Application Search

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid . Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: [ DEGS + H3PO4 ] Apprication of Lower free fatty acid
Column: DEGS+H3PO4(10%+1%) Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: Free lower fatty acids in water (2) (each 50ppm)
Column: FAL-M 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Methyl Alcohol , Ethyl Alcohol , Isopropyl Alcohol , tert-Butyl Alcohol , n-Propyl Alcohol , sec-Butyl Alcohol , Isobutyl Alcohol , n-Butyl Alcohol , Isoamyl Alcohol , n-Amyl Alcohol
Applications: Lower alcohol (2) (each 500ppm)
Column: FAL-M 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 90°C
Carrier gas: N2,40ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Acetaldehyde , Propionaldehyde , Isobutylaldehyde , n-Butylaldehyde , Isovaleraldehyde, n-Valeraldehyde
Applications: Saturated aldehyde
Column: FAL-M 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 75°C
Carrier gas: N2,40ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene Monomer , Cyclopentanol
Applications: Residual styrene monomer in the packaging material
Column: FFAP 20% Chromosorb W 80-100 AW
Column Size: 3.1m×3.2mm
Column temp.: 130°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Valeric Acid , Isocaproic Acid , Caproic Acid
Applications: Free lower fatty acids (4) (each 100ppm)
Column: FFAP+H3PO4(0.3%+0.3%) Graphitecarbon 60〜80
Column Size: 1.6m×3.2mm
Column temp.: 80°C→220°C(16°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Ethyleneoxide , Propyleneoxide , Ethanol
Applications: Oxirane and propylene oxide in Ethanol (2)
Column: Flexol 8N8 25% Chromosorb W 60-80 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 50°C
Carrier gas: N2,50ml/min
Injection port temp.: 200°C
Detector temp.: 200°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Valeric Acid , Isocaproic Acid , Caproic Acid
Applications: Free lower fatty acids in Acetone(each 200ppm)
Column: FON 20% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 170°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene Monomer , Cyclopenthanol , N,N-Dimethylformamide
Applications: Styrene monomer in the resin
Column: FON 20% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 110°C
Carrier gas: N2,50ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Formic Acid , Acetic Acid , Propionic Acid
Applications: Formic acid and propionic acid in the acetic acid
Column: FON 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: He,55ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(TCD)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: Free lower fatty acids in water (3) (each 50ppm)
Column: PEG 6000 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Valeric Acid , Isocaproic Acid , Caproic Acid , Methyl Lactate , Dimethyl Succinate
Applications: Free lower fatty acids (C2〜C6), Lactic acid methyl and Succinic acid methyl
Column: Reoplex 400 10% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 140°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Methyl Alcohol , Ethyl Alcohol , Isopropyl Alcohol , Ethyl Acetate , Methyl Ethyl Ketone , Benzene , Methyl Isobutyl Ketone , Toluene , Butyl Acetate , Cellosolve , Ethylbenzene , m-Xylene , p-Xylene , o-Xylene , Cyclohexanone
Applications: Organic solvents (2)
Column: SBS-1 10% Shimalite TPA 60-80
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,40ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: n-Hexane , Methyl Alcohol , Acetone , Isopropyl Alcohol , Ethyl Acetate , Methyl Ethyl Ketone , Benzene , Trichloroethylene , Isobutyl Alcohol , Isobutyl Acetate , Toluene , n-Butyl Acetate , Isoamyl Alcohol , Ethylbenzene , m-Xylene , o-Xylene , n-Propylbenzene , Cyclohexanone
Applications: Organic solvent in the air (ppm level)
Column: SBS-100 10% Shimalite TPA 60-80
Column Size: 3.1m×3.2mm
Column temp.: 110°C
Carrier gas: N2,30ml/min
Injection port temp.: 200°C
Detector temp.: 200°C(FID)

View detail

GC
Samples: Flon-113(1,1,2-Trichloro-1,2,2,-Trifluoroethane) , 2-Chloropropane , 1-Chloropropane
Applications: Freon113 and Chloropropane
Column: SBS-100 10% Shimalite TPA 60-80
Column Size: 3.1m×3.2mm
Column temp.: 85°C
Carrier gas: N2,60ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Acetone , Isopropyl Alcohol , n-Hexane , Ethyl Acetate , Chloroform , Carbon Tetrachloride , n-Butyl Alcohol , Methyl Isobutyl Ketone , Isobutyl Acetate , Toluene , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cyclohexanone , Butyl Cellosolve , 1,1,2,2-Tetrachloroethane , o-Dichlorobenzene
Applications: Organic solvent in work environment (2)
Column: SBS-200 20% Shimalite W 100-120 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Acetone , Isopropyl Alcohol , n-Hexane , Ethyl Acetate , Chloroform , Carbon Tetrachloride , n-Butyl Alcohol , Methyl Isobutyl Ketone , Isobutyl Acetate , Toluene , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cyclohexanone , Butyl Cellosolve , 1,1,2,2-Tetrachloroethane , o-Dichlorobenzene
Applications: Organic solvents of the atmosphere (ppm level)
Column: SBS-200 20% Shimalite W 100-120 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methane , Ethane , Ethylene , Propane , Propylene , iso-Butane , n-Butane , 1-Butylene , iso-Butylene , trans-2-Butylene , iso-Pentane , cis-2-Butylene , n-Pentane , 1,3-Butadiene
Applications: Lower Hydrocarbons C1〜C5
Column: Sebaconitrile 25% Shimalite 60-80 (NAW)
Column Size: 12m×3mm(SUS)
Column temp.: 40°C
Carrier gas: N2,40ml/min
Injection port temp.: 40°C
Detector temp.: 40°C(FID)

View detail

GC
Samples: Benzene , n-Octane , Toluene , n-Nonane , Ethylbenzene , p-Xylene , m-Xylene , o-Xylene , Isopropylbenzene , Styrene , n-Decane , p-Ethyltoluene , o-Ethyltoluene , 1,2,4-Trimethylbenzene
Applications: Styrene monomer and Lower Hydrocarbons
Column: Shinchrom F51+Bentone 34(6%+2%) Chromosorb W 80-100 (AW‐DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 80°C
Carrier gas: N2,60ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methane , Ethane , Ethylene , Propane , Propylene , iso-Butane , n-Butane , 1-Butene , iso-Butene , trans-2-Butene , cis-2-Butene , iso-Pentane , 1,3-Butadiene , n-Pentane ,
Applications: Liquefied petroleum gas (LPG)
Column: SM-6
Column Size: 6.0 m × 3.0 mm Stainless steel
Column temp.: 40°C
Carrier gas: He, 25 ml/min
Injection port temp.: 40°C
Detector temp.: 40°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Benzene , Toluene , Acetone , iso-Propanol , Ethanol , Isobutanol , Methanol
Applications: The impurity component in the carbinol
Column: Sorbitol 30% Shimalite 60-80 (NAW)
Column Size: 6.1m×3.2mm
Column temp.: 110°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methane , Ethane , Ethylene , Propane , iso-Butane , Propylene , n-Butane
Applications: Ethane and ethylene in the exhaust gas
Column: Squalane 1% Activated Alumina 60-80
Column Size: 1.1m×3.2mm
Column temp.: 40°C
Carrier gas: N2,30ml/min
Injection port temp.: 40°C
Detector temp.: 40°C(FID)

View detail

GC
Samples: Ethanol , Isopropyl Alcohol , Methyl Ethyl Ketone
Applications: Lower alcohol in water and Ketones
Column: Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 180°C
Carrier gas: N2,60ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methane , Ethane , Propane , Hydrogen Sulfide , Carbonyl Sulfide
Applications: Hydrogen sulfide and Sulfurization carbonium in Lower Hydrocarbons(C1〜C3)
Column: Sunpak-S 80-100
Column Size: 2.1m×3.2mm
Column temp.: 40°C→140°C(6°C/min)
Carrier gas: He,50ml/min
Injection port temp.: 180°C
Detector temp.: 180°C(TCD)

View detail

GC
Samples: Methane , Ethane , Hydrogen Sulfide , Cabonyl Sulfide , Propane , Isobutane , Methyl Mercaptane , n-Butane
Applications: Sulfur compounds in Lower Hydrocarbon
Column: Sunpak-S 80-100
Column Size: 2.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 180°C
Detector temp.: 180°C(FPD)

View detail

GC
Samples: Ethanol , Acetonitrile , Isopropanol , n-Hexane
Applications: Lower alcohol in water and Hydrocarbon
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 180°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Methanol , Acetaldehyde , Ethanol , Isopropanol , n-Propanol , Ethyl Acetate , Isobutanol , n-Butanol , Isoamyl Alcohol
Applications: Lower alcohol in water
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 180°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: IPA , Methyl Cellosolve , n-Butanol , 1-Methoxy-2-Propanol , Ethyl Cellosolve , Butyl Cellosolve
Applications: Lower alcohol and Cellosolves
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 170°C→220°C(6°C/min)
Carrier gas: N2,50ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Methyl Alcohol , Acetaldehyde , Ethyl Alcohol , n-Propyl Alcohol , Isobutyl Alcohol , Isoamyl Alcohol
Applications: Aldehyde in the wine and Lower alcohol
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 140°C→180°C(6°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: [ Thermon-1000+H3PO4 ] Apprication of Lower free fatty acid
Column: Thermon-1000+H3PO4(10%+1%) Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: Propyleneglycol , Ethyleneglycol , Decyl Alcohol , 1,4-Butanediol , Diethyleneglycol , Lauryl Alcohol , Myristyl Alcohol , Triethyleneglycol , Cetyl Alcohol , Stearyl Alcohol
Applications: Glycol and higher alcohol
Column: Thermon-3000 1% Shimalite TPA 60-80
Column Size: 1.1m×3.2mm
Column temp.: 90°C→180°C(5°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Isobutyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid , Lactic Acid
Applications: Free lower fatty acids in water and Lactic acid (1)
Column: Thermon-3000 3% Shimalite TPA 60-80
Column Size: 1.6m×3.2mm
Column temp.: 170°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Ethyleneoxide , Propyleneoxide , Ethanol
Applications: Oxirane and propylene oxide in Ethanol (1)
Column: TSG-1 15% SHINCARBON A 60-80
Column Size: 3.1m×3.2mm
Column temp.: 60°C
Carrier gas: N2,50ml/min
Injection port temp.: 220°C
Detector temp.: 220°C(FID)

View detail

GC
Samples: Dimethyl Ether , Methanol , Isopropanol , Methyl Ethyl Ketone , Isopropyl Acetate , 2-Butanol , n-Propyl Acetate , Isobutanol , Dioxane , Methyl Cellosolve , Toluene , Ethyl Cellosolve , N,N-Dimethylformamide , Chlorobenzene , Cellosolve Acetate , Cyclohexanone , Cyclohexanol , 2-Methyl Cyclohexanone , 2-Methyl Cyclohexanol , o-Dichlorobenzene
Applications: Organic solvents (4)
Column: Ucon LB 550X 20% Chromosorb W 80-100 (AW)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Cholesterol , Cholesterol Acetate , Cholesterol Propionate , Cholesterol Isobutyrate , Cholesterol n-Butyrate , Cholesterol n-Valerate , Cholesterol n-Caproate , Cholesterol n-Octanoate , Cholesterol n-Decanoate , Cholesterol Laurate , Cholesterol Myristate
Applications: Cholesterol ester
Column: ULBON HR-1
Column Size: 25m×0.25mm(0.15μm)
Column temp.: 250°C→330°C(5°C/min)
Carrier gas: He,1.3ml/min
Detector temp.: 340°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Solvents
Applications: Solvents (5)
Column: ULBON HR-1
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→120°C(2°C/min)
Carrier gas: He,0.93ml/min
Detector temp.: 150°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Methanol , Ethyl Ether , Isopropanol , trans-1,2-Dichloroethylene , Ethyl Acetate , Chloroform , Isobutanol , Trichloroethylene , n-Butanol , 1,4-Dioxane , Toluene , Tetrachloroethylene , n-Butyl Acetate , Ethylbenzene , p-Xylene , Isoamyl Acetate , o-Xylene , n-Amyl Acetate , Cyclohexanol , Cyclohexanone , 2-Methylcyclohexanol , 2-Methylcyclohexanone , p-Dichlorobenzene , o-Dichlorobenzene , o-Cresol , m-Cresol
Applications: The work environment (2)
Column: ULBON HR-1701
Column Size: 30m×0.53mm(5μm)
Column temp.: 60°C→180°C(4°C/min)
Carrier gas: He,10ml/min
Detector temp.: 200°C(FID)
Injection volume: 1ml

View detail

GC
Samples: Methanol , Ethanol , Acetone , IPA , n-Propanol , Ethyl Acetate , MEK , Chloroform , Benzene , n-Butanol , Toluene , MIBK , Isobutyl Acetate , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cellosolve Acetate
Applications: Solvents (2)
Column: ULBON HR-1701
Column Size: 25m×0.32mm(0.5μm)
Column temp.: 40°C→90°C(2°C/min)
Carrier gas: He,0.83ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Solvents (4)
Applications: Solvents (4)
Column: ULBON HR-1701
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→180°C(4°C/min)
Carrier gas: He,1.4ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Benzene , Acrylonitrile , Toluene , Ethylbenzene , iso-Propylbenzene , n-Propylbenzene , Styrene Monomer , N,N-Dimethylformamide
Applications: Styrene monomer (10ppm) in DMF
Column: ULBON HR-20M
Column Size: 30m×0.53mm(5.0μm/min)
Column temp.: 120°C
Carrier gas: He,10ml/min
Detector temp.: 200°C(FID)
Injection volume: 2μl

View detail

GC
Samples: Acetic Acid , Propionic Acid , iso-Butyric Acid , n-Butyric Acid , iso-Valeric Acid , iso-Caproic Acid , n-Caproic Acid , n-Heptanoic Acid
Applications: Lower fatty Acid in water
Column: ULBON HR-20M
Column Size: 30m×0.53mm(3.0μm)
Column temp.: 150°C
Carrier gas: He,10.5ml/min
Detector temp.: 280°C(FID)
Injection volume: 0.4μl

View detail

GC
Samples: Acetaldehyde , Ethyl Acetate , Ethanol , 1-Propanol , 3-Pentanol , 2-Methyl-1-Butanol , 3-Methyl-1-Butanol
Applications: Scotch whisky
Column: ULBON HR-20M
Column Size: 50m×0.32mm(1.0μm)
Column temp.: 60°C→240°C(5°C/min)
Carrier gas: He,4.0ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.6μl

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , p-Xylene , m-Xylene , iso-Propylbenzene , o-Xylene , n-Propylbenzene , p-Ethyltoluene , m-Ethyltoluene , o-Ethyltoluene , 1,2,5-Trimethylbenzene , 1,2,4-Trimethylbenzene , 1,2,3-Trimethylbenzene , Naphthalene
Applications: Aromatic hydrocarbons in Premium gasoline
Column: ULBON HR-20M
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 50°C→180°C(2°C/min)
Carrier gas: He,1.04ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.2μl

View detail

GC
Samples: n-Butyl Formate , n-Butyl Acetate , n-Butyl Propionate , n-Butyl iso-Butyrate , n-Butyl n-Butyrate , n-Butyl Crotonate , n-Butyl n-Caproate , n-Butyl Lactate , n-Butyl n-Caprate , Di-n-Butyl Oxalate , n-Butyl Benzoate , Di-n-Butyl Malonate , Di-n-Butyl Fumarate , Di-n-Butyl Succinate , Di-n-Butyl Maleate , Di-n-Butyl Adipate , Di-n-Butyl Maleate , Di-n-Butyl Phthalate , Di-n-Butyl Sebacate , Di-n-Butyl Isophthalate , Di-n-Butyl Terephthalate , Tri-n-Butyl Citrate
Applications: Organic acid butyl ester
Column: ULBON HR-20M
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 80°C→240°C(4°C/min)
Carrier gas: He,1.1ml/min
Detector temp.: 250°C(FID)
Injection volume: 1.0μm

View detail

GC
Samples: n-Hexane , Ethyl Ether , Acetone , Methyl Acetate , trans-1,2-Dichloroethylene , Methanol , Isopropyl Acetate , Isopropanol , Dichloromethane , n-Propyl Acetate , cis-1,2-Dichloroethylene , Methyl Isobutyl Ketone , Chloroform , Toluene , 1,4-Dioxane , Isobutanol , Isoamyl Acetate , Ethylbenzene , p-Xylene , m-Xylene , Methyl Cellosolve , o-Xylene , Ethyl Cellosolve , Styrene , Cellosolve Acetate , N,N-Dimethylformamide , 4-Methylcyclohexanone , Butyl Cellosolve , cis-4-Methylcyclohexanol , m-Dichlorobenzene , p-Dichlorobenzene , trans-4-Methylcyclohexanol , o-Dichlorobenzene , o-Cresol , p-Cresol , m-Cresol
Applications: Solvents (6)
Column: ULBON HR-20M
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→240°C(3°C/min)
Carrier gas: He,1.3ml/min
Detector temp.: 250°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , p-Xylene , m-Xylene , iso-Propylbenzene , o-Xylene , n-Propylbenzene , p-Ethyltoluene , m-Ethyltoluene , o-Ethyltoluene , 1,2,5-Trimethylbenzene , 1,2,4-Trimethylbenzene , 1,2,3-Trimethylbenzene , Naphthalene
Applications: Aromatic hydrocarbons in Regular gasoline
Column: ULBON HR-20M
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 50°C→180°C(2°C/min)
Carrier gas: He,1.04ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.2μl

View detail

GC
Samples: Dehydroepiandrosterone , Estrone , Cholestane , Progesterone , Estriol , Cholesterol , Lanosterol
Applications: Sterol
Column: ULBON HR-52
Column Size: 50m×0.25mm(0.25μm)
Column temp.: 250°C→320°C(4°C/min)
Carrier gas: He,0.57ml/min
Detector temp.: 330°C(FID)
Injection volume: 2μl

View detail

GC
Samples: Methanol , Ethanol , Acetone , n-Propanol , n-Hexane , Ethyl Acetate , Chloroform , Benzene , MIBK , Toluene , Isobutyl Acetate , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cellosolve Acetate
Applications: Solvents (1)
Column: ULBON HR-52
Column Size: 25m×0.32mm(0.5μm)
Column temp.: 40°C→90°C(2°C/min)
Carrier gas: He,0.83ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: n-Hexane, Benzene , n-Octane , Toluene , n-Nonane , Ethylbenzene , p-Xylene , m-Xylene , o-Xylene , Isopropylbenzene , Styrene , n-Propylbenzene , p-Ethyltoluene , m-Ethyltoluene , o-Ethyltoluene , 1,3,5-Trimethylbenzene , 1,2,4-Trimethylbenzene , 1,2,3-Trimethylbenzene , 4-n-Propyltoluene , 3-n-Propyltoluene , 2-n-Propyltoluene , 1,2,3,5-Tetramethylbenzene , 1,2,4,5-Tetramethylbenzene , 1,2,3,4-Tetramethylbenzene
Applications: Alkyl benzene isomer
Column: ULBON Xylene Master
Column Size: 50m×0.32mm
Column temp.: 70°C→120°C(2°C/min)
Carrier gas: He,1.4ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Ethanol , Acetic Acid , Isoamyl Alcohol , 3-(Methylthio)-1-propanol
Applications: Analysis flavor components of soy sauce using NeedlEx (for organic solvent).
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Carbonyl sulfide , Hydrogen sulfide , Carbon disulfide , Methyl mercaptan , Ethyl mercaptan , Dimethyl sulfide , Dimethyl disulfide
Applications: Analysis of methyl mercaptan, hydrogen sulfide, dimethyl sulfide, and dimethyl disulfide using Shinwasorb
Column: β,β’-Oxydipropionitrile 12.5% Shinwasorb-S 60/80 ST
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 70℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 180℃
Detector temp.: 180℃
Detector: FPD (S)
Injection volume: 1.0 μL

View detail

GC
Samples: Ethylene oxide , Propylene oxide
Applications: Measurement of ethylene oxide using Shinwasorb
Column: Flexol 8N8 12.5% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 150℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 150℃
Detector temp.: 150℃
Detector: FID
Injection volume: 100 μL

View detail

GC
Samples: liquefied petroleum gas (LPG)
Applications: Measurement of liquefied petroleum gas (LPG) using Shinwasorb
Column: DBM+ODPN (95:5) 35% Shinwasorb-U 60/80
Column Size: 6.0 m (3.0 m+3.0 m) x 3.0 mm I.D. stainless steel
Column temp.: 40℃
Carrier gas: 45 mL/min N₂
Injection port temp.: 50℃
Detector temp.: 50℃
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Acetic acid , Propionic acid , Isobutyric acid , Butyric acid , Isovaleric acid , Valeric acid , Isocaproic acid , Capric acid , Enanthic acid
Applications: Measurement of short-chain free fatty acids using Shinwasorb -1-
Column: Thermon-1000+H3PO4 2.5+0.25% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 150℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 250℃
Detector temp.: 240℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetic acid , Propionic acid , Isobutyric acid , Butyric acid , Isovaleric acid , Valeric acid , Isocaproic acid , Capric acid , Enanthic acid
Applications: Measurement of short-chain free fatty acids using Shinwasorb -2-
Column: FAL-M Shinwasorb-S 60/80 PA
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 150℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene monomer , Cyclopentanol , N,N-Dimethylformamide
Applications: Measurement of styrene monomer in DMF using Shinwasorb
Column: FON 10% Shinwasorb-S 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 110℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 230℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Mixture of 22 organic solvents
Applications: Measurement of organic solvents using Shinwasorb -2-
Column: PEG1500 12.5% Shinwasorb-U 40/60
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 60～120℃ (4℃/min)
Carrier gas: 40 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Propyleneglycol , 1,3-propanediol
Applications: Measurement of food additives using Sunpak-A
Column: Sunpak-A 50/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 180℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Propyleneglycol , 1,3-propanediol
Applications: Measurement of food additives using Sunpak-A
Column: Sunpak-A 50/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 180℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Methyl iodide , iso-Propyl iodide , n-Octane , o-Xylene
Applications: Analysis of hypromellose using Shinwasorb
Column: Silicone DC-200 10% Shinwasorb-S 100/120
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 90℃
Carrier gas: 38 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Carbon sulfide , Hydrogen sulfide , Carbon disulfide , Methyl mercaptan , Ethyl mercaptane , Dimethyl sulfide
Applications: Measurements of offensive odor substances using Shinwasorb -3-
Column: 1,2,3-TCEP 25% Shinwasorb-S 80/100 ST
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 70℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 180℃
Detector temp.: 180℃
Detector: FPD
Injection volume: 1.0 μL

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene monomer , Cyclopentanol , N, N-Dimethylformamide ,
Applications: Measurement of styrene monomer in DMF using Shinwasorb
Column: FFAP 10% Shinwasorb-U 60/80
Column Size: 3.1m×3.2mm glass
Column temp.: 120°C
Carrier gas: 50 mL/min N2
Injection port temp.: 240°C
Detector temp.: 240°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: n-valeric acid , valproic acid
Applications: Analysis of valproate sodium using Shinwasorb
Column: DEGA+H3PO4 2.5+0.5% Shinwasorb-S 80/100
Column Size: 2.1m×3.2mm glass
Column temp.: 145°C
Carrier gas: 35 mL/min N2
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: ethanol , 1-propanol , , ,
Applications: Analysis of doxycycline hydrochloride hydrate using Sunpak-A
Column: Sunpak-A 80/100
Column Size: 1.6m×3.2mm glass
Column temp.: 115°C
Carrier gas: 30 mL/min N2
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 µL

View detail

GC
Samples: Isopropyl iodide , Methylcyclohexane , o-xylene
Applications: Analysis of hydroxypropylcellulose (JP)
Column: ULBON HR-1
Column Size: 0.53 mm I.D. x 30 m df = 3.0 µm
Column temp.: 40℃ (3 min)～10℃/min～100℃～50℃/min～250℃ (3 min)
Carrier gas: 52 cm/sec He
Injection port temp.: 180°C
Detector temp.: 280°C
Detector: FID
Injection volume: 2.0 μL Split rate: 1:50

View detail

GC
Samples: Cyclohexane , Ethyl acetate , 2-propanol ,
Applications: Analysis of lenampicillin hydrochloride using Shinwasorb
Column: Quadrol 5% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 100℃
Carrier gas: 70 mL/min N₂ (Adjust so that the retention time of cyclohexane is about 1 minute.)
Injection port temp.: 160°C
Detector temp.: 160°C
Detector: FID
Injection volume: 4.0 μL

View detail

GC
Samples: Enflurane , 2-propanol ,
Applications: Analysis of enflurane using Shinwasorb
Column: DEGS 10% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 80℃
Carrier gas: 32 mL/min He (Adjust so that the retention time of enflurane is about 3 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 5.0 μL

View detail

GC
Samples: 2-propanol, ethanol in water
Applications: Analysis of sodium aurothiomalate using Sunpak-H ~Purity test (4) Ethanol~
Column: Sunpak-H 80/100
Column Size: 3.1m x 3.2 mm I.D. Glass
Column temp.: 145℃
Carrier gas: 28 mL/min N2 (Adjust so that the retention time of 2-propanol is about 7 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Cyclohexane , Dicyclohexyl phthalate , Etofenprox
Applications: Analysis of etofenprox using Shinwasorb
Column: Silicone OV-225 2.5% Shinwasorb-U 60/80
Column Size: 1.1m x 3.2 mm I.D. Glass
Column temp.: 240℃
Carrier gas: 37 mL/min N₂ (Adjust so that the retention time of dicyclohexyl phthalate is about 8 minutes.)
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 3.0 μL

View detail

GC
Samples: Etofenprox in Cyclohexane
Applications: Analysis of etofenprox using Shinwasorb -2- ～Purity (3) Related substances～
Column: Silicone OV-225 2.5% Shinwasorb-U 60/80
Column Size: 1.1m x 3.2 mm I.D. Glass
Column temp.: 240℃
Carrier gas: 37 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 3.0 μL

View detail

GC
Samples: Organic solvents
Applications: Analysis of organic solvents using Sunpak-A -1-
Column: Sunpak-A 50/80
Column Size: 2.0 m x 3.0 mm I.D. Glass
Column temp.: 150℃ ～ 220℃ (3 min hold) program rate 4℃/min
Carrier gas: 50 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Organic solvents
Applications: Analysis of organic solvents using Sunpak-A -2-
Column: Sunpak-A 50/80
Column Size: 2.0 m x 3.0 mm I.D. Glass
Column temp.: 150℃ ～ 220℃ (3 min hold) program rate 4℃/min
Carrier gas: 50 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetic acid , Propionic acid , iso-butyric acid , n-butyric acid , iso-valeric acid , n-valeric avid , iso-caproic acid , n-caproic acid
Applications: Lower free fatty acid in water
Column: Sunpak-H 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 175℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: liquefied petroleum gas (LPG)
Applications: Measurement of liquefied petroleum gas (LPG) using Supak-A
Column: Supak-A 50/80
Column Size: 2.1 m x 3.2 mm I.D. glass
Column temp.: 60℃～120℃ (5°C/min.)
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 0.5 mL

View detail

GC
Samples: Diethyl ether , n-Hexane , Methanol , Methyl acetate , 2-Propanol , Ethyl acetate , Tetrahydrofuran , 2-Butanol , iso-Butanol , Toluene , n-Butyl acetate , Methyl n-butyl ketone , iso-Amyl alcohol , Ethylbenzene , m-Xylene , p-Xylene , o-Xylene , Styrene monomer ,
Applications: Measurement of organic solvents using SBS-120
Column: SBS-120 12% Shincarbon-A2 80/100
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 90℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 230℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

LC
Samples: Eperisone
Applications: Muscle relaxant
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 0.6 mL/min
Column temp.: 25°C

View detail

LC
Samples: Clorprenaline
Applications: Clorprenaline
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 94/6
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alimemazine
Applications: Antihistaminic drug
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/CH3CN = 70/30
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Trimipramine
Applications: Trimipramine
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 75/25
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlorpheniramine maleate
Applications: Chlorpheniramine maleate
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 83/17
Frow rate: 1.0 mL/min
Column temp.: 15°C

View detail

LC
Samples: PTH-valine
Applications: PTH-valine
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3OH = X/Y
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Oxprenolol
Applications: Oxprenolol
Column: ULTRON ES-OVM
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/CH3CN = 100/10
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bunitrolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/C2H5OH = 100/3
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Arotinolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Pindolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)/C2H5OH = 100/30
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Propranolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.8)/CH3CN = 100/30
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Verapamil
Applications: Calcium rivalry medicine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Prenylamine
Applications: Calcium rivalry medicine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/CH3CN = 100/15
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Clorprenaline
Applications: Bronchodilator agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)/C2H5OH = 100/3
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Tolperisone
Applications: Muscle relaxant
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Trimipramine maleate
Applications: Analysis of the antidepressive drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/C2H5OH = 100/30
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Flurbiprofen
Applications: Flurbiprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ibuprofen
Applications: Ibuprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ketoprofen
Applications: Antiinflammatory agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Pranoprofen
Applications: Antiinflammatory agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/8
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Zaltoprofen
Applications: Antiinflammatory agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 87/13
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Biperiden
Applications: Antiparkinsonic agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Profenamine
Applications: Antiparkinsonic agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Trihexyphenidyl
Applications: Antiparkinsonic agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alimemazine
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlorpheniramine
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Promethazine
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Disopyramide phosphate
Applications: Disopyramide phosphate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/C2H5OH = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Proglumide
Applications: Peptic ulcer agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/C2H5OH = 100/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Thyroxine
Applications: Thyroxine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/CH3CN = 100/20
Frow rate: 1.2 mL/min
Column temp.: 15°C

View detail

LC
Samples: Benproperine
Applications: Antitussive drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlorphenesin
Applications: Muscle relaxant
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 5.5)
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Eperisone
Applications: Muscle relaxant
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 5.5)/C2H5OH = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Atenolol
Applications: Atenolol
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 + 20mM K2HPO4 (pH 6.0)/C2H5OH = 99/1
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alprenolol
Applications: β-Blocking agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.9 µL (0.6 mg/mL)

View detail

LC
Samples: Bufetolol
Applications: β-Blocking agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL (ca. 1 mg/mL)

View detail

LC
Samples: Terbutaline
Applications: Bronchodilator agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 5 µL (ca. 0.25 mg/mL)

View detail

LC
Samples: Salbutamol
Applications: Bronchodilator agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL (0.25 mg/mL)

View detail

LC
Samples: Propranolol
Applications: β-Blocking agent
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 65/35
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 20 µL

View detail

LC
Samples: Atenolol
Applications: Atenolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 90/10
Frow rate: 0.3 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alprenolol
Applications: Alprenolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Arotinolol
Applications: Arotinolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 75/25
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Eperisone
Applications: Muscle relaxant
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 70/30
Frow rate: 1.2 mL/min
Column temp.: 9°C

View detail

LC
Samples: Chlorphenesin
Applications: Muscle relaxant
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 70/30
Frow rate: 0.6 mL/min
Column temp.: 9°C

View detail

LC
Samples: Pindolol
Applications: Pindolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bunitrolol
Applications: β-Blocking agent
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 70/30
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Propranolol
Applications: Propranolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 60/40
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ethylene glycol , Diethylene glycol , Methanol , Ethanol , Isopropyl alcohol
Applications: Alcohols
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.5 MPa
Injection volume: 6.0 µL (10 mg/mL)

View detail

LC
Samples: Citric acid , Tartaric acid , Malic acid , Malonic acid , Succinic acid , Glycolic acid , Formic acid , Lactic acid , Acetic acid , Fumaric acid , Adipic acid , Pyroglutamic acid , Propionic acid , Acrylic acid , Pivalic acid , Methacrylic acid , Crotonic acid
Applications: Elution position of the aliphatic organic acid
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D. + 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)
Frow rate: 1.0 mL/min
Column temp.: 60°C

View detail

LC
Samples: Citric acid , Tartaric acid , Malic acid , Succinic acid , Lactic acid , Acetic acid , Pyroglutamic acid
Applications: Analysis of the soy sauce
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)
Frow rate: 1.0 mL/min
Column temp.: 60°C

View detail

LC
Samples: Citric acid , Tartaric acid , Malonic acid , Succinic acid , Lactic acid , Acetic acid , Gallic acid , Propionic acid , Phthalic acid , Phenoxyacetic acid , m-Hydroxybenzoic acid , p-Hydroxybenzoic acid , Vanilic acid , Caffeic acid , Benzoic acid , o-Hydroxybenzoic acid
Applications: Elution position of the aromatic organic acid
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 60°C

View detail

LC
Samples: Maltotriose , Maltose , Glucose , Glycerol , Ethanol
Applications: Sake
Column: ULTRON PS-80N
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.2 MPa
Injection volume: 10 µL (undiluted solution)

View detail

LC
Samples: Aspartic acid , Glutamic acid , Serine , Glycine , Histidine , Arginine , Threonine , Alanine , Proline , Tyrosine , Valine , Methionine , Cysteine-cysteine , Isoleucine , Leucine , Phenylalanine , Lysine
Applications: Analysis of the PTC amino acid
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: A: CH3COONa (pH 6.5)/CH3CN = 93/7, B: CH3CN/H2O = 4/1
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Iprodione, Bensulide
Applications: Iprodione, Bensulide
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 60/40
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Methylephedrine hydrochloride , Noscapine , Thiamine , Dextromethorphan , Carbinoxamine maleate
Applications: The component of the cold remedy (1)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O/H3PO4 = 510/490/1 + 0.5% Sodium dodecyl sulfate
Frow rate: 1.0 mL/min
Column temp.: 50°C

View detail

LC
Samples: Glycyrrhetic acid , Propyl paraben
Applications: Glycyrrhizin in the licorice end
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 15 times dilution Acetic acid aqueous solution/CH3CN = 3/2
Frow rate: 0.7 mL/min
Column temp.: ambient

View detail

LC
Samples: Methyl p-hydroxybenzoate , Ethyl p-hydroxybenzoate , Propyl p-hydroxybenzoate , Butyl p-hydroxybenzoate
Applications: The elution behavior of the acid sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 50/50
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Methyl salicylate , Ethyl salicylate , Propyl salicylate , Butyl salicylate
Applications: The elution behavior of the acid sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 70/30
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Salicylic acid , Diphenhydramine , Methyl salicylate , α-Camphor , Thymol
Applications: The component of the anti-inflammatory agent
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM Phosphoric acid buffer(pH 2.6) + 20 mM Heptane sodium sulphonate/CH3OH/CH3CN = 3/2/2
Frow rate: 1.0 mL/min
Column temp.: 45°C

View detail

LC
Samples: Nicotinic acid , Nicotinamide , Pantothenic acid , Pyridoxine , Riboflavin phosphate , Thiamine , Caffeine , Folic acid , Biotin , Riboflavin
Applications: The water-soluble vitamin (1)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100 mM Phosphoric acid buffer(pH 2.1) + 0.8 mM Octane sodium sulphonate/CH3CN = 9/1
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Methyl paraben , Ethyl paraben , Isopropyl paraben , Propyl paraben , Isobutyl paraben , Butyl paraben , Each 100ppm containing
Applications: Paraben (Added to commercial soy sauce)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM Phosphoric acid buffer(pH 2.6)/CH3OH = 1/1
Frow rate: 1.5 mL/min
Column temp.: 40°C

View detail

LC
Samples: Prostaglandin , 2,4,5-Trihydroxybutyrophenone , Nordihydroguaiaretic acid , Butyl hydroxy anisole , Octyl gallate , 2,6-Di-tert-butyl-4-hydroxymethylphenol , Lauryl gallate , 2,6-Di-t-butyl 4-methylphenol
Applications: The phenolic system antioxidant (Added to commercial edible oil)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: A: 10 mM Phosphoric acid buffer(pH 2.6), B: CH3CN
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Tartaric acid , Malic acid , Malonic acid , Acetic acid , Citric acid , Succinic acid , Malic acid degradate , Propionic acid
Applications: Organic acids
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 5 mM NH4H2PO4(pH 2.4)
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Procaineamide , N-Acetylprocaineamide
Applications: The elution behavior of the basic sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer(pH 7.6)/CH3OH = 6/4
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Maleic acid , Ascorbic acid , Citric acid , Fumaric acid
Applications: Organic acid and vitamin C in the juice (other the maleic acid)
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer(pH 2.4)
Frow rate: 0.8 mL/min
Column temp.: ambient

View detail

LC
Samples: 2-(4-Hydroxyphenoxy)propionic acid
Applications: 2-(4-Hydroxyphenoxy)propionic acid
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: 2-(4-Hydroxyphenoxy)propionic acid
Applications: 2-(4-Hydroxyphenoxy)propionic acid
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bicalutamide
Applications: Bicalutamide
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bicalutamide
Applications: Bicalutamide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/CH3CN = 87/13
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Omeprazole
Applications: Omeprazole
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 95/5
Frow rate: 0.9 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bupropion hydrochloride
Applications: Bupropion hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/C2H5OH = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Escitalopram oxalate
Applications: Escitalopram oxalate
Column: ULTRON ES-OVM , ULTRON ES-OVM-E
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 50 mM KH2PO4 + 0.2 N NaOH(pH 7.0)/CH3CN = 85/15
Frow rate: 0.6 mL/min
Column temp.: 30°C

View detail

LC
Samples: Ibuprofen
Applications: Ibuprofen
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Urea , Xanthine , Lactic acid , Creatinine , Uric acid
Applications: Sweat Composition
Column: ULTRON AF-HILIC-CD (PLSS)
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10 mM HCO2NH4(pH 3.0)/CH3CN = 10/90
Frow rate: 0.30 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL

View detail

LC
Samples: (CYS)2 , LYS , ARG , HIS , ASP , GLU , GLN , ASN , GLY , SER , ALA , THR , PRO , TYR , VAL , PHE , MET , TRP , LEU+ILE
Applications: Analysis of underivatized amino acids by LC/MS/MS
Column: ULTRON AF-HILIC-CD (PLSS)
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: A: 100 mM HCO2NH4(pH 3.0)/CH3CN = 10/90, B: 100 mM HCO2NH4(pH 3.0)/CH3CN = 70/30
Frow rate: 0.36 mL/min
Column temp.: 40°C
Injection volume: 1.0 µL (5.0 µg/mL)

View detail

LC
Samples: Formaldehyde , Methanol , Acetone
Applications: Formaldehyde , Methanol , Acetone
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4 aq
Frow rate: 1.0 mL/min
Column temp.: 60°C
Injection volume: 10 µL
Diluent: mobile phase

View detail

LC
Samples: L-DOPA , Dopamine , Adrenaline , Noradrenaline
Applications: Analysis of catecholamines
Column: ULTRON AF-HILIC-DA
Column Size: 100 mm L × 4.6 mm I.D.
Mobile phase: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90
Frow rate: 0.50 mL/min
Column temp.: 30°C
Injection volume: 4.0 µL
Diluent: mobile phase

View detail

LC
Samples: Maleic acid , Pyruvic acid , Ascorbic acid , Gluconic acid , Adipic acid , Fumaric acid , Tartaric acid , Malic acid , Citric acid
Applications: Analysis of organic acid
Column: ULTRON AF-HILIC-CD (PLSS)
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 25/75
Frow rate: 0.20 mL/min
Column temp.: 40°C
Injection volume: 2.0 µL
Diluent: mobile phase

View detail

LC
Samples: Acesulfame K , Saccharin , Caffeine , Sorbic acid , Benzoic acid , Quinine , Aspartame
Applications: Analysis of food additives
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 3.0 mm I.D.
Mobile phase: A: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90, B: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 70/30
Frow rate: Refer to the picture
Column temp.: 30°C
Injection volume: 2.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Analyses of Atomoxetine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analyses of Tolterodine in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analyses of Prilocaine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Analyses of Duloxetine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analyses of Rabeprazole sodium salt in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analyses of Ibuprofen in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Formoterol fumarate
Applications: Analyses of Formoterol fumarate in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analyses of Tolperisone hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Analyses of Atomoxetine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analyses of Tolterodine in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analyses of Prilocaine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Analyses of Duloxetine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analyses of Rabeprazole sodium salt in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analyses of Ibuprofen in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Formoterol fumarate
Applications: Analyses of Formoterol fumarate in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analyses of Tolperisone hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analysis of Tolperisone hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Nisoldipine
Applications: Analysis of Nisoldipine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 88/12
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Rabeprazole
Applications: Analysis of Rabeprozole
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Rotigotine
Applications: Analysis of Rotigotine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL
Diluent: methanol

View detail

LC
Samples: Cinacalcet hydrochloride
Applications: Analysis of Cinacalcet hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 93/7
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Atorvastatin calcium
Applications: Analysis of Atorvastatine calcium
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM K2HPO4 + H3PO4 (pH 7.5)/CH3OH = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Cisapride
Applications: Analysis of Cisapride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/C2H5OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Lafutidine
Applications: Analysis of Laftidine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL
Diluent: methanol

View detail

LC
Samples: Montelukast sodium
Applications: Analysis of Montelukast sodium
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3OH = 60/40
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Escitalopram oxalate
Applications: Analyses of Escitalopram oxalate in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 50 mM KH2PO4 + 0.2 N NaOH(pH 7.0)/CH3CN = 85/15
Frow rate: 0.6 mL/min
Column temp.: 30°C
Injection volume: (1)15.0 µL (2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rebamipide
Applications: Analysis of Rebamipide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 87/13
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL
Diluent: methanol

View detail

LC
Samples: Efavirentz
Applications: Analysis of Efavirentz
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Tamsulosin
Applications: Analysis of Tamsulosin
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/C2H5OH = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: 2-(4-Hydroxyphenoxy)propionic acid
Applications: Analysis of 2-(4-Hydroxyphenoxy)propionic acid
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: Pronethalol hydrochloride
Applications: Analysis of Pronethalol hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: 2-Phenoxypropionic acid
Applications: Analysis of 2-Phenoxypropionic acid
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/C2H5OH = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: Benfluorex
Applications: Analysis of Benfluorex
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 88/12
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: Ropivacaine
Applications: Analysis of Ropivacaine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 5.0 µL

View detail

LC
Samples: Methotrexate
Applications: Analysis of Methotrexate
Column: ULTRON ES-BSA-2
Column Size: 150 mm L × 4.0 mm I.D.
Mobile phase: 50mM sodium phosphate buffer (pH6.9)/1-Propanol = 92/8
Frow rate: 1.5 mL/min
Column temp.: 25°C
Injection volume: 20.0 µL
Diluent: mobile phase

View detail

LC
Samples: Sulindac
Applications: Analysis of Sulindac
Column: ULTRON ES-BSA-2
Column Size: 150 mm L × 4.0 mm I.D.
Mobile phase: 50mM sodium phosphate buffer (pH6.9)/1-Propanol = 92/8
Frow rate: 0.75 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL

View detail

LC
Samples: Ketoprofen
Applications: Analysis of Ketoprofen
Column: ULTRON ES-BSA-2
Column Size: 150 mm L × 4.0 mm I.D.
Mobile phase: 20mM sodium phosphate buffer (pH6.9)/1-Propanol/caprylic acid = 98/2/0.005
Frow rate: 0.75 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: 1-Propanol

View detail

LC
Samples: Escitalopram oxalate
Applications: Analysis of Escitalopram oxalate
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 50 mM KH2PO4 + 0.2 N NaOH(pH 7.0)/CH3CN = 85/15
Frow rate: 0.6 mL/min
Column temp.: 30°C
Injection volume: 0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Tolterodine
Applications: Analysis of Tolterodine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analysis of Tolterodine
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analysis of Prilocaine hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analysis of Prilocaine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analysis of Rabeprazole sodium salt
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analysis of Ibuprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analysis of Tolperisone hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Analysis of Atomoxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analysis of Tolterodine
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analysis of Prilocaine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Analysis of Duloxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analysis of Rabeprazole sodium salt
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analysis of Ibuprofen
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Formoterol fumarate
Applications: Analysis of Formoterol fumarate
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analysis of Tolperisone hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Acesulfame K , Saccharin , Sucralose , Advantame , Neotame , Aspartame
Applications: Analysis of artificial sweetener
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 10/90
Frow rate: 1.4 mL/min
Column temp.: 30°C
Injection volume: 4.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Dexketoprofen
Applications: Analysis of Dexketoprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM CH3CO2NH4 (pH 3.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2 µL
Diluent: 10% acetonitrile

View detail

LC/GC Search / Application Note

Shinwa Chemical Industries
Application Search

Keyword index

Search result
"PRO" Filtered 209 Item.

Shinwa Chemical Industries Application Search

Keyword index

Search result "PRO" Filtered 209 Item.

Shinwa Chemical Industries
Application Search

Search result
"PRO" Filtered 209 Item.
