol , p-Cresol
Applications
The work environment (1)
Column
ULBON HR-52
Column Size
30m×0.53mm(5μm)
Column temp.
60°C→130°C(3°C/min)
Carrier gas
He,8.0ml/min
Detector temp.
150°C(FID)
Injection volume
1ml

View detail


Graph

GC

Samples
Methanol , Ethanol , Acetone , n-Propanol , n-Hexane , Ethyl Acetate , Chloroform , Benzene , MIBK , Toluene , Isobutyl Acetate , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cellosolve Acetate
Applications
Solvents (1)
Column
ULBON HR-52
Column Size
25m×0.32mm(0.5μm)
Column temp.
40°C→90°C(2°C/min)
Carrier gas
He,0.83ml/min
Detector temp.
200°C(FID)
Injection volume
1μl

View detail


Graph

GC

Samples
Methanol , Acetone , Dichloromethane , trans-1,2-Dichloroethylene , n-Hexane , Ethyl Acetate , Tetrahydrofuran , 1,1,1-Trichloroethane , Carbon Tetrachloride , Trichloroethylene , 1,4-Dioxane , Methyl Isobutyl Ketone , Toluene , Methyl n-Butyl Ketone , n-Butyl Acetate , Tetrachloroethylene , Chlorobenzene , Ethylbenzene , p-Xylene , Styrene , o-Xylene , Butyl Cellosolve , 1,1,2,2-Tetrachloroethane , 3-Methylcyclohexanol(cis, trans) , 2-Methylcyclohexanone , 4-Methylcyclohexanone , m-Dichlorobenzene , p-Dichlorobenzene , o-Dichlorobenzene , o-Cresol , p-Cresol
Applications
Solvents (3)
Column
ULBON HR-52
Column Size
50m×0.25mm(0.5μm)
Column temp.
60°C→130°C(3°C/min)
Carrier gas
He,1.2ml/min
Detector temp.
200°C(FID)
Injection volume
1μl

View detail


Graph

GC

Samples
Ethanol , Acetic Acid , Isoamyl Alcohol , 3-(Methylthio)-1-propanol
Applications
Analysis flavor components of soy sauce using NeedlEx (for organic solvent).
Column
ULBON HR-1
Column Size
0.32mmI.D. × 30m (0.26um)
Column temp.
50°C→200°C(5°C/min)
Carrier gas
He,2.4ml/min
Detector temp.
250°C(FID)
Injection volume
-

View detail


Graph

GC

Samples
Ethanol , Acetic Acid , Isoamyl Alcohol
Applications
Analysis flavor components of worcestershire sauce using NeedlEx (for organic solvent).
Column
ULBON HR-1
Column Size
0.32mmI.D. × 30m (0.26um)
Column temp.
50°C→200°C(5°C/min)
Carrier gas
He,2.4ml/min
Detector temp.
250°C(FID)
Injection volume
-

View detail


Graph

GC

Samples
Mixture of 13 organic solvents
Applications
Measurement of organic solvents using Shinwasorb -1-
Column
PEG1500 12.5% Shinwasorb-U 40/60
Column Size
2.1 m x 3.2 mm I.D. Glass
Column temp.
70℃
Carrier gas
40 mL/min N₂
Injection port temp.
200℃
Detector temp.
200℃
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Mixture of 22 organic solvents
Applications
Measurement of organic solvents using Shinwasorb -2-
Column
PEG1500 12.5% Shinwasorb-U 40/60
Column Size
2.1 m x 3.2 mm I.D. Glass
Column temp.
60~120℃ (4℃/min)
Carrier gas
40 mL/min N₂
Injection port temp.
200℃
Detector temp.
200℃
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Propyleneglycol , 1,3-propanediol
Applications
Measurement of food additives using Sunpak-A
Column
Sunpak-A 50/80
Column Size
2.1 m x 3.2 mm I.D. Glass
Column temp.
180℃
Carrier gas
50 mL/min N₂
Injection port temp.
200℃
Detector temp.
230℃
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Propyleneglycol , 1,3-propanediol
Applications
Measurement of food additives using Sunpak-A
Column
Sunpak-A 50/80
Column Size
2.1 m x 3.2 mm I.D. Glass
Column temp.
180℃
Carrier gas
50 mL/min N₂
Injection port temp.
200℃
Detector temp.
230℃
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Chloroform , Ethanol , Naphthalene , Amantadine
Applications
Measurements of amantadine hydrochloride using Shinwasorb
Column
Apiezone L+KOH 2+1% Shinwasorb-S 80/100
Column Size
2.1 m x 3.2 mm I.D. Glass
Column temp.
125℃(5 min hold)~150℃(5℃/min)~150℃ (10 min hold)
Carrier gas
50 mL/min N₂
Injection port temp.
200℃
Detector temp.
200℃
Detector
FID
Injection volume
2.0 μL

View detail


Graph

GC

Samples
Ethanol , Dl-camphor , Methyl salicylate ,
Applications
Analysis of dl-camphor using Shinwasorb
Column
PEG 20M 5% Shinwasorb-S 60/80
Column Size
3.1m×3.2mm glass
Column temp.
160°C
Carrier gas
45 mL/min N2
Injection port temp.
200°C
Detector temp.
200°C
Detector
FID
Injection volume
2.0 μL

View detail


Graph

GC

Samples
ethanol , n-ethyl caprylate , L-menthol , , ,
Applications
Analysis of polystyrene peppermint oil using Shinwasorb
Column
PEG6000 12.5% Shinwasorb-S 60/80
Column Size
2.1m×3.2mm glass
Column temp.
140°C
Carrier gas
33 mL/min N2
Injection port temp.
200°C
Detector temp.
200°C
Detector
FID
Injection volume
1.0 µL

View detail


Graph

GC

Samples
ethanol , 1-propanol , , ,
Applications
Analysis of doxycycline hydrochloride hydrate using Sunpak-A
Column
Sunpak-A 80/100
Column Size
1.6m×3.2mm glass
Column temp.
115°C
Carrier gas
30 mL/min N2
Injection port temp.
200°C
Detector temp.
200°C
Detector
FID
Injection volume
1.0 µL

View detail


Graph

GC

Samples
Deet, diethyl phthalate in ethanol
Applications
Analysis of deet (Pesticide guidelines) ~Purity test (4) Related substances~
Column
ULBON HR-20M
Column Size
0.2 mm I.D. x 25 m df = 0.1 µmm
Column temp.
170℃
Carrier gas
21 cm/sec He (Adjust so that the retention time of deet is about 10 minutes.)
Injection port temp.
230°C
Detector temp.
230°C
Detector
FID
Injection volume
2.0 μL (Split rate: 1:70)

View detail


Graph

GC

Samples
Methanol in ethanol
Applications
Analysis of etidronate disodium using Sunpak-A ~Purity test (4) Methanol~
Column
Sunpak-A 50/80
Column Size
2.1m x3.2 mm I.D. Glass
Column temp.
130℃
Carrier gas
30 mL/min N2 (Adjust so that the retention time of methanol is about 2 minutes.)
Injection port temp.
200°C
Detector temp.
200°C
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
2-propanol, ethanol in water
Applications
Analysis of sodium aurothiomalate using Sunpak-H ~Purity test (4) Ethanol~
Column
Sunpak-H 80/100
Column Size
3.1m x 3.2 mm I.D. Glass
Column temp.
145℃
Carrier gas
28 mL/min N2 (Adjust so that the retention time of 2-propanol is about 7 minutes.)
Injection port temp.
230°C
Detector temp.
230°C
Detector
FID
Injection volume
2.0 μL

View detail


Graph

GC

Samples
water, acetonitrile in methanol
Applications
Analysis of panipenem using Sunpak-A ~Water~
Column
Sunpak-A 80/100
Column Size
2.1m x 3.2 mm I.D. Glass
Column temp.
125℃
Carrier gas
29 mL/min He (Adjust so that the retention time of acetonitrile is about 8 minutes.)
Injection port temp.
200°C
Detector temp.
200°C
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Ethanol , Toluene , Chlorobenzene
Applications
Analysis of allethrin using Sunpak-H Part 1 ~Purity (4) Toluene~
Column
Sunpak-H 80/100
Column Size
1.1 m x 3.2 mm I.D. Glass
Column temp.
170℃
Carrier gas
37 mL/min N₂ (Adjust so that the retention time of toluene is about 5 minutes.)
Injection port temp.
200°C
Detector temp.
200°C
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Organic solvents
Applications
Analysis of organic solvents using Sunpak-A -1-
Column
Sunpak-A 50/80
Column Size
2.0 m x 3.0 mm I.D. Glass
Column temp.
150℃ ~ 220℃ (3 min hold) program rate 4℃/min
Carrier gas
50 mL/min N₂
Injection port temp.
250°C
Detector temp.
250°C
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Organic solvents
Applications
Analysis of organic solvents using Sunpak-A -2-
Column
Sunpak-A 50/80
Column Size
2.0 m x 3.0 mm I.D. Glass
Column temp.
150℃ ~ 220℃ (3 min hold) program rate 4℃/min
Carrier gas
50 mL/min N₂
Injection port temp.
250°C
Detector temp.
250°C
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Diethyl ether , n-Hexane , Methanol , Methyl acetate , 2-Propanol , Ethyl acetate , Tetrahydrofuran , 2-Butanol , iso-Butanol , Toluene , n-Butyl acetate , Methyl n-butyl ketone , iso-Amyl alcohol , Ethylbenzene , m-Xylene , p-Xylene , o-Xylene , Styrene monomer ,
Applications
Measurement of organic solvents using SBS-120
Column
SBS-120 12% Shincarbon-A2 80/100
Column Size
3.1 m x 3.2 mm I.D. Glass
Column temp.
90℃
Carrier gas
40 mL/min N₂
Injection port temp.
230℃
Detector temp.
230℃
Detector
FID
Injection volume
1.0 μL

View detail


Graph

GC

Samples
Ammonia and Mono, Di, Tri-Methylamine in Water ,
Applications
Ammonia and Mono, Di, Tri-Methylamine in Water
Column
Thermon-3000 + KOH 2+2% Sunpak-N 60/100 mesh
Column Size
2.1 m x 3.2 mm I.D. Glass
Column temp.
120℃
Carrier gas
50 mL/min He
Injection port temp.
250°C
Detector temp.
250°C
Detector
TCD
Injection volume
1.0 μL

View detail


Graph

LC

Samples
Clorprenaline
Applications
Clorprenaline
Column
ES-CD
Column Size
150 mm L × 6.0 mm I.D.
Mobile phase
20 mM KH2PO4(pH 4.6)/CH3CN = 94/6
Frow rate
1.2 mL/min
Column temp.
25°C

View detail


Graph

LC

Samples
Clorprenaline
Applications
Bronchodilator agent
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4(pH 5.5)/C2H5OH = 100/3
Frow rate
1.0 mL/min
Column temp.
25°C

View detail


Graph

LC

Samples
Hydroxyzine
Applications
Antianxiety agent
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4(pH 4.6)/CH3CN = 100/10
Frow rate
1.0 mL/min
Column temp.
25°C

View detail


Graph

LC

Samples
Salbutamol
Applications
Bronchodilator agent
Column
ES-PEPSIN
Column Size
150 mm L × 6.0 mm I.D.
Mobile phase
20 mM KH2PO4(pH 5.0)/C2H5OH = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
1.0 µL (0.25 mg/mL)

View detail


Graph

LC

Samples
α-Phenylethylalchol
Applications
α-Phenylethylalchol
Column
ES-PhCD
Column Size
150 mm L × 6.0 mm I.D.
Mobile phase
20 mM KH2PO4(pH 4.6)/CH3CN = 90/10
Frow rate
0.6 mL/min
Column temp.
15°C

View detail


Graph

LC

Samples
Formaldehyde , Acetaldehyde , Ethanol
Applications
Formaldehyde, Acetaldehyde, Ethanol
Column
ULTRON PS-80H
Column Size
50 mm L × 8.0 mm I.D. + 300 mm L × 8.0 mm I.D.
Mobile phase
HClO4aq.(pH 2.1)
Frow rate
1.0 mL/min
Column temp.
60°C
Pressure
2.5 MPa

View detail


Graph

LC

Samples
Ethylene glycol , Diethylene glycol , Methanol , Ethanol , Isopropyl alcohol
Applications
Alcohols
Column
ULTRON PS-80H
Column Size
300 mm L × 8.0 mm I.D.
Mobile phase
H2O
Frow rate
1.0 mL/min
Column temp.
60°C
Pressure
2.5 MPa
Injection volume
6.0 µL (10 mg/mL)

View detail


Graph

LC

Samples
Maltotriose , Maltose , Glucose , Glycerol , Ethanol
Applications
Sake
Column
ULTRON PS-80N
Column Size
300 mm L × 8.0 mm I.D.
Mobile phase
H2O
Frow rate
1.0 mL/min
Column temp.
60°C
Pressure
2.2 MPa
Injection volume
10 µL (undiluted solution)

View detail


Graph

LC

Samples
Methylephedrine hydrochloride , Noscapine , Thiamine , Dextromethorphan , Carbinoxamine maleate
Applications
The component of the cold remedy (1)
Column
STR ODS-II
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
CH3CN/H2O/H3PO4 = 510/490/1 + 0.5% Sodium dodecyl sulfate
Frow rate
1.0 mL/min
Column temp.
50°C

View detail


Graph

LC

Samples
Hypoxanthine , Inosine 5'-monophosphate , Adenosine 5'-diphosphate , Adenosine 5'-monophosphate , Inosine , Adenosine 5'-triphosphate
Applications
The freshness K value
Column
STR ODS-II
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
24 mM 2-Diethylaminoethanol + 16 mM Citric acid
Frow rate
2.0 mL/min
Column temp.
40°C

View detail


Graph

LC

Samples
Nicotinic acid , Nicotinamide , Pantothenic acid , Pyridoxine , Riboflavin phosphate , Thiamine , Caffeine , Folic acid , Biotin , Riboflavin
Applications
The water-soluble vitamin (1)
Column
STR ODS-II
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
100 mM Phosphoric acid buffer(pH 2.1) + 0.8 mM Octane sodium sulphonate/CH3CN = 9/1
Frow rate
1.0 mL/min
Column temp.
40°C

View detail


Graph

LC

Samples
Formaldehyde , Methanol , Acetone
Applications
Formaldehyde/Methanol/Acetone
Column
ULTRON PS-80H
Column Size
300 mm L × 8.0 mm I.D.
Mobile phase
HClO4 aq
Frow rate
1.0 mL/min
Column temp.
60°C
Injection volume
10 µL
Diluent
Mobile phase

View detail


Graph

LC

Samples
Acesulfame K , Saccharin , Caffeine , Sorbic Acid , Benzoic Acid , Quinine , Aspartame
Applications
Analysis of food additives
Column
ULTRON AF-HILIC-CD
Column Size
150 mm L × 3.0 mm I.D.
Mobile phase
A: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90, B: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 70/30
Frow rate
Refer to the picture
Column temp.
30°C
Injection volume
2.0 µL
Diluent
H2O /CH3CN = 50/50

View detail


Graph

LC

Samples
Carvedilol
Applications
Analyses of carvedilol in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 75/25
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Amlodipine
Applications
Analyses of amlodipine in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Atomoxetine hydrochloride
Applications
Analyses of atomoxetine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Candesartan cilexetil
Applications
Analyses of candesartan cilexetil in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4/CH3CN = 75/25
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tolterodine
Applications
Analyses of tolterodine in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Prilocaine hydrochloride
Applications
Analyses of prilocaine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Rabeprazole sodium salt
Applications
Analyses of rabeprazole sodium salt in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Ibuprofen
Applications
Analyses of ibuprofen in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Formoterol fumarate
Applications
Analyses of formoterol fumarate in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tolperisone hydrochloride
Applications
Analyses of tolperisone hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Tadalafil
Applications
Analyses of tadalafil in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Carvedilol
Applications
Analyses of carvedilol in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 75/25
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Amlodipine
Applications
Analyses of amlodipine in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Atomoxetine hydrochloride
Applications
Analyses of atomoxetine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Candesartan cilexetil
Applications
Analyses of candesartan cilexetil in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4/CH3CN = 75/25
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tolterodine
Applications
Analyses of tolterodine in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Prilocaine hydrochloride
Applications
Analyses of prilocaine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Rabeprazole sodium salt
Applications
Analyses of rabeprazole sodium salt in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Ibuprofen
Applications
Analyses of ibuprofen in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Formoterol fumarate
Applications
Analyses of formoterol fumarate in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tolperisone hydrochloride
Applications
Analyses of tolperisone hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Tadalafil
Applications
Analyses of tadalafil in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column
ES-OVM
Column Size
(1)150 mm L × 4.6 mm I.D. (2)100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate
(1)1.0 mL/min (2)0.28 mL/min
Column temp.
25°C
Injection volume
(1)2.0 µL (2)0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Lenalidomide
Applications
Analysis of Lenalidomide
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/C2H5OH = 95/5
Frow rate
0.7 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Nitrendipine
Applications
Analysis of Nitrendipine
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Sertraline hydrochloride
Applications
Analysis of Sertraline hydrochloride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tosufloxacin tosilate hydrate
Applications
Analysis of Tosufloxacin tosilate hydrate
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Nefopam hydrochloride
Applications
Analysis of Nefopam hydrochloride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Tolperisone hydrochloride
Applications
Analysis of Tolperisone hydrochloride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + 20mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Nisoldipine
Applications
Analysis of Nisoldipine
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 88/12
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Rabeprazole
Applications
Analysis of Rabeprozole
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Sertraline hydrochloride
Applications
Analysis of Sertraline hydrochloride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Rotigotine
Applications
Analysis of Rotigotine
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
1.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Cinacalcet hydrochloride
Applications
Analysis of Cinacalcet hydrochloride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 93/7
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Atorvastatin calcium
Applications
Analysis of Atorvastatine calcium
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM K2HPO4 + H3PO4 (pH 7.5)/CH3OH = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Cisapride
Applications
Analysis of Cisapride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/C2H5OH = 80/20
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Lafutidine
Applications
Analysis of Laftidine
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3OH = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
1.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Montelukast sodium
Applications
Analysis of Montelukast sodium
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3OH = 60/40
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Rebamipide
Applications
Analysis of Rebamipide
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 87/13
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
1.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Efavirentz
Applications
Analysis of Efavirentz
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Sulfinpyrazone
Applications
Analysis of sulfinpyrazone
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
10 mM CH3COONH4 (pH 6.8)/CH3CH(OH)CH3 = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Sulconazole nitrate
Applications
Analysis of Sulconazole nitrate
Column
ULTRON ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3OH = 86/14
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
3,3-Dimethyl-4-phenyl-2-azetidinone
Applications
Analysis of 3,3-Dimethyl-4-phenyl-2-azetidinone
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/C2H5OH = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Pronethalol hydrochloride
Applications
Analysis of Pronethalol hydrochloride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
water

View detail


Graph

LC

Samples
Tolterodine
Applications
Analysis of tolterodine
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tolterodine
Applications
Analysis of tolterodine
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Prilocaine hydrochloride
Applications
Analysis of prilocaine hydrochloride
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Prilocaine hydrochloride
Applications
Analysis of prilocaine hydrochloride
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Rabeprazole sodium salt
Applications
Analysis of rabeprazole sodium salt
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Ibuprofen
Applications
Analysis of ibuprofen
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Tolperisone hydrochloride
Applications
Analysis of tolperisone hydrochloride
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Tadalafil
Applications
Analysis of tadalafil
Column
ES-OVM
Column Size
150 mm L × 4.6 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
2.0 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tadalafil
Applications
Analysis of tadalafil
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate
1.0 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Carvedilol
Applications
Analysis of carvedilol
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 75/25
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Amlodipine
Applications
Analysis of amlodipine
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Atomoxetine hydrochloride
Applications
Analysis of atomoxetine hydrochloride
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Candesartan cilexetil
Applications
Analysis of candesartan cilexetil
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4/CH3CN = 75/25
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tolterodine
Applications
Analysis of tolterodine
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Prilocaine hydrochloride
Applications
Analysis of prilocaine hydrochloride
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Rabeprazole sodium salt
Applications
Analysis of rabeprazole sodium salt
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Ibuprofen
Applications
Analysis of ibuprofen
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Formoterol fumarate
Applications
Analysis of formoterol fumarate
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail


Graph

LC

Samples
Tolperisone hydrochloride
Applications
Analysis of tolperisone hydrochloride
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
ethanol

View detail


Graph

LC

Samples
Tadalafil
Applications
Analysis of tadalafil
Column
ES-OVM
Column Size
100 mm L × 3.0 mm I.D.
Mobile phase
20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate
0.28 mL/min
Column temp.
25°C
Injection volume
0.5 µL
Diluent
methanol

View detail
