Application Search

GC
Samples: Carbonyl Sulfide , Hydrogen Sulfide , Carbon Disulfide , Methyl Mercaptan , Ethyl Mercaptan , Dimethyl Sulfide , Benzene(Solvent) , Dimethyl Disulfide
Applications: Sulfur Compounds of Air Pollution
Column: 1,2,3-TCEP 25% Shimalite 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 70°C
Carrier gas: N2,50ml/min
Injection port temp.: 180°C
Detector temp.: 180°C
Detector: FPD

View detail

GC
Samples: Air , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Gas (Air, CO, CH4, CO2)
Column: Activated Charcoal 60-80
Column Size: 1.6m×3.2mm
Column temp.: 50°C
Carrier gas: He,50ml/min
Injection port temp.: 50°C
Detector temp.: 50°C(TCD)

View detail

GC
Samples: Methyl Caprate , Methyl Laurate , Methyl Myristate , Methyl Palmitate , Methyl Stearate , Methyl Oleate , Methyl Linoleate , Methyl Arachidate , Methyl Linolenate , Methyl Behenate
Applications: Standard Mixture of Fatty Acid Methyl Esters
Column: Advance-DS 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 200°C
Carrier gas: N2,40ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Erythritol , Adonitol , Xylitol , Mannitol , Sorbitol , Inositol
Applications: Alditol
Column: Advance-DS 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 225°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Caprylic Acid , Capric Acid , Lauric Acid , Myristic Acid , Palmitic Acid , Stearic Acid , Oleoic Acid
Applications: Free fatty acid in the cocoanut oil
Column: Advance-DS 5% Shinchrom A 80〜100(DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 225°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Myristic Acid , Palmitic Acid , Palmitoleic Acid , Stearic Acid , Oleoic Acid , Linoleic Acid , cis-5-Eicosenoic Acid , Erucic Acid
Applications: Free fatty acid of fish oil (salmon)
Column: Advance-DS 5% Shinchrom A 80-100 (DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 225°C
Carrier gas: N2,40ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Sorbic Acid , Dehydroacetic Acid , Benzoic Acid , trans-Stilbene(I.S.)
Applications: Antiseptics in the food
Column: Advance-DS 5% Shinchrom A 80-100 (DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 210°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: p-Chlorostyrene , m-Chlorostyrene
Applications: Chlorostyrene isomer
Column: Bentone 34+DNP(5%+5%) Shimalite 80-100 (AW)
Column Size: 3.1m×3.2mm
Column temp.: 110°C
Carrier gas: He,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(TCD)

View detail

GC
Samples: Ethylbenzene , p-Xylene , m-Xylene , o-Xylene
Applications: Xylene isomer (each 1000ppm)
Column: Bentone 34+DNP 5%+5% Shimalite 80/100 NAW
Column Size: 3.1m×3.2mm
Column temp.: 80°C
Carrier gas: N2,50ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid . Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: [ DEGS + H3PO4 ] Apprication of Lower free fatty acid
Column: DEGS+H3PO4(10%+1%) Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: Sorbic Acid , Dehydroacetic Acid , Benzoic Acid , trans-Stilbene
Applications: Antiseptics (2)
Column: DEGS+H3PO4(2%+0.5%) Chromosorb W 60-80 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 200°C
Carrier gas: N2,40ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Sorbic Acid , Dehydroacetic Acid , Benzoic Acid , trans-Stilbene(I.S.)
Applications: Antiseptics (1)
Column: DEGS+H3PO4(5%+1%) Chromosorb W 60-80 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 185°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Trimethylamine , Dimethylamine , Monomethylamine
Applications: Mono-, di-, trimethylamine
Column: Diglycerol+TEP+KOH(15%+15%+2%) Chromosorb W 80-100 (AW-DMIS)
Column Size: 3.1m×3.2mm
Column temp.: 70°C
Carrier gas: N2,60ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: Free lower fatty acids in water (2) (each 50ppm)
Column: FAL-M 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Methyl Alcohol , Ethyl Alcohol , Isopropyl Alcohol , tert-Butyl Alcohol , n-Propyl Alcohol , sec-Butyl Alcohol , Isobutyl Alcohol , n-Butyl Alcohol , Isoamyl Alcohol , n-Amyl Alcohol
Applications: Lower alcohol (2) (each 500ppm)
Column: FAL-M 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 90°C
Carrier gas: N2,40ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Acetaldehyde , Acrolein , Crotonaldehyde , Paraldehyde , Furfural , Benzaldehyde
Applications: Unsaturated aldehyde (200ppm)
Column: FAL-M 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 120°C
Carrier gas: N2,40ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: Acetaldehyde , Propionaldehyde , Isobutylaldehyde , n-Butylaldehyde , Isovaleraldehyde, n-Valeraldehyde
Applications: Saturated aldehyde
Column: FAL-M 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 75°C
Carrier gas: N2,40ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: 2,6-Xylenol , o-Cresol , Phenol , 2,4-Xylenol , p-Cresol , m-Cresol , 3,5-Xylenol , 3,4-Xylenol
Applications: Cresol isomer and Xylenol
Column: FAP-S Chromosorb W 60-80 (AW)
Column Size: 3.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,60ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene Monomer , Cyclopentanol
Applications: Residual styrene monomer in the packaging material
Column: FFAP 20% Chromosorb W 80-100 AW
Column Size: 3.1m×3.2mm
Column temp.: 130°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Valeric Acid , Isocaproic Acid , Caproic Acid
Applications: Free lower fatty acids (4) (each 100ppm)
Column: FFAP+H3PO4(0.3%+0.3%) Graphitecarbon 60〜80
Column Size: 1.6m×3.2mm
Column temp.: 80°C→220°C(16°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Ethyleneoxide , Propyleneoxide , Ethanol
Applications: Oxirane and propylene oxide in Ethanol (2)
Column: Flexol 8N8 25% Chromosorb W 60-80 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 50°C
Carrier gas: N2,50ml/min
Injection port temp.: 200°C
Detector temp.: 200°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Valeric Acid , Isocaproic Acid , Caproic Acid
Applications: Free lower fatty acids in Acetone(each 200ppm)
Column: FON 20% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 170°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene Monomer , Cyclopenthanol , N,N-Dimethylformamide
Applications: Styrene monomer in the resin
Column: FON 20% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 110°C
Carrier gas: N2,50ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Formic Acid , Acetic Acid , Propionic Acid
Applications: Formic acid and propionic acid in the acetic acid
Column: FON 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: He,55ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(TCD)

View detail

GC
Samples: Phenetole , o-Cresol , Phenol , p-Cresol , m-Cresol , 3,4-Xylenol
Applications: Cresol isomer and Phenol (each 1000ppm)
Column: Lanoline(Denatured) 10% Chromosorb W 80-100 (AW-DMCS)
Column Size: 1.6m×3.2mm
Column temp.: 180°C
Carrier gas: N2,55ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: Oxygen , Nitrogen , Methane , Carbon Monoxide
Applications: Gas (O2, N2, CH4, CO)
Column: Molecular Sieve 5A 60-80
Column Size: 1.6m×3.2mm
Column temp.: 50°C
Carrier gas: He,40ml/min
Injection port temp.: 50°C
Detector temp.: 50°C(TCD)

View detail

GC
Samples: Methanol , Ethanol , Water
Applications: Methanol and Ethanol in water
Column: PEG 1000 15% Shimalite F 20-80
Column Size: 1.6m×3.2mm
Column temp.: 70°C
Carrier gas: He,60ml/min
Injection port temp.: 250°C
Detector temp.: 230°C(TCD)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: Free lower fatty acids in water (3) (each 50ppm)
Column: PEG 6000 10% Shimalite TPA 60-80
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Hydrogen Sulfide , Sulfur Dioxide , Methyl Mercaptan , Ethyl Mercaptan , Dimethyl Sulfide , Carbon Disulfide , Benzene , Dimethyl Disulfide
Applications: Air pollution sulfur compound (1)
Column: PPE-5rings 10% Shimalite TPA 60-80
Column Size: 3.1m×3.2mm
Column temp.: 70°C
Carrier gas: N2,50ml/min
Injection port temp.: 180°C
Detector temp.: 180°C(FPD)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Valeric Acid , Isocaproic Acid , Caproic Acid , Methyl Lactate , Dimethyl Succinate
Applications: Free lower fatty acids (C2〜C6), Lactic acid methyl and Succinic acid methyl
Column: Reoplex 400 10% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 140°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Methyl Alcohol , Ethyl Alcohol , Isopropyl Alcohol , Ethyl Acetate , Methyl Ethyl Ketone , Benzene , Methyl Isobutyl Ketone , Toluene , Butyl Acetate , Cellosolve , Ethylbenzene , m-Xylene , p-Xylene , o-Xylene , Cyclohexanone
Applications: Organic solvents (2)
Column: SBS-1 10% Shimalite TPA 60-80
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,40ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: n-Hexane , Methyl Alcohol , Acetone , Isopropyl Alcohol , Ethyl Acetate , Methyl Ethyl Ketone , Benzene , Trichloroethylene , Isobutyl Alcohol , Isobutyl Acetate , Toluene , n-Butyl Acetate , Isoamyl Alcohol , Ethylbenzene , m-Xylene , o-Xylene , n-Propylbenzene , Cyclohexanone
Applications: Organic solvent in the air (ppm level)
Column: SBS-100 10% Shimalite TPA 60-80
Column Size: 3.1m×3.2mm
Column temp.: 110°C
Carrier gas: N2,30ml/min
Injection port temp.: 200°C
Detector temp.: 200°C(FID)

View detail

GC
Samples: Flon-113(1,1,2-Trichloro-1,2,2,-Trifluoroethane) , 2-Chloropropane , 1-Chloropropane
Applications: Freon113 and Chloropropane
Column: SBS-100 10% Shimalite TPA 60-80
Column Size: 3.1m×3.2mm
Column temp.: 85°C
Carrier gas: N2,60ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Acetone , Isopropyl Alcohol , n-Hexane , Ethyl Acetate , Chloroform , Carbon Tetrachloride , n-Butyl Alcohol , Methyl Isobutyl Ketone , Isobutyl Acetate , Toluene , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cyclohexanone , Butyl Cellosolve , 1,1,2,2-Tetrachloroethane , o-Dichlorobenzene
Applications: Organic solvent in work environment (2)
Column: SBS-200 20% Shimalite W 100-120 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Acetone , Isopropyl Alcohol , n-Hexane , Ethyl Acetate , Chloroform , Carbon Tetrachloride , n-Butyl Alcohol , Methyl Isobutyl Ketone , Isobutyl Acetate , Toluene , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cyclohexanone , Butyl Cellosolve , 1,1,2,2-Tetrachloroethane , o-Dichlorobenzene
Applications: Organic solvents of the atmosphere (ppm level)
Column: SBS-200 20% Shimalite W 100-120 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Dichloromethane , trans-1,2-Dichloroethylene , Chloroform , 1,2-Dichloroethane , 1,1,1-Trichloroethane , Carbon Tetrachloride , Trichloroethylene , Toluene , Tetrachloroethylene , Chlorobenzene , 1,1,2,2-Tetrachloroethane , o-Dichlorobenzene
Applications: Organic solvents in work environment (3)
Column: SBS-300 20% Shimalite W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,30ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Dichloromethane , trans-1,2-Dichloroethylene , Chloroform , 1,2-Dichloroethane , 1,1,1-Trichloroethane , Carbon Tetrachloride , Trichloroethylene , Toluene , Tetrachloroethylene , Chlorobenzene , 1,1,2,2-Tetrachloroethane , o-Dichlorobenzene
Applications: Chlorinated solvents of the atmosphere (ppm level)
Column: SBS-300 20% Shimalite W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,30ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methane , Ethane , Ethylene , Propane , Propylene , iso-Butane , n-Butane , 1-Butylene , iso-Butylene , trans-2-Butylene , iso-Pentane , cis-2-Butylene , n-Pentane , 1,3-Butadiene
Applications: Lower Hydrocarbons C1〜C5
Column: Sebaconitrile 25% Shimalite 60-80 (NAW)
Column Size: 12m×3mm(SUS)
Column temp.: 40°C
Carrier gas: N2,40ml/min
Injection port temp.: 40°C
Detector temp.: 40°C(FID)

View detail

GC
Samples: Palmitic Acid Methyl Ester , Palmitoleic Acid Methyl Ester , Stearic Acid Methyl Ester , Oleoic Acid Methyl Ester , Linoleic Acid Methyl Ester , Linolenic Acid Methyl Ester , gamma-linolenic Acid Methyl Ester , Arachidonic Acid Methyl Ester , 11,14,17-Eicosadienoic Acid Methyl Ester , 7,10,13,16-Docatetranoic Acid Methyl Ester , Docosapentanoic Acid Methyl Ester
Applications: Fatty acid methyl ester in the serum
Column: Shinchrom E71 5% Shimalite 80-100 (AW)
Column Size: 3.1m×3.2mm
Column temp.: 230°C
Carrier gas: N2,40ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Myristic Acid Methyl Ester , Palmitic Acid Methyl Ester , Palmitoleic Acid Methyl Ester , Stearic Acid Methyl Ester , Oleoic Acid Methyl Ester , Linoleic Acid Methyl Ester , 5,8,11,14,17-Eicosapentaenoic Acid Methyl Ester , Docosapentanoic Acid Methyl Ester , 4,7,10,13,16,19-Docosahexaenoic Acid Methyl Ester
Applications: Fatty acid methyl ester of fish oil (yellow-tail)
Column: Shinchrom E71 5% Shimalite 80-100 (AW)
Column Size: 3.1m×3.2mm
Column temp.: 230°C
Carrier gas: N2,40ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Benzene , n-Octane , Toluene , n-Nonane , Ethylbenzene , p-Xylene , m-Xylene , o-Xylene , Isopropylbenzene , Styrene , n-Decane , p-Ethyltoluene , o-Ethyltoluene , 1,2,4-Trimethylbenzene
Applications: Styrene monomer and Lower Hydrocarbons
Column: Shinchrom F51+Bentone 34(6%+2%) Chromosorb W 80-100 (AW‐DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 80°C
Carrier gas: N2,60ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Ethylbenzene , p-Xylene , m-Xylene , o-Xylene
Applications: Xylenol isomer
Column: Shinchrom F51+Bentone 34(6%+4%) Chromosorb W 80-100 (AW‐DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 80°C
Carrier gas: N2,60ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Air , Carbon Monoxide , Methane , Ethane , Carbon Dioxide , Ethylene
Applications: Gas (O2, N2, CO, Methan, Ethan, CO2, Ethylene)
Column: Silica Gel 60-80
Column Size: 1.6m×3.2mm
Column temp.: 50°C
Carrier gas: He,60ml/min
Injection port temp.: 50°C
Detector temp.: 50°C(TCD)

View detail

GC
Samples: Chloroform , 1,1,1-Trichloroethane , Trichloroethylene , Bromodichloromethane , Chlorodibromomethane , Tetrachloroethylene , Bromoform
Applications: Trihalomethane standard mixed sample (2)
Column: Silicone DC 200 20% Chromosorb W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 80°C
Carrier gas: N2,60ml/min
Injection port temp.: 220°C
Detector temp.: 220°C(ECD)

View detail

GC
Samples: 1,1,1-Trichloroethane , Carbon Tetrachloride , Trichloroethylene , Tetrachloroethylene
Applications: Trihalomethane under drainage
Column: Silicone DC 200 20% Chromosorb W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 85°C
Carrier gas: N2,60ml/min
Injection port temp.: 220°C
Detector temp.: 220°C(ECD)

View detail

GC
Samples: DDVP , Methyldimethone , Methylparathion , Ethylparathion , EPN
Applications: Organic phosphorus system pesticides (3)
Column: Silicone DC 200 5% Chromosorb HP 80-100
Column Size: 2.1m×3.2mm
Column temp.: 200°C→230°C(4°C/min)
Carrier gas: N2,50ml/min
Injection port temp.: 270°C
Detector temp.: 270°C(FPD)

View detail

GC
Samples: Chloroform , 1,1,1-Trichloroethane , Trichloroethylene , Bromodichloromethane , Tetrachloroethylene , Chlorodibromomethane , Bromoform
Applications: Trihalomethane standard mixed sample (1)
Column: Silicone DC 550 20% Chromosorb W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 90°C
Carrier gas: N2,60ml/min
Injection port temp.: 220°C
Detector temp.: 220°C(ECD)

View detail

GC
Samples: KC-500
Applications: KC-500 Standard samples
Column: Silicone OV-1 2% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 210°C
Carrier gas: N2,60ml/min
Injection port temp.: 280°C
Detector temp.: 280°C(ECD)

View detail

GC
Samples: Ethyl Acetate , Acetaldehyde-2,4-Dinitrophenylhydrazone
Applications: Acetaldehyde -2,4- dinitrophenylhydrazone
Column: Silicone OV-17 1% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 220°C
Carrier gas: N2,60ml/min
Injection port temp.: 270°C
Detector temp.: 270°C(FID)

View detail

GC
Samples: Estrone , Estriol
Applications: Estrone and Estriol
Column: Silicone OV-17 1.5% Shimalite W 80-100 (AW-DMCS)
Column Size: 1.6m×3.2mm
Column temp.: 260°C
Carrier gas: N2,50ml/min
Injection port temp.: 290°C
Detector temp.: 290°C(FID)

View detail

GC
Samples: α-BHC , γ-BHC , β-BHC , δ-BHC , Parathion , PP´-DDE , Endrin , PP´-DDD , PP´-DDT , EPN
Applications: Chlorinated pesticide in green tea
Column: Silicone OV-17 2% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 200°C
Carrier gas: N2,60ml/min
Injection port temp.: 270°C
Detector temp.: 270°C(ECD)

View detail

GC
Samples: BHT , BHA , Fluorene(I.S.)
Applications: BHT and BHA in the margarine
Column: Silicone OV-25 3% Shimalite W 80-100 (AW-DMCS)
Column Size: 2.6m×3.2mm
Column temp.: 165°C
Carrier gas: N2,50ml/min
Injection port temp.: 260°C
Detector temp.: 260°C
Detector: FID

View detail

GC
Samples: Sodium Cyclamate Nitrite , n-Nonane
Applications: Sodium Cyclamate Nitrite
Column: Silicone SE-30 5% Chromosorb W 60-80 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 190°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: n-Nonane , n-Hedecane , n-Tridecane , n-Pentadecane , n-Heptadecane , n-Nonadecane , n-Heneicosane , Pyrene(I.S.)
Applications: The mixed sample of kerosene and light oil
Column: Silicone SE-52 5% Shimalite W 60-80 (AW)
Column Size: 2.5m×3mm(SUS)
Column temp.: 80°C→250°C(6°C/min)
Carrier gas: N2,50ml/min
Injection port temp.: 270°C
Detector temp.: 270°C(FID)

View detail

GC
Samples: Methane , Ethane , Ethylene , Propane , Propylene , iso-Butane , n-Butane , 1-Butene , iso-Butene , trans-2-Butene , cis-2-Butene , iso-Pentane , 1,3-Butadiene , n-Pentane ,
Applications: Liquefied petroleum gas (LPG)
Column: SM-6
Column Size: 6.0 m × 3.0 mm Stainless steel
Column temp.: 40°C
Carrier gas: He, 25 ml/min
Injection port temp.: 40°C
Detector temp.: 40°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Benzene , Toluene , Acetone , iso-Propanol , Ethanol , Isobutanol , Methanol
Applications: The impurity component in the carbinol
Column: Sorbitol 30% Shimalite 60-80 (NAW)
Column Size: 6.1m×3.2mm
Column temp.: 110°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methane , Ethane , Ethylene , Propane , iso-Butane , Propylene , n-Butane
Applications: Ethane and ethylene in the exhaust gas
Column: Squalane 1% Activated Alumina 60-80
Column Size: 1.1m×3.2mm
Column temp.: 40°C
Carrier gas: N2,30ml/min
Injection port temp.: 40°C
Detector temp.: 40°C(FID)

View detail

GC
Samples: Ethanol , Isopropyl Alcohol , Methyl Ethyl Ketone
Applications: Lower alcohol in water and Ketones
Column: Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 180°C
Carrier gas: N2,60ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methane , Carbon Dioxide , Ethylene , Ethane , Water
Applications: Methane CO2 Ethylene Ethane
Column: Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 50°C
Carrier gas: He,50ml/min
Injection port temp.: 150°C
Detector temp.: 150°C(TCD)

View detail

GC
Samples: Methane , Ethane , Propane , Hydrogen Sulfide , Carbonyl Sulfide
Applications: Hydrogen sulfide and Sulfurization carbonium in Lower Hydrocarbons(C1〜C3)
Column: Sunpak-S 80-100
Column Size: 2.1m×3.2mm
Column temp.: 40°C→140°C(6°C/min)
Carrier gas: He,50ml/min
Injection port temp.: 180°C
Detector temp.: 180°C(TCD)

View detail

GC
Samples: Methane , Ethane , Hydrogen Sulfide , Cabonyl Sulfide , Propane , Isobutane , Methyl Mercaptane , n-Butane
Applications: Sulfur compounds in Lower Hydrocarbon
Column: Sunpak-S 80-100
Column Size: 2.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 180°C
Detector temp.: 180°C(FPD)

View detail

GC
Samples: Ethyleneglycol , Diethyleneglycol , Triethyleneglycol
Applications: Glycols (1)
Column: TENAX TA 60-80
Column Size: 1.1m×3.2mm
Column temp.: 180°C→210°C(3°C/min)
Carrier gas: N2,50ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Mono Ethanolamine , Diethanolamine , Triethanolamine
Applications: Tri-, di-, monoethanolamine in water
Column: TENAX TA 60-80
Column Size: 1.1m×3.2mm
Column temp.: 160°C→270°C(10°C/min)
Carrier gas: N2,40ml/min
Injection port temp.: 290°C
Detector temp.: 290°C(FID)

View detail

GC
Samples: n-Pentane , n-Hexane , n-Heptane , n-Octane , Acrolein , Carbon Tetrachloride , Benzene , Acrylonitrile , Acetonitrile , Perchloroethylene , Toluene , Ethylbenzene , m-Xylene , o-Xylene , n-Dodecane , Styrene monomer , n-Tridecane , p-Xylene
Applications: Organic solvent in work environment (1)
Column: Thermon-1000 25% Shimalite 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 130°C
Carrier gas: N2,40ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: 1-Octanol , 1-Decanol , 1-Tetradecanol , 1-Hexadecanol , 1-Octadecanol
Applications: Higher Alcohol (1000ppm)
Column: Thermon-1000 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 65°C→235°C(10°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 280°C
Detector temp.: 280°C(FID)

View detail

GC
Samples: n-Docosane , n-Tricosane , n-Tetracosane , n-Hexacosane , n-Heptacosane , n-Octacosane , n-Nonacosane , n-Triacontane , n-Dotriacontane , n-Tritriacontane
Applications: Paraffin wax (3) (m.p.48〜50°C,1000ppm)
Column: Thermon-1000 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 250°C
Carrier gas: N2,80ml/min
Injection port temp.: 290°C
Detector temp.: 280°C(FID)

View detail

GC
Samples: Ethanol , Acetonitrile , Isopropanol , n-Hexane
Applications: Lower alcohol in water and Hydrocarbon
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 180°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Methanol , Acetaldehyde , Ethanol , Isopropanol , n-Propanol , Ethyl Acetate , Isobutanol , n-Butanol , Isoamyl Alcohol
Applications: Lower alcohol in water
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 180°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: IPA , Methyl Cellosolve , n-Butanol , 1-Methoxy-2-Propanol , Ethyl Cellosolve , Butyl Cellosolve
Applications: Lower alcohol and Cellosolves
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 170°C→220°C(6°C/min)
Carrier gas: N2,50ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Acrylonitrile , Methyl Methacrylate Monomer , DMF , Chlorobenzene , Styrene Monomer , α-Methylstyrene Monomer , N,N-Dimetylformamide
Applications: Residual solvent in the packaging material
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 220°C
Carrier gas: N2,50ml/min
Injection port temp.: 260°C
Detector temp.: 260°C
Detector: FID
Injection volume: 1 μL

View detail

GC
Samples: Methyl Alcohol , Acetaldehyde , Ethyl Alcohol , n-Propyl Alcohol , Isobutyl Alcohol , Isoamyl Alcohol
Applications: Aldehyde in the wine and Lower alcohol
Column: Thermon-1000 5% Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 140°C→180°C(6°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Acetic Acid , Propionic Acid , Isobutyric Acid , Butyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid
Applications: [ Thermon-1000+H3PO4 ] Apprication of Lower free fatty acid
Column: Thermon-1000+H3PO4(10%+1%) Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 160°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: TETA(Triethylene Tetramine) , TEPA(Tetraethylene Pentamine)
Applications: TETA and TEPA
Column: Thermon-1000+KOH(10%+3%) Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 250°C
Carrier gas: N2,55ml/min
Injection port temp.: 280°C
Detector temp.: 280°C(FID)

View detail

GC
Samples: o-Phenylenediamine , p-Phenylenediamine , m-Phenylenediamine
Applications: Phenylenediamine
Column: Thermon-1000+KOH(10%+3%) Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 250°C
Carrier gas: N2,60ml/min
Injection port temp.: 280°C
Detector temp.: 280°C(FID)

View detail

GC
Samples: Propyleneglycol , Ethyleneglycol , Decyl Alcohol , 1,4-Butanediol , Diethyleneglycol , Lauryl Alcohol , Myristyl Alcohol , Triethyleneglycol , Cetyl Alcohol , Stearyl Alcohol
Applications: Glycol and higher alcohol
Column: Thermon-3000 1% Shimalite TPA 60-80
Column Size: 1.1m×3.2mm
Column temp.: 90°C→180°C(5°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Catechol , Hydroquinone , Resorcinol
Applications: Dihydric phenol in water
Column: Thermon-3000 1% Shimalite TPA 60-80
Column Size: 0.5m×3.2mm
Column temp.: 160°C
Carrier gas: N2,60ml/min
Detector temp.: 260°C(FID)

View detail

GC
Samples: Pynacol , Butanediol(1,4) , Pentanediol(1,5) , Hexanediol(1,6) , Heptanediol(1,7) , Octanediol(1,8) , Nonanediol(1,9) , Decanediol(1,10)
Applications: Diols (standard mixed sample)
Column: Thermon-3000 10% Chromosorb W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 228°C
Carrier gas: N2,60ml/min
Injection port temp.: 270°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: dl-Camphor , l-Menthol , Methyl Salicylate , Thymol
Applications: The component of the liniment
Column: Thermon-3000 10% Chromosorb W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 175°C
Carrier gas: N2,60ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(FID)

View detail

GC
Samples: Capsaicine
Applications: Capsaicine (Free)
Column: Thermon-3000 2% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 260°C
Carrier gas: N2,40ml/min
Injection port temp.: 290°C
Detector temp.: 280°C(FID)

View detail

GC
Samples: TBZ(Thiabendazole)
Applications: Thiabendazole (TBZ,200ppm)
Column: Thermon-3000 2% Chromosorb W 80-100 (AW-DMCS)
Column Size: 1.1m×3.2mm
Column temp.: 220°C
Carrier gas: N2,60ml/min
Injection port temp.: 270°C
Detector temp.: 270°C(FID)

View detail

GC
Samples: Diethyl Phthalate , Di-iso-Butyl Phthalate , Di-n-Butyl Phthalate , Di-n-Amyl Phthalate , Diheptyl Phthalate , Dioctyl Phthalate
Applications: Phthalic acid ester (2) (200ppm)
Column: Thermon-3000 2% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 215°C
Carrier gas: N2,65ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Isobutyric Acid , Isovaleric Acid , Isocaproic Acid , Caproic Acid , Enanthic Acid , Lactic Acid
Applications: Free lower fatty acids in water and Lactic acid (1)
Column: Thermon-3000 3% Shimalite TPA 60-80
Column Size: 1.6m×3.2mm
Column temp.: 170°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: β-Phenylethyl Acetamide , Lauryl Acetamide
Applications: Acetamide
Column: Thermon-3000 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 200°C
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: α-Pinene , β-Pinene , Limonene , Octyl Aldehyde , Nonyl Aldehyde , Citronellal , Decyl Aldehyde , Linalool , Linalyl Acetate , Isobornyl Acetate(Citronellol) , Menthol , Benzyl Acetate , Perillaldehyde , Geraniol , α-Ionone , Rose-P , C12-Alcohol , Anisaldehyde , Methyl Cinnamate , Ethyl Cinnamate , Eugenol , Heliotropin , DEP , Vanillin , Benzyl Benzoate , Benzyl Salicylate
Applications: The mixed sample of perfume component
Column: Thermon-3000 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 80°C→250°C(6°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 290°C
Detector temp.: 280°C(FID)

View detail

GC
Samples: Diphenhydramine
Applications: Diphenhydramine
Column: Thermon-3000 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 1.1m×3.2mm
Column temp.: 200°C
Carrier gas: N2,80ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Nicotine
Applications: Nicotine extracted from the tobacco
Column: Thermon-3000 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 3.1m×3.2mm
Column temp.: 115°C→205°C(8°C/min)
Carrier gas: N2,60ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Pyruvic Acid
Applications: Pyruvic Acid (Free)
Column: Thermon-3000 5% Chromosorb W 80-100 (AW-DMCS)
Column Size: 2.1m×3.2mm
Column temp.: 105°C
Carrier gas: N2,30ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Monomethylamine , Dimethylamine , Trimethylamine
Applications: Tri-, di-, monomethylamine in Nitrogen
Column: Thermon-3000+KOH(5%+1%) Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 150°C
Carrier gas: N2,50ml/min
Injection port temp.: 240°C
Detector temp.: 240°C(FID)

View detail

GC
Samples: Methylamine , Dimethylamine , Trimethylamine
Applications: Tri-, di-, monomethylamine in water
Column: Thermon-3000+KOH(5%+1%) Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 140°C
Carrier gas: N2,50ml/min
Injection port temp.: 250°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: Methanol , Acetaldehyde , Ethanol , Trimethylamine
Applications: Methanol Ethanol Acetaldehyde Trimethylamine in water
Column: Thermon-3000+KOH(5%+1%) Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 120°C
Carrier gas: N2,50ml/min(headspace)
Injection port temp.: 220°C
Detector temp.: 220°C(FID)

View detail

GC
Samples: Monomethylamine , Dimethylamine , Trimethylamine
Applications: Tri-, di-, monomethylamine in water
Column: Thermon-3000+KOH(5%+1%) Sunpak-A
Column Size: 2.1m×3.2mm
Column temp.: 140°C
Carrier gas: N2,50ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(FID)

View detail

GC
Samples: Ethylmercury Chloride , Methylmercury Chloride
Applications: Methyl Mercury and Ethylmercury
Column: Thermon-HG 10% Chromosorb W 80-100 (AW-DMCS)
Column Size: 0.5m×3.2mm
Column temp.: 160°C
Carrier gas: N2,55ml/min
Injection port temp.: 250°C
Detector temp.: 250°C(ECD)

View detail

GC
Samples: Methylmercury Chloride , Ethylmercury Chloride
Applications: Organic mercury (1)
Column: Thermon-HG 10% Chromosorb W 80-100 (AW-DMCS)
Column Size: 0.5m×3.2mm
Column temp.: 160°C
Carrier gas: N2,55ml/min
Injection port temp.: 260°C
Detector temp.: 260°C(ECD)

View detail

GC
Samples: Formaldehyde , Methanol , Ethanol
Applications: Formalin and Ethanol (1)
Column: TSG-1 15% SHINCARBON A 60-80
Column Size: 3.1m×3.2mm
Column temp.: 90°C
Carrier gas: He,40ml/min
Injection port temp.: 250°C
Detector temp.: 230°C(TCD)

View detail

GC
Samples: Ethyleneoxide , Propyleneoxide , Ethanol
Applications: Oxirane and propylene oxide in Ethanol (1)
Column: TSG-1 15% SHINCARBON A 60-80
Column Size: 3.1m×3.2mm
Column temp.: 60°C
Carrier gas: N2,50ml/min
Injection port temp.: 220°C
Detector temp.: 220°C(FID)

View detail

GC
Samples: Formaldehyde , Methanol , Ethanol
Applications: Formalin and Ethanol (2)
Column: TSG-1 15% SHINCARBON A 60-80
Column Size: 3.1m×3.2mm
Column temp.: 90°C
Carrier gas: He,30ml/min
Injection port temp.: 250°C
Detector temp.: 230°C(TCD)

View detail

GC
Samples: Dimethyl Ether , Methanol , Isopropanol , Methyl Ethyl Ketone , Isopropyl Acetate , 2-Butanol , n-Propyl Acetate , Isobutanol , Dioxane , Methyl Cellosolve , Toluene , Ethyl Cellosolve , N,N-Dimethylformamide , Chlorobenzene , Cellosolve Acetate , Cyclohexanone , Cyclohexanol , 2-Methyl Cyclohexanone , 2-Methyl Cyclohexanol , o-Dichlorobenzene
Applications: Organic solvents (4)
Column: Ucon LB 550X 20% Chromosorb W 80-100 (AW)
Column Size: 3.1m×3.2mm
Column temp.: 100°C
Carrier gas: N2,50ml/min
Injection port temp.: 230°C
Detector temp.: 230°C(FID)

View detail

GC
Samples: 2,6-Xylenol , p-Cresol , m-Cresol , 2,4,6-Trimethylphenol , 2,4-Xylenol , 2,5-Xylenol , 2,3,6-Trimethylphenol , 2,3-Xylenol , p-Ethylphenol , m-Ethylphenol , 3,5-Xylenol , 3,4-Xylenol
Applications: Analysis of the impurity in the 3,5- xylenol ( 10% benzene solution )
Column: ULBON ALPhen
Column Size: 50m×0.20mm
Column temp.: 130°C
Carrier gas: N2,0.39ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.5μm

View detail

GC
Samples: Phenol , o-Cresol , p-Cresol , m-Cresol
Applications: Analysis of m-cresol in the p-cresol ( 10% benzene solution )
Column: ULBON ALPhen
Column Size: 50m×0.20mm
Column temp.: 130°C
Carrier gas: N2,0.39ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.5μm

View detail

GC
Samples: Phenol , 2,6-Xylenol , o-Cresol , p-Cresol , m-Cresol , o-Ethylphenol , 2,4,6-Trimethylphenol , 2,4-Xylenol , 2,5-Xylenol , 2,3,6-Trimethylphenol , 2,3-Xylenol , p-Ethylphenol , m-Ethylphenol , 3,5-Xylenol , 3,4-Xylenol , 2,3,5-Trimethylphenol
Applications: Alkylphenol isomer
Column: ULBON ALPhen (WCOT)
Column Size: 50m×0.20mm
Column temp.: 130°C
Carrier gas: N2,0.39ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: o-Ethoxybenzamide , Phenacetin , Caffeine , Aminopyrine , Chlorpheniramine Maleate
Applications: Medicine
Column: ULBON HR-1
Column Size: 15m×0.53mm(1.0μm)
Column temp.: 180°C
Carrier gas: He,7.2ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Cholesterol , Cholestanol
Applications: Cholestanols, Cholesterol
Column: ULBON HR-1
Column Size: 50m×0.25mm(0.25μm)
Column temp.: 300°C
Carrier gas: He,0.65ml/min
Detector temp.: 330°C(FID)
Injection volume: 0.8μl

View detail

GC
Samples: Cholesterol , Cholesterol Acetate , Cholesterol Propionate , Cholesterol Isobutyrate , Cholesterol n-Butyrate , Cholesterol n-Valerate , Cholesterol n-Caproate , Cholesterol n-Octanoate , Cholesterol n-Decanoate , Cholesterol Laurate , Cholesterol Myristate
Applications: Cholesterol ester
Column: ULBON HR-1
Column Size: 25m×0.25mm(0.15μm)
Column temp.: 250°C→330°C(5°C/min)
Carrier gas: He,1.3ml/min
Detector temp.: 340°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Brassicasterol , Campesterol , Stigmasterol , β-Sitosterol
Applications: Plant sterols
Column: ULBON HR-1
Column Size: 30m×0.53mm(1.0μm)
Column temp.: 290°C
Carrier gas: He,7.1ml/min
Detector temp.: 320°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Naphthalene , Biphenyl , Fluorene , Phenanthrene , Anthracene , o-Terphenyl , Fluoranthene , Pyrene , m-Terphenyl , p-Terphenyl , Chrysene , 4,5-Benzpyrene , 1,2-Benzpyrene , Perylene
Applications: Polycyclic aromatic hydrocarbon
Column: ULBON HR-1
Column Size: 50m×0.25mm(0.25μm)
Column temp.: 200°C→320°C(4°C/min)
Carrier gas: He,068ml/min
Detector temp.: 330°C(FID)
Injection volume: 1μl

View detail

GC
Samples: n-Hexacosane , n-Hexatriacontane
Applications: Paraffin wax (1) (m.p.68〜70°C)
Column: ULBON HR-1
Column Size: 25m×0.25mm(0.15μm)
Column temp.: 200°C→320°C(6°C/min)
Carrier gas: He,0.74ml/min
Detector temp.: 330°C(FID)
Injection volume: 2μl

View detail

GC
Samples: n-Eicosane , n-Pentacosane
Applications: Paraffin wax (3) (m.p.48〜50°C)
Column: ULBON HR-1
Column Size: 25m×0.25mm(0.15μm)
Column temp.: 200°C→320°C(6°C/min)
Carrier gas: He,0.74ml/min
Detector temp.: 330°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Dimethyl Phthalate , Diethyl Phthalate , Diallyl Phthalate , Di-iso-Butyl Phthalate , Di-n-Butyl Phthalate , Di-n-Amyl Phthalate , Di-2-Ethylhexyl Phthalate , Di-n-Octyl Phthalate
Applications: Phthalic acid ester (1)
Column: ULBON HR-1
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 180°C→300°C(6°C/min)
Carrier gas: He,0.98ml/min
Detector temp.: 320°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: n-Pentane , n-Hexane , Benzene , iso-Octane , Toluene , Ethylbenzene , m-Xylene , o-Xylene , p-Xylene
Applications: Premium gasoline
Column: ULBON HR-1
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→220°C(4°C/min)
Carrier gas: He,0.75ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: DDVP , Methyldimethone , Methylparathion , Ethylparathion , EPN
Applications: Organic phosphorus system pesticides (1)
Column: ULBON HR-1
Column Size: 15m×0.53mm(1.0μm)
Column temp.: 150°C→220°C(6°C/min)
Carrier gas: He,10.7ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.8μl

View detail

GC
Samples: Solvents
Applications: Solvents (5)
Column: ULBON HR-1
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→120°C(2°C/min)
Carrier gas: He,0.93ml/min
Detector temp.: 150°C(FID)
Injection volume: 1μl

View detail

GC
Samples: n-Pentane , n-Hexane , Benzene , iso-Octane , Toluene , Ethylbenzene , m-Xylene , o-Xylene , p-Xylene
Applications: Regular gasoline
Column: ULBON HR-1
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→220°C(4°C/min)
Carrier gas: He,0.75ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Cholesterol , Brassicasterol , Campesterol , Stigmasterol , β-Sitosterol
Applications: Cholesterol and Plant sterols
Column: ULBON HR-17
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 290°C
Carrier gas: He,1.5ml/min
Detector temp.: 310°C(FID)
Injection volume: 1.5μl

View detail

GC
Samples: Methanol , Ethyl Ether , Isopropanol , trans-1,2-Dichloroethylene , Ethyl Acetate , Chloroform , Isobutanol , Trichloroethylene , n-Butanol , 1,4-Dioxane , Toluene , Tetrachloroethylene , n-Butyl Acetate , Ethylbenzene , p-Xylene , Isoamyl Acetate , o-Xylene , n-Amyl Acetate , Cyclohexanol , Cyclohexanone , 2-Methylcyclohexanol , 2-Methylcyclohexanone , p-Dichlorobenzene , o-Dichlorobenzene , o-Cresol , m-Cresol
Applications: The work environment (2)
Column: ULBON HR-1701
Column Size: 30m×0.53mm(5μm)
Column temp.: 60°C→180°C(4°C/min)
Carrier gas: He,10ml/min
Detector temp.: 200°C(FID)
Injection volume: 1ml

View detail

GC
Samples: Sucrose , Maltose , Lactose , Raffinose
Applications: Sugar
Column: ULBON HR-1701
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 180°C→280°C(4°C/min)
Carrier gas: He,0.49ml/min
Detector temp.: 300°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Methanol , Ethanol , Acetone , IPA , n-Propanol , Ethyl Acetate , MEK , Chloroform , Benzene , n-Butanol , Toluene , MIBK , Isobutyl Acetate , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cellosolve Acetate
Applications: Solvents (2)
Column: ULBON HR-1701
Column Size: 25m×0.32mm(0.5μm)
Column temp.: 40°C→90°C(2°C/min)
Carrier gas: He,0.83ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Solvents (4)
Applications: Solvents (4)
Column: ULBON HR-1701
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→180°C(4°C/min)
Carrier gas: He,1.4ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Benzene , Acrylonitrile , Toluene , Ethylbenzene , iso-Propylbenzene , n-Propylbenzene , Styrene Monomer , N,N-Dimethylformamide
Applications: Styrene monomer (10ppm) in DMF
Column: ULBON HR-20M
Column Size: 30m×0.53mm(5.0μm/min)
Column temp.: 120°C
Carrier gas: He,10ml/min
Detector temp.: 200°C(FID)
Injection volume: 2μl

View detail

GC
Samples: Capric Acid Methyl Ester , Lauric Acid Methyl Ester , Myristic Acid Methyl Ester , Palmitic Acid Methyl Ester , Palmitoleic Acid Methyl Ester , Stearic Acid Methyl Ester , Oleoc Acid Methyl Ester , Linoleic Acid Methyl Ester , Linoelaidic Acid Methyl Ester , Arachidic Acid Methyl Ester , cis-11-Eicosenoic Acid Methyl Ester , Behenic Acid Methyl Ester , Erucic Acid Methyl Ester , 7,10,13,16-Docatetranoic Acid Methyl Ester , Lignoceric Acid Methyl Ester , Nervonic Acid Methyl Ester
Applications: Fatty acid methyl esters
Column: ULBON HR-20M
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 130°C→240°C(4°C/min)
Carrier gas: He,1.1ml/min
Detector temp.: 250°C(FID)
Injection volume: 1.0μm

View detail

GC
Samples: Acetic Acid , Propionic Acid , iso-Butyric Acid , n-Butyric Acid , iso-Valeric Acid , iso-Caproic Acid , n-Caproic Acid , n-Heptanoic Acid
Applications: Lower fatty Acid in water
Column: ULBON HR-20M
Column Size: 30m×0.53mm(3.0μm)
Column temp.: 150°C
Carrier gas: He,10.5ml/min
Detector temp.: 280°C(FID)
Injection volume: 0.4μl

View detail

GC
Samples: Acetaldehyde , Ethyl Acetate , Ethanol , 1-Propanol , 3-Pentanol , 2-Methyl-1-Butanol , 3-Methyl-1-Butanol
Applications: Scotch whisky
Column: ULBON HR-20M
Column Size: 50m×0.32mm(1.0μm)
Column temp.: 60°C→240°C(5°C/min)
Carrier gas: He,4.0ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.6μl

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , p-Xylene , m-Xylene , iso-Propylbenzene , o-Xylene , n-Propylbenzene , p-Ethyltoluene , m-Ethyltoluene , o-Ethyltoluene , 1,2,5-Trimethylbenzene , 1,2,4-Trimethylbenzene , 1,2,3-Trimethylbenzene , Naphthalene
Applications: Aromatic hydrocarbons in Premium gasoline
Column: ULBON HR-20M
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 50°C→180°C(2°C/min)
Carrier gas: He,1.04ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.2μl

View detail

GC
Samples: n-Butyl Formate , n-Butyl Acetate , n-Butyl Propionate , n-Butyl iso-Butyrate , n-Butyl n-Butyrate , n-Butyl Crotonate , n-Butyl n-Caproate , n-Butyl Lactate , n-Butyl n-Caprate , Di-n-Butyl Oxalate , n-Butyl Benzoate , Di-n-Butyl Malonate , Di-n-Butyl Fumarate , Di-n-Butyl Succinate , Di-n-Butyl Maleate , Di-n-Butyl Adipate , Di-n-Butyl Maleate , Di-n-Butyl Phthalate , Di-n-Butyl Sebacate , Di-n-Butyl Isophthalate , Di-n-Butyl Terephthalate , Tri-n-Butyl Citrate
Applications: Organic acid butyl ester
Column: ULBON HR-20M
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 80°C→240°C(4°C/min)
Carrier gas: He,1.1ml/min
Detector temp.: 250°C(FID)
Injection volume: 1.0μm

View detail

GC
Samples: n-Hexane , Ethyl Ether , Acetone , Methyl Acetate , trans-1,2-Dichloroethylene , Methanol , Isopropyl Acetate , Isopropanol , Dichloromethane , n-Propyl Acetate , cis-1,2-Dichloroethylene , Methyl Isobutyl Ketone , Chloroform , Toluene , 1,4-Dioxane , Isobutanol , Isoamyl Acetate , Ethylbenzene , p-Xylene , m-Xylene , Methyl Cellosolve , o-Xylene , Ethyl Cellosolve , Styrene , Cellosolve Acetate , N,N-Dimethylformamide , 4-Methylcyclohexanone , Butyl Cellosolve , cis-4-Methylcyclohexanol , m-Dichlorobenzene , p-Dichlorobenzene , trans-4-Methylcyclohexanol , o-Dichlorobenzene , o-Cresol , p-Cresol , m-Cresol
Applications: Solvents (6)
Column: ULBON HR-20M
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→240°C(3°C/min)
Carrier gas: He,1.3ml/min
Detector temp.: 250°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , p-Xylene , m-Xylene , iso-Propylbenzene , o-Xylene , n-Propylbenzene , p-Ethyltoluene , m-Ethyltoluene , o-Ethyltoluene , 1,2,5-Trimethylbenzene , 1,2,4-Trimethylbenzene , 1,2,3-Trimethylbenzene , Naphthalene
Applications: Aromatic hydrocarbons in Regular gasoline
Column: ULBON HR-20M
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 50°C→180°C(2°C/min)
Carrier gas: He,1.04ml/min
Detector temp.: 250°C(FID)
Injection volume: 0.2μl

View detail

GC
Samples: n-Octadecane , n-Docosane
Applications: Higher alcohol in Calnaubawax
Column: ULBON HR-52
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 200°C→320°C(5°C/min)
Carrier gas: He,0.5ml/min
Detector temp.: 330°C(FID)
Injection volume: 1.2μl

View detail

GC
Samples: Arachidic Acid Methyl Ester , Behenic Acid Methyl Ester , Lignoceric Acid Methyl Ester , Cerotic Acid Methyl Ester , Montanic Acid Methyl Ester , Melissic Acid Methyl Ester
Applications: Higher fatty acid esters in Calnaubawax
Column: ULBON HR-52
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 200°C→320°C(5°C/min)
Carrier gas: He,0.5ml/min
Detector temp.: 330°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Campesterol , Stigmasterol , β-Sitosterol
Applications: Plant sterol in the rice bran oil
Column: ULBON HR-52
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 250°C→320°C(5°C/min)
Carrier gas: He,0.5ml/min
Detector temp.: 330°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Methanol , Acetone , Dichloromethane , trans-1,2-Dichloroethylene , n-Hexane , Ethyl Acetate , Tetrahydrofuran , 1,1,1-Trichloroethane , Carbon Tetrachloride , Trichloroethylene , Methyl Isobutyl Ketone , Toluene , Methyl Butyl Ketone , Tetrachloroethylene , Chlorobenzene , Ethylbenzene , p-Xylene , Styrene , 1,1,2,2-Tetrachloroethane , 2-Methylcyclohexanone , 4-Methylcyclohexanone , m-Dichlorobenzene , p-Dichlorobenzene , o-Cresol , p-Cresol
Applications: The work environment (1)
Column: ULBON HR-52
Column Size: 30m×0.53mm(5μm)
Column temp.: 60°C→130°C(3°C/min)
Carrier gas: He,8.0ml/min
Detector temp.: 150°C(FID)
Injection volume: 1ml

View detail

GC
Samples: n-Octylamine , n-Decylamine , Laurylamine , n-Tetradecylamine , Cetylamine , Stearylamine
Applications: Aliphatic amine
Column: ULBON HR-52
Column Size: 25m×0.25mm(0.25μm)
Column temp.: 150°C→230°C(4°C/min)
Carrier gas: He,0.48ml/min
Detector temp.: 250°C(FID)
Injection volume: 1.5μl

View detail

GC
Samples: Dehydroepiandrosterone , Estrone , Cholestane , Progesterone , Estriol , Cholesterol , Lanosterol
Applications: Sterol
Column: ULBON HR-52
Column Size: 50m×0.25mm(0.25μm)
Column temp.: 250°C→320°C(4°C/min)
Carrier gas: He,0.57ml/min
Detector temp.: 330°C(FID)
Injection volume: 2μl

View detail

GC
Samples: Methanol , Ethanol , Acetone , n-Propanol , n-Hexane , Ethyl Acetate , Chloroform , Benzene , MIBK , Toluene , Isobutyl Acetate , n-Butyl Acetate , Ethylbenzene , m-Xylene , o-Xylene , Cellosolve Acetate
Applications: Solvents (1)
Column: ULBON HR-52
Column Size: 25m×0.32mm(0.5μm)
Column temp.: 40°C→90°C(2°C/min)
Carrier gas: He,0.83ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: n-Hexacosane , n-Hexatriacontane
Applications: Paraffin wax (2) (m.p.68〜70°C)
Column: ULBON HR-52
Column Size: 25m×0.25mm(0.15μm)
Column temp.: 200°C→320°C(6°C/min)
Carrier gas: He,0.7ml/min
Detector temp.: 330°C(FID)
Injection volume: 2μl

View detail

GC
Samples: n-Eicosane , n-Pentacosane
Applications: Paraffin wax (4) (m.p.48〜50°C)
Column: ULBON HR-52
Column Size: 25m×0.25mm(0.15μm)
Column temp.: 200°C→320°C(6°C/min)
Carrier gas: He,0.7ml/min
Detector temp.: 330°C(FID)
Injection volume: 0.5μl

View detail

GC
Samples: Methanol , Acetone , Dichloromethane , trans-1,2-Dichloroethylene , n-Hexane , Ethyl Acetate , Tetrahydrofuran , 1,1,1-Trichloroethane , Carbon Tetrachloride , Trichloroethylene , 1,4-Dioxane , Methyl Isobutyl Ketone , Toluene , Methyl n-Butyl Ketone , n-Butyl Acetate , Tetrachloroethylene , Chlorobenzene , Ethylbenzene , p-Xylene , Styrene , o-Xylene , Butyl Cellosolve , 1,1,2,2-Tetrachloroethane , 3-Methylcyclohexanol(cis, trans) , 2-Methylcyclohexanone , 4-Methylcyclohexanone , m-Dichlorobenzene , p-Dichlorobenzene , o-Dichlorobenzene , o-Cresol , p-Cresol
Applications: Solvents (3)
Column: ULBON HR-52
Column Size: 50m×0.25mm(0.5μm)
Column temp.: 60°C→130°C(3°C/min)
Carrier gas: He,1.2ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Myristic Acid Methyl Ester , Palmitic Acid Methyl Ester , Palmitoleic Acid Methyl Ester , Stearic Acid Methyl Ester , Oleoic Acid Methyl Ester , Linoleic Acid Methyl Ester , Linolenic Acid Methyl Ester
Applications: Fatty acid methyl ester of the carp
Column: ULBON HR-SS-10
Column Size: 25m×0.25mm
Column temp.: 170°C→200°C(2°C/min)
Carrier gas: He,1.5ml/min
Detector temp.: 250°C(FID)

View detail

GC
Samples: Myristic Acid Methyl Ester , Palmitic Acid Methyl Ester , Palmitoleic Acid Methyl Ester , Stearic Acid Methyl Ester , Oleoic Acid Methyl Ester , Linoleic Acid Methyl Ester , Linolenic Acid Methyl Ester , 5,8,11,14,17-Eicosapentaenoic Acid Ethyl Ester , Docosapentanoic Acid Methyl Ester , 4,7,10,13,16,19-Docosahexaenoic Acid Methyl Ester
Applications: Fatty acid methyl ester of the yellow-tail
Column: ULBON HR-SS-10
Column Size: 25m×0.25mm
Column temp.: 150°C→220°C(2°C/min)
Carrier gas: He,1.5ml/min
Detector temp.: 250°C(FID)

View detail

GC
Samples: Capric Acid Methyl Ester , Lauric Acid Methyl Ester , Myristic Acid Methyl Ester , Palmitic Acid Methyl Ester , Oleoic Acid Methyl Ester , Stearic Acid Methyl Ester , Elaidic Acid Methyl Ester , Linoelaidic Acid Methyl Ester , Linoleic Acid Methyl Ester , Linolenic Acid Methyl Ester , Arachidic Acid Methyl Ester , cis-11-Eicosenoic Acid Methyl Ester , Behenic Acid Methyl Ester , Erucic Acid Methyl Ester , Lignoceric Acid Methyl Ester , Nervonic Acid Methyl Ester , 4,7,10,13,16,19-Docosahexaenoic Acid Methyl Ester
Applications: Standard data Fatty acid methyl ester standard (2)
Column: ULBON HR-SS-10
Column Size: 50m×0.32mm
Column temp.: 150°C→220°C(3°C/min)
Carrier gas: He,3.4ml/min
Detector temp.: 250°C(FID)

View detail

GC
Samples: Myristic Acid Methyl Ester , Palmitic Acid Methyl Este , Palmitoleic Acid Methyl Ester , Stearic Acid Methyl Ester , Oleoic Acid Methyl Ester , Linoleic Acid Methyl Ester , Linolenic Acid Methyl Ester , 5,8,11,14,17-Eicosapentaenoic Acid Ethyl Ester , Docosapentanoic Acid Methyl Ester , 4,7,10,13,16,19-Docosahexaenoic Acid Methyl Ester
Applications: Fatty acid methyl ester of the tuna ( trolley )
Column: ULBON HR-SS-10
Column Size: 25m×0.25mm
Column temp.: 150°C→220°C(2°C/min)
Carrier gas: He,1.5ml/min
Detector temp.: 250°C(FID)

View detail

GC
Samples: Triglyceride
Applications: The oil ball
Column: ULBON HR-TGC1
Column Size: 25m×0.25mm(0.1μm)
Column temp.: 100°C→390°C(8°C/min)
Carrier gas: He,1.5kg/cm2
Detector temp.: 390°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Triglyceride
Applications: Calnaubawax
Column: ULBON HR-TGC1
Column Size: 25m×0.25mm(0.1μm)
Column temp.: 250°C→380°C(5°C/min)
Carrier gas: He,1.3kg/cm2
Detector temp.: 390°C(FID)
Injection volume: 0.2μl

View detail

GC
Samples: Triglyceride
Applications: Triglyceride
Column: ULBON HR-TGC1
Column Size: 25m×0.25mm(0.1μm)
Column temp.: 250°C→380°C(5°C/min)
Carrier gas: He,1.3kg/cm2
Detector temp.: 390°C(FID)
Injection volume: 0.2μl

View detail

GC
Samples: Capric Acid Methyl Ester , Lauric Acid Methyl Ester , Myristic Acid Methyl Ester , Palmitic Acid Methyl Ester , Palmitoleic Acid Methyl Ester , Stearic Acid Methyl Ester , Oleoic Acid Methyl Ester , Linoleic Acid Methyl Ester , Linolenic Acid Methyl Ester , Arachidic Acid Methyl Ester , cis-11-Eicosenoic Acid Methyl Ester , Behenic Acid Methyl Ester , Erucic Acid Methyl Ester , 4,7,10,13,16,19-Docosahexaenoic Acid Methyl Ester , Lignoceric Acid Methyl Ester , Nervonic Acid Methyl Ester
Applications: Standard data Fatty acid methyl ester standard (1)
Column: ULBON HR-Thermon-3000B
Column Size: 50m×0.25mm
Column temp.: 180°C→220°C(1°C/min)
Carrier gas: He,1.7ml/min
Detector temp.: 250°C(FID)

View detail

GC
Samples: α-Pinene , β-Pinene , Limonene , Linalool , Linalyl Acetate , Benzyl Acetate , Phenethyl Alcohol
Applications: perfume (1)
Column: ULBON HR-Thermon-600T
Column Size: 50m×0.25mm
Column temp.: 70°C→230°C(4°C/min)
Carrier gas: He,1.1ml/min
Detector temp.: 250°C(FID)

View detail

GC
Samples: β-Pinene , Limonene , Linalool , Linalyl Acetate , Benzyl Acetate , α-Ionene , Phenethyl Alcohol , Lauryl Alcohol , Eugenol , Diethyl Phthalate , Vanillin , Benzyl Salicylate
Applications: perfume (2)
Column: ULBON HR-Thermon-600T
Column Size: 50m×0.25mm
Column temp.: 70°C→230°C(4°C/min)
Carrier gas: He,1.1ml/min
Detector temp.: 250°C(FID)

View detail

GC
Samples: Methyl Mercuric Chloride , Ethyl Mercuric Chloride
Applications: Alkyl Mercury
Column: ULBON HR-Thermon-HG
Column Size: 15m×0.53mm
Column temp.: 150°C
Carrier gas: N2,4.5ml/min
Detector temp.: 220°C(ECD)
Injection volume: 1μl

View detail

GC
Samples: Tri-n-Butyltin Chloride
Applications: Tri-n-Butyltin Chloride
Column: ULBON HR-Thermon-HG
Column Size: 15m×0.53mm
Column temp.: 150°C
Carrier gas: N2,4.5ml/min
Detector temp.: 220°C(ECD)
Injection volume: 1μl

View detail

GC
Samples: n-Hexane, Benzene , n-Octane , Toluene , n-Nonane , Ethylbenzene , p-Xylene , m-Xylene , o-Xylene , Isopropylbenzene , Styrene , n-Propylbenzene , p-Ethyltoluene , m-Ethyltoluene , o-Ethyltoluene , 1,3,5-Trimethylbenzene , 1,2,4-Trimethylbenzene , 1,2,3-Trimethylbenzene , 4-n-Propyltoluene , 3-n-Propyltoluene , 2-n-Propyltoluene , 1,2,3,5-Tetramethylbenzene , 1,2,4,5-Tetramethylbenzene , 1,2,3,4-Tetramethylbenzene
Applications: Alkyl benzene isomer
Column: ULBON Xylene Master
Column Size: 50m×0.32mm
Column temp.: 70°C→120°C(2°C/min)
Carrier gas: He,1.4ml/min
Detector temp.: 200°C(FID)
Injection volume: 1μl

View detail

GC
Samples: Carbon Disulfide , Hydrogen Sulfide , Methyl Mercaptan ,Ethyl Mercaptan , DMS , Benzene . DMDS
Applications: Air pollution sulfur compound (3)
Column: β,β-ODPN 25% Chromosorb W 60-80 (AW-DMCS-ST)
Column Size: 3.1m×3.2mm
Column temp.: 70°C
Carrier gas: N2,50ml/min
Detector temp.: 180°C(FPD)
Injection volume: -

View detail

GC
Samples: Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide , Ethylene , Ethane
Applications: Inorganic gas and Lower hydrocarbons (3) Analysis by the 2m column
Column: Shincarbon-ST
Column Size: 2m × 3mmI.D.
Column temp.: 40°C (5min. hold) → 200°C (10°C/min.)
Carrier gas: He
Detector temp.: 200°C
Injection volume: 0.5mL

View detail

GC
Samples: Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide , Ethylene , Ethane
Applications: Inorganic gas and Lower hydrocarbons (4) Analysis by the 4m column
Column: Shincarbon-ST
Column Size: 4m (2m×2) × 3mmI.D.
Column temp.: 40°C (7min. hold) → 200°C (10°C/min.)
Carrier gas: He
Detector temp.: 200°C
Injection volume: 0.5mL

View detail

GC
Samples: Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide , Ethylene , Ethane
Applications: Inorganic gas and Lower hydrocarbons (5) Analysis by the 6m column
Column: Shincarbon-ST
Column Size: 6m (2m×3)) × 3mmI.D.
Column temp.: 40°C (12min. hold) → 200°C (10°C/min.)
Carrier gas: He
Detector temp.: 200°C
Injection volume: 0.5mL

View detail

GC
Samples: Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide , Ethylene , Ethane
Applications: Inorganic gas and Lower hydrocarbons (6) Analysis by the 8m column
Column: Shincarbon-ST
Column Size: 8m (2m×4) × 3mmI.D.
Column temp.: 40°C (20min. hold) → 200°C (10°C/min.)
Carrier gas: He
Detector temp.: 200°C
Injection volume: 0.5mL

View detail

GC
Samples: kerosene
Applications: Analysis of the kerosene
Column: ULBON HR-1
Column Size: 0.25mmI.D. × 50m (0.5um)
Column temp.: 90°C → 200°C (2°C/min.)
Carrier gas: He
Detector temp.: 250°C
Injection volume: 0.5ul

View detail

GC
Samples: Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide , Ethylene , Ethane
Applications: Inorganic gas and Lower hydrocarbons (7) Analysis by the 8m column
Column: Micropacked-ST
Column Size: 2m ×　1mmI.D.
Column temp.: 35°C (2min. hold) → 200°C (25°C/min.)
Carrier gas: He,200kPa
Detector temp.: 200°C
Injection volume: 0.05mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gas and Lower hydrocarbons (8) Analysis by the 8m column
Column: Micropacked-ST
Column Size: 2m ×　1mmI.D.
Column temp.: 80°C
Carrier gas: Ar,200kPa
Detector temp.: 80°C
Injection volume: 0.05mL

View detail

GC
Samples: Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gas and Lower hydrocarbons (9) Analysis by the 8m column
Column: Micropacked-ST
Column Size: 3m ×　1mmI.D.
Column temp.: 35°C (3.5min. hold) → 80°C (10°C/min.)
Carrier gas: He,300kPa
Detector temp.: 80°C
Injection volume: 0.05mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane
Applications: Inorganic gas and Lower hydrocarbons (10) Analysis by the 8m column
Column: Micropacked-MS
Column Size: 2m ×　1mmI.D.
Column temp.: 80°C
Carrier gas: He,200kPa
Detector temp.: 80°C
Injection volume: 0.05mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane
Applications: Inorganic gas and Lower hydrocarbons (11) Analysis by the 8m column
Column: Micropacked-MS
Column Size: 2m ×　1mmI.D.
Column temp.: 80°C
Carrier gas: Ar,200kPa
Detector temp.: 80°C
Injection volume: 0.05mL

View detail

GC
Samples: 1,8-Cineole , β-Phenethyl Alcohol , Benzyl Acetate
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　1
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.25um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Linalool , Anisaldehyde , Geraniol , Perillaldehyde
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　2
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: α-Pinene , Limonene , Isobornyl Acetate , α-Ionone
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　3
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Myrcene , 1,8-Cineole , L-Menthol , Anisaldehyde
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　4
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: α-Pinene , 1,8-Cineole , β-Phenethyl Alcohol
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　5
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: L-Menthon , Anisaldehyde , Geraniol , L-Perillaldehyde , α-Ionone
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　6
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Myrcene , Limonene
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　7
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Benzyl Alcohol , β-Phethyl Alcohol , Eugenol
Applications: Analysis of the fragrance of a flower using NeedlEx (for organic solvent)　8
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Ethanol , Acetic Acid , Isoamyl Alcohol , 3-(Methylthio)-1-propanol
Applications: Analysis flavor components of soy sauce using NeedlEx (for organic solvent).
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Ethanol , Acetic Acid , Isoamyl Alcohol
Applications: Analysis flavor components of worcestershire sauce using NeedlEx (for organic solvent).
Column: ULBON HR-1
Column Size: 0.32mmI.D. × 30m (0.26um)
Column temp.: 50°C→200°C(5°C/min)
Carrier gas: He,2.4ml/min
Detector temp.: 250°C(FID)
Injection volume: -

View detail

GC
Samples: Chloroform , Fenitrothion , Fluoranthene
Applications: Analysis of fenitrothion using Shinwasorb
Column: Polyphenyl Ether (5 rings) 1.5% Shinwasorb-S 100/120
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 195℃
Carrier gas: 55 mL/min N₂
Injection port temp.: 230℃
Detector temp.: 230℃
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Carbonyl sulfide , Hydrogen sulfide , Carbon disulfide , Methyl mercaptan , Ethyl mercaptan , Dimethyl sulfide , Dimethyl disulfide
Applications: Analysis of methyl mercaptan, hydrogen sulfide, dimethyl sulfide, and dimethyl disulfide using Shinwasorb
Column: β,β’-Oxydipropionitrile 12.5% Shinwasorb-S 60/80 ST
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 70℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 180℃
Detector temp.: 180℃
Detector: FPD (S)
Injection volume: 1.0 μL

View detail

GC
Samples: Trimethylamine , Dimethylamine , Methylamine
Applications: Analysis of methylamines using Shinwasorb
Column: Diglycerol+TEP+KOH 7.5+7.5+1% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 70℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 220℃
Detector temp.: 220℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: PCBs
Applications: Analysis of PCBs using Shinwasorb
Column: Silicone OV-17 2％ Shinwasorb-U 60/80　　
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 210℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: ECD
Injection volume: 4.0 μL

View detail

GC
Samples: PCBs
Applications: Analysis of PCBs using Shinwasorb
Column: Silicone OV-1 2％ Shinwasorb-U 60/80　　
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 195℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: ECD
Injection volume: 4.0 μL

View detail

GC
Samples: H2 , HD , D2
Applications: Analysis of deuterium (heavy hydrogen)
Column: Shinwa OGO-SP
Column Size: 3.0 m x 3.0 mm I.D. Stainless steel
Column temp.: -196℃
Carrier gas: 60 mL/min He
Injection port temp.: 40℃
Detector temp.: 100℃
Detector: TCD 120 mA
Injection volume: 1.0 mL

View detail

GC
Samples: Ethylene oxide , Propylene oxide
Applications: Measurement of ethylene oxide using Shinwasorb
Column: Flexol 8N8 12.5% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 150℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 150℃
Detector temp.: 150℃
Detector: FID
Injection volume: 100 μL

View detail

GC
Samples: Dichlorvos (DDVP) , Methyldemeton , Methyl parathion , Parathion , EPN
Applications: Measurement of organophosphorus compounds using Shinwasorb
Column: Silicone OV-17 1% Shinwasorb-S 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 180-250℃ (8℃/min)
Carrier gas: 50 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FPD
Injection volume: 1.0 μL

View detail

GC
Samples: 2,6-Xylenol , o-Cresol , Phenol , 2,4-Xylenol , p-Cresol , m-Cresol , 3,5-Xylenol , 3,4-Xylenol
Applications: Measurements of cresol and xylenol isomers using Shinwasorb
Column: FAP-S Shinwasorb-U 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 160℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 250℃
Detector temp.: 250℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Methyl mercuric chloride , Ethyl mercuric chloride
Applications: Measurement of alkyl mercury compounds (each 100 ppb in n-hexane) using Shinwasorb
Column: Thermon-HG 5% Shinwasorb-U 60/80
Column Size: 0.5 m x 3.0 mm I.D. Glass
Column temp.: 160℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 250℃
Detector temp.: 250℃
Detector: ECD
Injection volume: 1.0 μL

View detail

GC
Samples: long-chain fatty acid methyl esters (FAMEs)
Applications: Measurement of long-chain fatty acid methyl esters (FAMEs C10～C24) using Shinwasorb
Column: Shinchrom E71 5% Shinwasorb-U 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 230℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 250℃
Detector temp.: 250℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Ethylbenzene , p-Xylene , m-Xylene , o-Xylene
Applications: Measurement of xylene isomers using Shinwasorb
Column: Shinchrom F51+Bentone 34 3+2% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 80℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 240℃
Detector temp.: 240℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Dichloromethane , trans-1,2-Dichloroethylene , Chloroform , 1,2-Dichloroethane , 1,1,1-Trichloroethane , Carbon tetrachloride , Trichloroethylene , Toluene , Tetrachloroethylene , Chlorobenzene , 1,1,2,2,-Tetrachloroethane , o-Dichlorobenzene
Applications: Measurement of chlorinated solvents in air using Shinwasorb
Column: SBS-300 10% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 100℃
Carrier gas: 30 mL/min N₂
Injection port temp.: 240℃
Detector temp.: 240℃
Detector: FID
Injection volume: 1.0 mL

View detail

GC
Samples: palm oil
Applications: Measurement of fatty acid methyl esters (palm oil) using Shinwasorb
Column: Shinchrom E71 5% Shinwasorb-U 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 210℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: beef tallow
Applications: Measurement of Measurement of beef tallow fatty acid methyl esters (FAMEs) using Shinwasorb
Column: Shinchrom E71 5% Shinwasorb-U 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 210℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: liquefied petroleum gas (LPG)
Applications: Measurement of liquefied petroleum gas (LPG) using Shinwasorb
Column: DBM+ODPN (95:5) 35% Shinwasorb-U 60/80
Column Size: 6.0 m (3.0 m+3.0 m) x 3.0 mm I.D. stainless steel
Column temp.: 40℃
Carrier gas: 45 mL/min N₂
Injection port temp.: 50℃
Detector temp.: 50℃
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Palmitic acid , Stearic acid , Oleic acid , Linoleic acid , Linolenic acid
Applications: Measurement of fatty acid methyl esters (soy bean oil) using Shinwasorb
Column: Shinchrom E71 5% Shinwasorb-U 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 230℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: 1,1,1-Trichloroethane , Trichloroethylene , Bromodichloromethane , Chlorodibromomethane , Tetrachloroethylene , Bromoform
Applications: Measurements of trihalomethanes using Shinwasorb -1-
Column: Silicone DC-200 10% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 100℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 240℃
Detector temp.: 240℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: 1,1,1-Trichloroethane , Trichloroethylene , Bromodichloromethane , Chlorodibromomethane , Tetrachloroethylene , Bromoform
Applications: Measurements of trihalomethanes using Shinwasorb -2-
Column: Silicone DC-550 10% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 90℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 220℃
Detector temp.: 220℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetic acid , Propionic acid , Isobutyric acid , Butyric acid , Isovaleric acid , Valeric acid , Isocaproic acid , Capric acid , Enanthic acid
Applications: Measurement of short-chain free fatty acids using Shinwasorb -1-
Column: Thermon-1000+H3PO4 2.5+0.25% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 150℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 250℃
Detector temp.: 240℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetic acid , Propionic acid , Isobutyric acid , Butyric acid , Isovaleric acid , Valeric acid , Isocaproic acid , Capric acid , Enanthic acid
Applications: Measurement of short-chain free fatty acids using Shinwasorb -2-
Column: FAL-M Shinwasorb-S 60/80 PA
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 150℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene monomer , Cyclopentanol , N,N-Dimethylformamide
Applications: Measurement of styrene monomer in DMF using Shinwasorb
Column: FON 10% Shinwasorb-S 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 110℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 230℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Methyl mercuric chloride
Applications: Measurement of methylmercury in black bass using Shinwasorb
Column: Thermon-HG 5% Shinwasorb-U 60/80
Column Size: 0.5 m x 3.0 mm I.D. Glass
Column temp.: 170℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: ECD
Injection volume: 1.0 μL

View detail

GC
Samples: Methyl mercuric chloride
Applications: Measurement of methylmercury in tuna using Shinwasorb
Column: Thermon-HG 5% Shinwasorb-U 60/80
Column Size: 0.5 m x 3.0 mm I.D. Glass
Column temp.: 170℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: ECD
Injection volume: 1.0 μL

View detail

GC
Samples: Mixture of 13 organic solvents
Applications: Measurement of organic solvents using Shinwasorb -1-
Column: PEG1500 12.5% Shinwasorb-U 40/60
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 70℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Mixture of 22 organic solvents
Applications: Measurement of organic solvents using Shinwasorb -2-
Column: PEG1500 12.5% Shinwasorb-U 40/60
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 60～120℃ (4℃/min)
Carrier gas: 40 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Propyleneglycol , 1,3-propanediol
Applications: Measurement of food additives using Sunpak-A
Column: Sunpak-A 50/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 180℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Propyleneglycol , 1,3-propanediol
Applications: Measurement of food additives using Sunpak-A
Column: Sunpak-A 50/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 180℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Sorbic acid , Dehydroacetic acid , Benzoic acid , trans-Stilbene
Applications: Analysis of preservatives using Shinwasorb -1-
Column: DEGS+H3PO4 5.0+0.5% Shinwasorb-S 40/60
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 185℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: preservatives
Applications: Analysis of preservatives using Shinwasorb -2-
Column: Advance-DS+H3PO4 2+0.25% Shinwasorb-S 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 200℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 260℃
Detector temp.: 260℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Methyl iodide , iso-Propyl iodide , n-Octane , o-Xylene
Applications: Analysis of hypromellose using Shinwasorb
Column: Silicone DC-200 10% Shinwasorb-S 100/120
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 90℃
Carrier gas: 38 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Carbon sulfide , Hydrogen sulfide , Carbon disulfide , Methyl mercaptan , Ethyl mercaptane , Dimethyl sulfide
Applications: Measurements of offensive odor substances using Shinwasorb -3-
Column: 1,2,3-TCEP 25% Shinwasorb-S 80/100 ST
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 70℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 180℃
Detector temp.: 180℃
Detector: FPD
Injection volume: 1.0 μL

View detail

GC
Samples: Fragrance
Applications: Measurements of fragrance using Shinwasorb
Column: Thermon-3000 5% Shinwasorb-S 80/100
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 80～260℃（6℃/min)
Carrier gas: 50 mL/min N₂
Injection port temp.: 280℃
Detector temp.: 280℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Chloroform , Ethanol , Naphthalene , Amantadine
Applications: Measurements of amantadine hydrochloride using Shinwasorb
Column: Apiezone L+KOH 2+1% Shinwasorb-S 80/100
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 125℃(5 min hold)～150℃(5℃/min)～150℃ (10 min hold)
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: 200 ppm in hexane
Applications: Measurements of eucalyptus oil using Shinwasorb
Column: Thermon-3000 5% Shinwasorb-S 80/100
Column Size: 5.1 m x 3.2 mm I.D. Glass
Column temp.: 120℃ & 130℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: homatropine hydrobromide , atropine
Applications: Analysis of opium alkaloid atropine using Shinwasorb
Column: Silicone OV-17 1% Shinwasorb-S 60/80
Column Size: 1.6m×3.2mm glass
Column temp.: 210°C
Carrier gas: 40 mL/min N2
Injection port temp.: 270°C
Detector temp.: 270°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: homatropine hydrobromide , scopolamine
Applications: Analysis of opium alkaloid scopolamine using Shinwasorb
Column: Silicone OV-17 1% Shinwasorb-S 60/80
Column Size: 1.6m×3.2mm glass
Column temp.: 210°C
Carrier gas: 45 mL/min N2
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Benzene , Toluene , Ethylbenzene , Isopropylbenzene , n-Propylbenzene , Styrene monomer , Cyclopentanol , N, N-Dimethylformamide ,
Applications: Measurement of styrene monomer in DMF using Shinwasorb
Column: FFAP 10% Shinwasorb-U 60/80
Column Size: 3.1m×3.2mm glass
Column temp.: 120°C
Carrier gas: 50 mL/min N2
Injection port temp.: 240°C
Detector temp.: 240°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: decane , undecane , dodecane , tridecane , tetradecane , pentadecane , hexadecane , heptadecane , octadecane , nonadecane , eicosane , heneicosane , docosane
Applications: Analysis of mixture of kerosene and gas oil using Shinwasorb
Column: Silicone SE-52 5% Shinwasorb-U 40/60
Column Size: 2.5 m x 3.0 mm I.D. Stainless steel
Column temp.: 80～250℃ (6℃/min), 250℃ (12 min hold)
Carrier gas: 50 mL/min N2
Injection port temp.: 270°C
Detector temp.: 270°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Ethyl acetate , di-n-butyl phthalate , Teprenone (mono-cis isomer) , Teprenone (all-trans isomer) , ,
Applications: Analysis of teprenone using Shinwasorb -1-
Column: FFAP 5% Shinwasorb-U 80/100
Column Size: 2.1m×3.2mm glass
Column temp.: 235°C
Carrier gas: 47 mL/min N2
Injection port temp.: 270°C
Detector temp.: 270°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: n-valeric acid , valproic acid
Applications: Analysis of valproate sodium using Shinwasorb
Column: DEGA+H3PO4 2.5+0.5% Shinwasorb-S 80/100
Column Size: 2.1m×3.2mm glass
Column temp.: 145°C
Carrier gas: 35 mL/min N2
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Ethanol , Dl-camphor , Methyl salicylate ,
Applications: Analysis of dl-camphor using Shinwasorb
Column: PEG 20M 5% Shinwasorb-S 60/80
Column Size: 3.1m×3.2mm glass
Column temp.: 160°C
Carrier gas: 45 mL/min N2
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Ethyl acetate , di-n-butyl phthalate , Teprenone (mono-cis isomer) , Teprenone (all-trans isomer) , ,
Applications: Analysis of teprenone using Shinwasorb -2-
Column: FFAP 5% Shinwasorb-U 80/100
Column Size: 2.1m×3.2mm glass
Column temp.: 235°C
Carrier gas: 47 mL/min N2
Injection port temp.: 270°C
Detector temp.: 270°C
Detector: FID
Injection volume: 2.0 µL

View detail

GC
Samples: acetone , styrene , , ,
Applications: Analysis of polystyrene sulfonate calcium using Shinwasorb
Column: PEG20M 7.5% Shinwasorb-S 80/100
Column Size: 2.1m×3.2mm glass
Column temp.: 90°C
Carrier gas: 60 mL/min N2
Injection port temp.: 260°C
Detector temp.: 260°C
Detector: FID
Injection volume: 5.0 µL

View detail

GC
Samples: ethanol , n-ethyl caprylate , L-menthol , , ,
Applications: Analysis of polystyrene peppermint oil　using Shinwasorb
Column: PEG6000 12.5% Shinwasorb-S 60/80
Column Size: 2.1m×3.2mm glass
Column temp.: 140°C
Carrier gas: 33 mL/min N2
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 µL

View detail

GC
Samples: ethanol , 1-propanol , , ,
Applications: Analysis of doxycycline hydrochloride hydrate using Sunpak-A
Column: Sunpak-A 80/100
Column Size: 1.6m×3.2mm glass
Column temp.: 115°C
Carrier gas: 30 mL/min N2
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 µL

View detail

GC
Samples: docosanoic acid methyl , ethyl icosapentate ,
Applications: Analysis of ethyl icosapentate using Shinwasorb
Column: DEGS 12.5% Shinwasorb-S 60/80
Column Size: 1.8 m x 4.0 mm I.D. Glass
Column temp.: 210℃
Carrier gas: 47 mL/min N2
Injection port temp.: 230℃
Detector temp.: 200℃ 　
Detector: FID
Injection volume: 3.0 μL

View detail

GC
Samples: ethyl acetate
Applications: Analysis of sultamicillin tosilate hydrate using Sunpak-H
Column: Sunpak-H 80/100
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 130℃
Carrier gas: 34 mL/min N2
Injection port temp.: 200℃
Detector temp.: 200℃ 　
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: ethyl acetate
Applications: Analysis of sultamicillin tosilate hydrate using Sunpak-H
Column: Sunpak-H 80/100
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 130℃
Carrier gas: 34 mL/min N2
Injection port temp.: 200℃
Detector temp.: 200℃ 　
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Chloroform , Trichloroethylene , N,N-dimethylformamide ,
Applications: Analysis of tranilast using Sunpak-H ～Purity test (3) Chloroform～
Column: Sunpak-H 80/100
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 160℃
Carrier gas: 45 mL/min N2
Injection port temp.: 200℃
Detector temp.: 200℃ 　
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: N,N-dimethylformamide , Triphenylantimony , Spectinomycin ,
Applications: Analysis of spectinomycin hydrochloride hydrate using Shinwasorb
Column: Silicone SE-52 2.5% Shinwasorb-S 80/100
Column Size: 0.6 m x 3.2 mm I.D. Glass
Column temp.: 180℃
Carrier gas: 37 mL/min N2
Injection port temp.: 215℃
Detector temp.: 220℃ 　
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Petroleum ether , Methyl oleate
Applications: Analysis of oleic acid using Shinwasorb
Column: Shinchrom E71 10% Shinwasorb-U 80/100
Column Size: 2.1m×3.2mm
Column temp.: 210°C
Carrier gas: N2,21 ml/min
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 0.2 μL

View detail

GC
Samples: Ethyl acetate , Caffeine , o-Toluene sulfonamide
Applications: Analysis of saccharin using Shinwasorb
Column: DEGS 1.5% Shinwasorb-S 60/80
Column Size: 1.0 m x 3.0 mm I.D. Glass
Column temp.: 210°C
Carrier gas: N2,55ml/min
Injection port temp.: 225°C
Detector temp.: 250°C
Detector: FID

View detail

GC
Samples: Limonene , Cineole
Applications: Analysis of eucalyptus oil using Shinwasorb
Column: Thermon-3000 5% Shinwasorb-S 80/100
Column Size: 5.1 m x 3.2 mm I.D. Glass
Column temp.: 130°C
Carrier gas: N2,35ml/min
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID

View detail

GC
Samples: Dichloromethane , l-menthol ,
Applications: Analysis of l-menthol using Shinwasorb
Column: PEG6000 12.5％ Shinwasorb-S 60/80
Column Size: 2.1m x3.2 mm I.D. Glass
Column temp.: 140°C
Carrier gas: N2,33ml/min
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 5.0 μL

View detail

GC
Samples: Pyridine , N,N-dimethylformamide
Applications: Analysis of niceritrol using Shinwasorb
Column: PEG20M 5% Shinwasorb-S 80/100
Column Size: 3.1m x3.2 mm I.D. Glass
Column temp.: 160°C
Carrier gas: N2, 55ml/min
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Isopropyl iodide , Methylcyclohexane , o-xylene
Applications: Analysis of hydroxypropylcellulose (JP)
Column: ULBON HR-1
Column Size: 0.53 mm I.D. x 30 m df = 3.0 µm
Column temp.: 40℃ (3 min)～10℃/min～100℃～50℃/min～250℃ (3 min)
Carrier gas: 52 cm/sec He
Injection port temp.: 180°C
Detector temp.: 280°C
Detector: FID
Injection volume: 2.0 μL Split rate: 1:50

View detail

GC
Samples: Ethylene glycol , Diethylene glycol
Applications: Analysis of macrogol 400 using Shinwasorb
Column: Sorbitol 3% Shinwasorb-S 80/100
Column Size: 1.6 m x 3.2 mm I.D. Glass
Column temp.: 160℃
Carrier gas: 47 mL/min N2
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Cyclohexane , N,N-dimethylaniline , Naphthalene ,
Applications: Analysis of ampicillin hydrate using Shinwasorb
Column: Silicone OV-17 1.5% Shinwasorb-S 60/80
Column Size: 2.1 m x 2.6 mm I.D. Glass
Column temp.: 105℃
Carrier gas: 20 mL/min He（adjust so that the retention time of N,N-dimethylaniline is about 5 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Cyclohexane , Ethyl acetate , 2-propanol ,
Applications: Analysis of lenampicillin hydrochloride using Shinwasorb
Column: Quadrol 5% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 100℃
Carrier gas: 70 mL/min N₂ (Adjust so that the retention time of cyclohexane is about 1 minute.)
Injection port temp.: 160°C
Detector temp.: 160°C
Detector: FID
Injection volume: 4.0 μL

View detail

GC
Samples: Enflurane , 2-propanol ,
Applications: Analysis of enflurane using Shinwasorb
Column: DEGS 10% Shinwasorb-S 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 80℃
Carrier gas: 32 mL/min He (Adjust so that the retention time of enflurane is about 3 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 5.0 μL

View detail

GC
Samples: Isoflurane , Ethyl acetate
Applications: Analysis of isoflurane using Shinwasorb
Column: Igepal CO-880+Ucon LB-550X 5+7.5% Shinwasorb-S 100/120
Column Size: 3.5 m x 3.0 mm I.D. Stainless steel
Column temp.: 80℃
Carrier gas: 37 mL/min N2 (Adjust so that the retention time of isoflurane is about 7 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Pyridine , 2-ethyl-2-phenylmalonediamide , Stearylalcohol ,
Applications: Analysis of primidone using Shinwasorb ～Purity test (3) 2-ethyl-2-phenylmalonediamide～
Column: Silicone OV-17 1.5% Shinwasorb-S 100/120
Column Size: 1.6 m x 3.2 mm I.D. Glass
Column temp.: 195℃
Carrier gas: 31 mL/min N2 (Adjust so that the retention time of stearylalcohol is about 10 minutes.)
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Deet, diethyl phthalate in ethanol
Applications: Analysis of deet (Pesticide guidelines) ~Purity test (4) Related substances~
Column: ULBON HR-20M
Column Size: 0.2 mm I.D. x 25 m df = 0.1 µmm
Column temp.: 170℃
Carrier gas: 21 cm/sec He (Adjust so that the retention time of deet is about 10 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 2.0 μL (Split rate: 1:70)

View detail

GC
Samples: Methanol in ethanol
Applications: Analysis of etidronate disodium using Sunpak-A ~Purity test (4) Methanol~
Column: Sunpak-A 50/80
Column Size: 2.1m x3.2 mm I.D. Glass
Column temp.: 130℃
Carrier gas: 30 mL/min N2 (Adjust so that the retention time of methanol is about 2 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: 2-propanol, ethanol in water
Applications: Analysis of sodium aurothiomalate using Sunpak-H ~Purity test (4) Ethanol~
Column: Sunpak-H 80/100
Column Size: 3.1m x 3.2 mm I.D. Glass
Column temp.: 145℃
Carrier gas: 28 mL/min N2 (Adjust so that the retention time of 2-propanol is about 7 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: water, acetonitrile in methanol
Applications: Analysis of panipenem using Sunpak-A ~Water~
Column: Sunpak-A 80/100
Column Size: 2.1m x 3.2 mm I.D. Glass
Column temp.: 125℃
Carrier gas: 29 mL/min He (Adjust so that the retention time of acetonitrile is about 8 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetone , Ethyl acetate
Applications: Analysis of piperacillin hydrate using Sunpak-H ~(4) Residual solvents~
Column: Sunpak-H 80/100
Column Size: 1.1m x 3.2 mm I.D. Glass
Column temp.: 145℃
Carrier gas: 33 mL/min N2 (Adjust so that the retention time of ethyl acetate is about 4 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Cyclohexane , Dicyclohexyl phthalate , Etofenprox
Applications: Analysis of etofenprox using Shinwasorb
Column: Silicone OV-225 2.5% Shinwasorb-U 60/80
Column Size: 1.1m x 3.2 mm I.D. Glass
Column temp.: 240℃
Carrier gas: 37 mL/min N₂ (Adjust so that the retention time of dicyclohexyl phthalate is about 8 minutes.)
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 3.0 μL

View detail

GC
Samples: Etofenprox in Cyclohexane
Applications: Analysis of etofenprox using Shinwasorb -2- ～Purity (3) Related substances～
Column: Silicone OV-225 2.5% Shinwasorb-U 60/80
Column Size: 1.1m x 3.2 mm I.D. Glass
Column temp.: 240℃
Carrier gas: 37 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 3.0 μL

View detail

GC
Samples: o-Dichlorobenzene, m-Bromochlorobenzene in acetone
Applications: Analysis of o-dichlorobenzene using Shinwasorb
Column: PEG20M-TPA 2.5% Shinwasorb-U 60/80
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 115℃
Carrier gas: 39 mL/min N₂ (Adjust so that the retention time of o-dichlorobenzene is about 11 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Ethanol , Toluene , Chlorobenzene
Applications: Analysis of allethrin using Sunpak-H Part 1 ～Purity (4) Toluene～
Column: Sunpak-H 80/100
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 170℃
Carrier gas: 37 mL/min N₂ (Adjust so that the retention time of toluene is about 5 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetone , cis-Allethrin , trans-Allethrin
Applications: Analysis of allethrin using Shinwasorb Part 2 ～Isomer ratio～
Column: Silicone DC QF-1 2.5% Shinwasorb-U 80/100
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 165℃
Carrier gas: 45 mL/min N₂ (Adjust so that the retention time of trans-allethrin is about 40 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetone , Allethrin , Di(2-ethylhexyl) phthalate
Applications: Analysis of allethrin using Shinwasorb Part 3
Column: Diethyleneglycol Succinate (DEGS) 2.5% Shinwasorb-U 80/100
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 200℃
Carrier gas: 36 mL/min N₂ (Adjust so that the retention time of allethrin is about 8 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetone , Dichlorvos , 1-chloronaphthalene
Applications: Analysis of dichlorvos using Shinwasorb
Column: Silicone DC-550 10% Shinwasorb-S 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 180℃
Carrier gas: 40 mL/min N₂ (Adjust so that the retention time of dichlorvos is about 6 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Chloroform , Fenitrothion , Fluoranthene
Applications: Analysis of fenitrothion using Shinwasorb
Column: Polyphenyl Ether (5 rings) 1.5% Shinwasorb-S 100/120
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 195℃
Carrier gas: 55 mL/min N₂ (Adjust so that the retention time of fenitrothion is about 16 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Dichlorvos , Tributyl phosphate
Applications: Analysis of dichlorvos using Shinwasorb -2-
Column: Silicone OV-225 1% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 170℃
Carrier gas: 50 mL/min N₂（Adjust so that the retention time of tributyl phosphate is about 5 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FPD
Injection volume: 2.0 μL

View detail

GC
Samples: Acetone , Allethrin , Cinerin I , Jasmolin I , Pyrethrin I , Cinerin II , Jasmolin II , Pyrethrin II
Applications: Analysis of pyrethrum extract using Shinwasorb
Column: Silicone OV-17 1% Shinwasorb-S 80/100
Column Size: 1.1 m x 3.2 mm I.D. Glass
Column temp.: 205℃
Carrier gas: 35 mL/min N₂（Adjust so that the retention time of Allethrin is about 3 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FPD
Injection volume: 1.0 μL

View detail

GC
Samples: Dichlorvos, Diphenyl in Acetone
Applications: Analysis of dichlorvos resin strip using Shinwasorb
Column: Silicone OV-11 10% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 170℃
Carrier gas: 35 mL/min N₂（Adjust so that the retention time of dichlorvos is about 8 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 3.0 μL

View detail

GC
Samples: Diazinon, Di-n-butyl phthalate in Acetone
Applications: Analysis of diazinon using Shinwasorb
Column: Silicone OV-11 10% Shinwasorb-U 60/80
Column Size: 1.6 m x 3.2 mm I.D. Glass
Column temp.: 200℃
Carrier gas: 25 mL/min N₂（Adjust so that the retention time of diazinon is about 7 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 3.0 μL

View detail

GC
Samples: Anhydrous caffeine, Fenitrothion in Acetone
Applications: Analysis of Fenitrothion Emulsifiable Concentrate using Shinwasorb
Column: Silicone OV-210 3% Shinwasorb-S 80/100
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 175℃
Carrier gas: 51 mL/min N₂（Adjust so that the retention time of Anhydrous caffeine is about 10 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Anhydrous caffeine, Fenitrothion in Acetone
Applications: Analysis of Fenitrothion Microcapsule using Shinwasorb
Column: Silicone OV-210 1.5% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 165℃
Carrier gas: 50 mL/min N₂（Adjust so that the retention time of diazinon is about 17 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Benzyl salicylate, Fenitrothion in Acetone
Applications: Analysis of fenitrothion, phthalthrin mixed emulsifiable concentrate using Shinwasorb -1-
Column: Silicone OV-210 1.5% Shinwasorb-U 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 175℃
Carrier gas: 52 mL/min N₂ (Adjust so that the retention time of fenitrothion is about 15 minutes.)
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: FID
Injection volume: 2.0 μL

View detail

GC
Samples: Phthalthrin in Acetone
Applications: Analysis of phthalthrin using Shinwasorb ～Isomer ratio phthalthrin～
Column: Silicone DC QF-1 2.5% Shinwasorb-S 80/100
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 200℃
Carrier gas: 40 mL/min N₂（ Adjusted so that the retention time of 3.Phthalthrin is about 40 minutes.)
Injection port temp.: 230°C
Detector temp.: 230°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Organic solvents
Applications: Analysis of organic solvents using Sunpak-A -1-
Column: Sunpak-A 50/80
Column Size: 2.0 m x 3.0 mm I.D. Glass
Column temp.: 150℃ ～ 220℃ (3 min hold) program rate 4℃/min
Carrier gas: 50 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Organic solvents
Applications: Analysis of organic solvents using Sunpak-A -2-
Column: Sunpak-A 50/80
Column Size: 2.0 m x 3.0 mm I.D. Glass
Column temp.: 150℃ ～ 220℃ (3 min hold) program rate 4℃/min
Carrier gas: 50 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Acetic acid , Propionic acid , iso-butyric acid , n-butyric acid , iso-valeric acid , n-valeric avid , iso-caproic acid , n-caproic acid
Applications: Lower free fatty acid in water
Column: Sunpak-H 60/80
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 175℃
Carrier gas: 50 mL/min N₂
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: HCl , SO2 , Cl2 , CHCl3 , SO2Ci2 , CCl4 ,
Applications: Analysis of sulfuryl chloride
Column: TAKU-1 20% Shimalite-F 40/80
Column Size: 5.1 m × 3.2 mm glass
Column temp.: 70°C
Carrier gas: He, 40 ml/min
Injection port temp.: 150°C
Detector temp.: 150°C
Detector: TCD
Injection volume: 1.5 μL

View detail

GC
Samples: Air , HCl , Water
Applications: Analysis of Hydrogen chloride
Column: SF-96 15% Shimalite-F 20/80
Column Size: 3.1 m × 3.2 mm glass
Column temp.: 60°C
Carrier gas: He, 30 ml/min
Injection port temp.: 190°C
Detector temp.: 190°C
Detector: TCD
Injection volume: 1.0 ml

View detail

GC
Samples: liquefied petroleum gas (LPG)
Applications: Measurement of liquefied petroleum gas (LPG) using Supak-A
Column: Supak-A 50/80
Column Size: 2.1 m x 3.2 mm I.D. glass
Column temp.: 60℃～120℃ (5°C/min.)
Carrier gas: 50 mL/min N₂
Injection port temp.: 200℃
Detector temp.: 200℃
Detector: FID
Injection volume: 0.5 mL

View detail

GC
Samples: Diethyl ether , n-Hexane , Methanol , Methyl acetate , 2-Propanol , Ethyl acetate , Tetrahydrofuran , 2-Butanol , iso-Butanol , Toluene , n-Butyl acetate , Methyl n-butyl ketone , iso-Amyl alcohol , Ethylbenzene , m-Xylene , p-Xylene , o-Xylene , Styrene monomer ,
Applications: Measurement of organic solvents using SBS-120
Column: SBS-120 12% Shincarbon-A2 80/100
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 90℃
Carrier gas: 40 mL/min N₂
Injection port temp.: 230℃
Detector temp.: 230℃
Detector: FID
Injection volume: 1.0 μL

View detail

GC
Samples: Ammonia and Mono, Di, Tri-Methylamine in Water ,
Applications: Ammonia and Mono, Di, Tri-Methylamine in Water
Column: Thermon-3000 + KOH 2+2% Sunpak-N 60/100 mesh
Column Size: 2.1 m x 3.2 mm I.D. Glass
Column temp.: 120℃
Carrier gas: 50 mL/min He
Injection port temp.: 250°C
Detector temp.: 250°C
Detector: TCD
Injection volume: 1.0 μL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gases analysis including hydrogen by Shincarbon-ST column 2m
Column: Shincarbon-ST 50/80 mesh
Column Size: 2.0 m x 3.0 mm I.D. Stainless
Column temp.: 40°C (3 min. hold) - 200°C (20°C/min.)
Carrier gas: 50 mL/min Ar
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gases analysis including hydrogen by Shincarbon-ST column 6m
Column: Shincarbon-ST 50/80 mesh
Column Size: 6.0 m x 3.0 mm I.D. Stainless
Column temp.: 40°C (8 min. hold) - 200°C (20°C/min.)
Carrier gas: 50 mL/min Ar
Injection port temp.: 200°C
Detector temp.: 200°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane
Applications: Inorganic gases analysis including hydrogen by Molecular Sieve 5A column
Column: Molecular Sieve 5A 60/80 mesh
Column Size: 2.0 m x 3.0 mm I.D. Stainless
Column temp.: 60°C
Carrier gas: 30 mL/min Ar
Injection port temp.: 60°C
Detector temp.: 60°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane
Applications: Inorganic gases analysis including hydrogen by Molecular Sieve 13X column
Column: Molecular Sieve 13X 60/80 mesh
Column Size: 2.0 m x 3.0 mm I.D. Stainless
Column temp.: 60°C
Carrier gas: 30 mL/min Ar
Injection port temp.: 60°C
Detector temp.: 60°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gases analysis including hydrogen by Activated Charcoal column
Column: Activated Charcoal 60/80 mesh
Column Size: 2.0 m x 3.0 mm I.D. Stainless
Column temp.: 60°C
Carrier gas: 30 mL/min Ar
Injection port temp.: 60°C
Detector temp.: 60°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gases analysis including hydrogen by Silica Gel column
Column: Silica Gel 60/80 mesh
Column Size: 2.0 m x 3.0 mm I.D. Stainless
Column temp.: 60°C
Carrier gas: 30 mL/min Ar
Injection port temp.: 60°C
Detector temp.: 60°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gases analysis including hydrogen by Sunpak-A column
Column: Sunpak-A 50/80 mesh
Column Size: 2.0 m x 3.0 mm I.D. Stainless
Column temp.: 40°C
Carrier gas: 30 mL/min Ar
Injection port temp.: 60°C
Detector temp.: 60°C
Detector: TCD
Injection volume: 1.0 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane , Carbon Dioxide
Applications: Inorganic gases analysis including hydrogen by Micropacked-ST column
Column: Micropacked-ST
Column Size: 2.0 m x 1.0 mm I.D. Stainless
Column temp.: 80°C
Carrier gas: 200 kPa Ar
Injection port temp.: 80°C
Detector temp.: 80°C
Detector: TCD
Injection volume: 0.05 mL

View detail

GC
Samples: Hydrogen , Oxigen , Nitrogen , Carbon Monoxide , Methane
Applications: Inorganic gases analysis including hydrogen by Micropacked-MS column
Column: Micropacked-MS
Column Size: 2.0 m x 1.0 mm I.D. Stainless
Column temp.: 80°C
Carrier gas: 200 kPa Ar
Injection port temp.: 80°C
Detector temp.: 80°C
Detector: TCD
Injection volume: 0.05 mL

View detail

GC
Samples: Oxigen , Nitrogen
Applications: Oxygen purity test (JP) by Molecular Sieve 5A column
Column: Molecular Sieve 5A 45/60 mesh
Column Size: 3.1 m x 3.2 mm I.D. Glass
Column temp.: 50°C
Carrier gas: 30 mL/min He
Injection port temp.: 80°C
Detector temp.: 80°C
Detector: TCD
Injection volume: 1.0 mL

View detail

LC
Samples: Ethiazide
Applications: Ethiazide
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92.5/7.5
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Terbutaline
Applications: Terbutaline
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/CH3CN = 99/1
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Eperisone
Applications: Muscle relaxant
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 0.6 mL/min
Column temp.: 25°C

View detail

LC
Samples: Clorprenaline
Applications: Clorprenaline
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 94/6
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlormezanone
Applications: Chlormezanone
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 93/7
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alimemazine
Applications: Antihistaminic drug
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/CH3CN = 70/30
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Thioridazine
Applications: Thioridazine
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 75/25
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Methylphenidate
Applications: The central neuron stimulant
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/CH3CN = 90/10
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Trimipramine
Applications: Trimipramine
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 75/25
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Flavanone
Applications: Flavanone
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Hexobarbital
Applications: Hexobarbital
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 83/17
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Benzoin
Applications: Benzoin
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 88/12
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlorpheniramine maleate
Applications: Chlorpheniramine maleate
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 83/17
Frow rate: 1.0 mL/min
Column temp.: 15°C

View detail

LC
Samples: Mephobarbital
Applications: Mephobarbital
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 0.6 mL/min
Column temp.: 25°C

View detail

LC
Samples: PTH-valine
Applications: PTH-valine
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3OH = X/Y
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: (1S,2R)-1-Methyl cis-1,2,3,6-tetrahydrophthalate
Applications: (1S,2R)-1-Methyl cis-1,2,3,6-tetrahydrophthalate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: 1,2-Diphenylethylamine
Applications: 1,2-Diphenylethylamine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Oxprenolol
Applications: Oxprenolol
Column: ULTRON ES-OVM
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/CH3CN = 100/10
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bunitrolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/C2H5OH = 100/3
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Arotinolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Pindolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)/C2H5OH = 100/30
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Propranolol
Applications: β-Blocking agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.8)/CH3CN = 100/30
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bay K 8644
Applications: Calcium rivalry medicine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Verapamil
Applications: Calcium rivalry medicine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Prenylamine
Applications: Calcium rivalry medicine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/CH3CN = 100/15
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Clorprenaline
Applications: Bronchodilator agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)/C2H5OH = 100/3
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bupivacaine
Applications: The local anesthetic
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)/CH3CN = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlormezanone
Applications: Muscle relaxant
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Tolperisone
Applications: Muscle relaxant
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.5)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ethiazide
Applications: Antihypertensive diuretic
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Trimipramine maleate
Applications: Analysis of the antidepressive drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/C2H5OH = 100/30
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Flurbiprofen
Applications: Flurbiprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ibuprofen
Applications: Ibuprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ketoprofen
Applications: Antiinflammatory agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Pranoprofen
Applications: Antiinflammatory agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/8
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Zaltoprofen
Applications: Antiinflammatory agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 87/13
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Mepenzolate bromide
Applications: Anticholinergic agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Thioridazine hydrochloride
Applications: Antipsychotic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 77/23
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Mephobarbital
Applications: Antiepileptic
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Acetylpheneturide
Applications: Antiepileptic
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/7.5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Biperiden
Applications: Antiparkinsonic agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Profenamine
Applications: Antiparkinsonic agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Trihexyphenidyl
Applications: Antiparkinsonic agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alimemazine
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlorpheniramine
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Dimethindene maleate
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 100/9
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Homochlorcyclizine
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/20
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Promethazine
Applications: Antihistaminic drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 3.0)/CH3CN = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Hydroxyzine
Applications: Antianxiety agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Disopyramide phosphate
Applications: Disopyramide phosphate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/C2H5OH = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Glutethimide
Applications: Hypnotic
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Hexobarbital
Applications: Hypnotic
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 6.0)/C2H5OH = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Proglumide
Applications: Peptic ulcer agent
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/C2H5OH = 100/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Thyroxine
Applications: Thyroxine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/CH3CN = 100/20
Frow rate: 1.2 mL/min
Column temp.: 15°C

View detail

LC
Samples: Benproperine
Applications: Antitussive drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 100/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Meclizine
Applications: Meclizine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/C2H5OH = 100/35
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Flavanone
Applications: Flavonoid
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/CH3CN = 100/30
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Benzoin
Applications: Benzoin
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/C2H5OH = 100/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Chlorphenesin
Applications: Muscle relaxant
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 5.5)
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Eperisone
Applications: Muscle relaxant
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 5.5)/C2H5OH = 100/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Cloperastine
Applications: Antitussive drug
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 (pH 4.6)/C2H5OH = 100/15
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Atenolol
Applications: Atenolol
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20mM KH2PO4 + 20mM K2HPO4 (pH 6.0)/C2H5OH = 99/1
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alprenolol
Applications: β-Blocking agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.9 µL (0.6 mg/mL)

View detail

LC
Samples: Bufetolol
Applications: β-Blocking agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL (ca. 1 mg/mL)

View detail

LC
Samples: Terbutaline
Applications: Bronchodilator agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 6.0)
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 5 µL (ca. 0.25 mg/mL)

View detail

LC
Samples: Salbutamol
Applications: Bronchodilator agent
Column: ULTRON ES-PEPSIN
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 5.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL (0.25 mg/mL)

View detail

LC
Samples: 1,1'-Bi-2-naphthol
Applications: 1,1'-Bi-2-naphthol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: n-Hexane/Dichloromethane/CH3OH = 75/25/5
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: α-Phenylethylamine , (S)-(-)-α-Methylbenzylamine
Applications: α-Phenylethylamine
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 95/5
Frow rate: 0.6 mL/min
Column temp.: 15°C

View detail

LC
Samples: α-Phenylethylalchol
Applications: α-Phenylethylalchol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 0.6 mL/min
Column temp.: 15°C

View detail

LC
Samples: Propranolol
Applications: β-Blocking agent
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 65/35
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 20 µL

View detail

LC
Samples: Acetylpheneturide
Applications: Antiepileptic
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 76/24
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Atenolol
Applications: Atenolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 90/10
Frow rate: 0.3 mL/min
Column temp.: 25°C

View detail

LC
Samples: Alprenolol
Applications: Alprenolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Arotinolol
Applications: Arotinolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 75/25
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bupivacaine
Applications: The local anesthetic
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Eperisone
Applications: Muscle relaxant
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 70/30
Frow rate: 1.2 mL/min
Column temp.: 9°C

View detail

LC
Samples: Chlormezanone
Applications: Muscle relaxant
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 70/30
Frow rate: 0.6 mL/min
Column temp.: 9°C

View detail

LC
Samples: Chlorphenesin
Applications: Muscle relaxant
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 70/30
Frow rate: 0.6 mL/min
Column temp.: 9°C

View detail

LC
Samples: trans-Stilbene oxide
Applications: Analysis in normal phase mobile phase
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: n-Hexane/CH3OH = 99.9/0.1
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: N-(3,5-Dinitrobenzoyl)-α-Methylbenzylamine
Applications: Analysis in normal phase mobile phase
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: n-Hexane/C2H5OH = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Flavanone
Applications: Analysis in normal phase mobile phase
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: n-Hexane/C2H5OH = 99/1
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Pindolol
Applications: Pindolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bunitrolol
Applications: β-Blocking agent
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 70/30
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Propranolol
Applications: Propranolol
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 60/40
Frow rate: 1.2 mL/min
Column temp.: 25°C

View detail

LC
Samples: Sucrose , Lactose , Glucose , Galactose , Fructose
Applications: Yoghurt drink
Column: ULTRON PS-80C
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 0.5 mL/min
Column temp.: 80°C
Pressure: 2.0 MPa
Injection volume: 10 µL

View detail

LC
Samples: Formaldehyde, Acetaldehyde, Ethanol
Applications: Formaldehyde, Acetaldehyde, Ethanol
Column: ULTRON PS-80H
Column Size: 50 mm L × 8.0 mm I.D. + 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.5 MPa

View detail

LC
Samples: Ethylene glycol , Diethylene glycol , Methanol , Ethanol , Isopropyl alcohol
Applications: Alcohols
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.5 MPa
Injection volume: 6.0 µL (10 mg/mL)

View detail

LC
Samples: Glucuronic acid , N-Acetylglucosamine , N-Acetylgalactosamine
Applications: Uronic acid, Acetylation amino sugar
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.5 MPa

View detail

LC
Samples: Citric acid , Tartaric acid , Malic acid , Malonic acid , Succinic acid , Glycolic acid , Formic acid , Lactic acid , Acetic acid , Fumaric acid , Adipic acid , Pyroglutamic acid , Propionic acid , Acrylic acid , Pivalic acid , Methacrylic acid , Crotonic acid
Applications: Elution position of the aliphatic organic acid
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D. + 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)
Frow rate: 1.0 mL/min
Column temp.: 60°C

View detail

LC
Samples: Citric acid , Tartaric acid , Malic acid , Succinic acid , Lactic acid , Acetic acid , Pyroglutamic acid
Applications: Analysis of the soy sauce
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)
Frow rate: 1.0 mL/min
Column temp.: 60°C

View detail

LC
Samples: Citric acid , Tartaric acid , Malonic acid , Succinic acid , Lactic acid , Acetic acid , Gallic acid , Propionic acid , Phthalic acid , Phenoxyacetic acid , m-Hydroxybenzoic acid , p-Hydroxybenzoic acid , Vanilic acid , Caffeic acid , Benzoic acid , o-Hydroxybenzoic acid
Applications: Elution position of the aromatic organic acid
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4aq. (pH 2.1)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 60°C

View detail

LC
Samples: Stachyose , Raffinose , Glucose
Applications: Separation of stachyose and raffinose
Column: ULTRON PS-80N
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.5 MPa
Injection volume: 10 µL (2 mg/mL)

View detail

LC
Samples: Maltotriose , Maltose , Glucose , Glycerol , Ethanol
Applications: Sake
Column: ULTRON PS-80N
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.2 MPa
Injection volume: 10 µL (undiluted solution)

View detail

LC
Samples: Maltotriose , Maltose , Glucose
Applications: Starch syrup
Column: ULTRON PS-80N
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 60°C
Pressure: 2.2 MPa
Injection volume: 5 µL (25 mg/mL)

View detail

LC
Samples: Sucrose , Lactose , Glucose , Xylose , Galactose , Fructose , Inositol
Applications: Sugar and alditol
Column: ULTRON PS-80P
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 80°C
Pressure: 2.0 MPa

View detail

LC
Samples: Nicotinamide adenine dinucleotide oxidized , Nicotinamide adenine dinucleotide reduced
Applications: NAD, NADH
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM NH4H2PO4 (pH 2.6)
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Aspartic acid , Glutamic acid , Serine , Glycine , Histidine , Arginine , Threonine , Alanine , Proline , Tyrosine , Valine , Methionine , Cysteine-cysteine , Isoleucine , Leucine , Phenylalanine , Lysine
Applications: Analysis of the PTC amino acid
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: A: CH3COONa (pH 6.5)/CH3CN = 93/7, B: CH3CN/H2O = 4/1
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Asulam
Applications: Asulam
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 50 mM Phosphoric acid buffer (pH 3.3)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Saccharin, Aspartame, Benzoic acid, Sorbic acid
Applications: Saccharin, Aspartame, Benzoic acid, Sorbic acid
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 40 mM Acetate buffer (pH 4.0)/CH3OH = 3/1
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Iprodione, Bensulide
Applications: Iprodione, Bensulide
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 60/40
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Hippuric acid , o-Methyl hippuric acid , p-Methyl hippuric acid , m-Methyl hippuric acid
Applications: Hippuric acid
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer (pH 2.5) + 10 mM β-Cyclodextrin/CH3CN = 8/1
Frow rate: 1.0 mL/min
Column temp.: 50°C

View detail

LC
Samples: Arbutin , Hydroquinone , Gallic acid
Applications: Arbutin in the Bearberry Leaf end
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100 mM Phosphoric acid buffer (pH 2.1)/CH3OH = 40/1
Frow rate: 0.9 mL/min
Column temp.: 35°C

View detail

LC
Samples: Berberine
Applications: Berberine in the Coptis end
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: The result of dissolving potassium dihydrogenphosphate 3.4 g and sodium lauryl sulfate 1.7 g at water 1 L/CH3CN = 1/1
Frow rate: 0.5 mL/min
Column temp.: 40°C

View detail

LC
Samples: Oxine-copper
Applications: Oxine-copper
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 50 mM Phosphoric acid buffer (pH 2.2)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Cytosine , Uracil , Guanine , Adenine , Cytidine , Uridine , Thymine , Adenosine , Guanosine , Thymidine
Applications: Nucleic acid base, Nucleoside
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 0.1 M Phosphoric acid buffer (pH 2.1) + 0.2 M NaClO4
Frow rate: 1.0 mL/min
Column temp.: 50°C

View detail

LC
Samples: Methylephedrine hydrochloride , Noscapine , Thiamine , Dextromethorphan , Carbinoxamine maleate
Applications: The component of the cold remedy (1)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O/H3PO4 = 510/490/1 + 0.5% Sodium dodecyl sulfate
Frow rate: 1.0 mL/min
Column temp.: 50°C

View detail

LC
Samples: Acetaminophen , Caffeine , Riboflavin , Phenol , Potassium guaiacol-4-sulfonate
Applications: The component of the cold remedy (2)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: H2O/CH3CN/50 mM Tetrabutylammonium = 15/2/1 (Adjusted to pH 6 with Phosphoric acid)
Frow rate: 1.0 mL/min
Column temp.: 50°C

View detail

LC
Samples: Glycyrrhetic acid , Propyl paraben
Applications: Glycyrrhizin in the licorice end
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 15 times dilution Acetic acid aqueous solution/CH3CN = 3/2
Frow rate: 0.7 mL/min
Column temp.: ambient

View detail

LC
Samples: 1,5-Dihydroxyanthraquinone
Applications: The elution behavior of the sample which forms metal complex
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer (pH 7.6)/CH3OH = 30/70
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Acetylacetone
Applications: The elution behavior of the sample which forms metal complex
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer (pH 7.6)/CH3OH = 30/70
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Ethosuximide , Primidone , Phenobarbital , Phenytoin , Carbamazepin
Applications: Anticonvulsant analysis
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100 mM Phosphoric acid buffer(pH 4.0)/CH3OH/CH3CN = 4/2/1
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Methyl p-hydroxybenzoate , Ethyl p-hydroxybenzoate , Propyl p-hydroxybenzoate , Butyl p-hydroxybenzoate
Applications: The elution behavior of the acid sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 50/50
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Methyl salicylate , Ethyl salicylate , Propyl salicylate , Butyl salicylate
Applications: The elution behavior of the acid sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 70/30
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Benzoic acid , p-Toluic acid , p-Ethylbenzoic acid
Applications: The elution behavior of the acid sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/0.1% Phosphoric acid = 50/50
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Paeoniflorin
Applications: Paeoniflorin in the peony end
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM CH3COONa (pH 4.8)/CH3CN = 5/1
Frow rate: 0.5 mL/min
Column temp.: 40°C

View detail

LC
Samples: Salicylic acid , Diphenhydramine , Methyl salicylate , α-Camphor , Thymol
Applications: The component of the anti-inflammatory agent
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM Phosphoric acid buffer(pH 2.6) + 20 mM Heptane sodium sulphonate/CH3OH/CH3CN = 3/2/2
Frow rate: 1.0 mL/min
Column temp.: 45°C

View detail

LC
Samples: Vitamin A , Vitamin D2 , Vitamin D3 , Vitamin E , Tocopherol acetate
Applications: Fat-soluble vitamin
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Hypoxanthine , Inosine 5'-monophosphate , Adenosine 5'-diphosphate , Adenosine 5'-monophosphate , Inosine , Adenosine 5'-triphosphate
Applications: The freshness K value
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 24 mM 2-Diethylaminoethanol + 16 mM Citric acid
Frow rate: 2.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Nicotinic acid , Nicotinamide , Pantothenic acid , Pyridoxine , Riboflavin phosphate , Thiamine , Caffeine , Folic acid , Biotin , Riboflavin
Applications: The water-soluble vitamin (1)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100 mM Phosphoric acid buffer(pH 2.1) + 0.8 mM Octane sodium sulphonate/CH3CN = 9/1
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Pyridoxal , Pyridoxine , Pyridoxamine
Applications: The water-soluble vitamin (2)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100 mM Phosphoric acid buffer(pH 2.1) + 50 mM Hexane sodium sulphonate/CH3CN = 9/1
Frow rate: 1.0 mL/min
Column temp.: 45°C

View detail

LC
Samples: Cholic acid , Glycocholic acid , Taurocholic acid , Chenodeoxycholic acid , Glycochenodeoxycholic acid , Deoxycholic acid , Taurochenodeoxycholic acid , Taurodeoxycholic acid
Applications: Bile acid
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/30 mM (NH4)2HPO4(Ajusted to pH 7.2 with NH4H2PO4), A: 10/90, B: 50/50
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Thiuram
Applications: Thiuram
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 50/50
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Cytidine 5'-monophosphate , Uridine 5'-monophosphate , Guanosine 5'-monophosphate , Adenosine 5'-triphosphate , Cytidine , Uridine , Adenosine 5'-monophosphate , Inosine , Guanosine
Applications: Nucleoside, Nucleotide
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 0.1 M KH2PO4(pH 5.8) + 0.2 mM Na2SO4
Frow rate: 1.0 mL/min
Column temp.: ambient
Pressure: UV-254 nm

View detail

LC
Samples: Methyl paraben , Ethyl paraben , Isopropyl paraben , Propyl paraben , Isobutyl paraben , Butyl paraben , Each 100ppm containing
Applications: Paraben (Added to commercial soy sauce)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM Phosphoric acid buffer(pH 2.6)/CH3OH = 1/1
Frow rate: 1.5 mL/min
Column temp.: 40°C

View detail

LC
Samples: Prostaglandin , 2,4,5-Trihydroxybutyrophenone , Nordihydroguaiaretic acid , Butyl hydroxy anisole , Octyl gallate , 2,6-Di-tert-butyl-4-hydroxymethylphenol , Lauryl gallate , 2,6-Di-t-butyl 4-methylphenol
Applications: The phenolic system antioxidant (Added to commercial edible oil)
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: A: 10 mM Phosphoric acid buffer(pH 2.6), B: CH3CN
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Tartaric acid , Malic acid , Malonic acid , Acetic acid , Citric acid , Succinic acid , Malic acid degradate , Propionic acid
Applications: Organic acids
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 5 mM NH4H2PO4(pH 2.4)
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Procaineamide , N-Acetylprocaineamide
Applications: The elution behavior of the basic sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer(pH 7.6)/CH3OH = 6/4
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Berberine
Applications: The elution behavior of the basic sample
Column: STR ODS-II
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM Phosphoric acid buffer(pH 2.6)/100 mM NaClO4/CH3CN = 2/2/1
Frow rate: 1.0 mL/min
Column temp.: 50°C

View detail

LC
Samples: p-Hydroxybenzoic acid , m-Hydroxybenzoic acid , Phenol , Acetylsalicylic acid , Benzoic acid , Salicylic acid
Applications: Acidic compounds
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM (NH4)3PO4(pH 2.5)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Pyridine , Phenol
Applications: Pyridine, Phenol test
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 30/70
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Inosine 5'-monophosphate , Pyroglutamic acid
Applications: 5'-IMP(Inosinic acid), Pyroglutamic acid
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer(pH 6.7)/CH3OH = 99/1
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: β-Carotene
Applications: β-Carotene
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3OH/Tetrahydrofuran = 9/1 + 0.05% BHT
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Glycyrrhizin
Applications: Glycyrrhizin
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 7/3
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Glycyrrhetic acid
Applications: Glycyrrhetic acid
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 1/4
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Cortisone acetate , Butyl p-hydroxybenzoate
Applications: Cortisone acetate, Butyl p-hydroxybenzoate
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/H2O = 35/65
Frow rate: 1.0 mL/min
Column temp.: 30°C

View detail

LC
Samples: Oxalic acid , Nitric acid
Applications: Oxalic acid (COO-)2, Nitric acid(NO3-)
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 2.2)/CH3OH = 91/9 + 2 mM Tetrabutylammonium bromide
Frow rate: 1.0 mL/min
Column temp.: ambient

View detail

LC
Samples: Maleic acid , Ascorbic acid , Citric acid , Fumaric acid
Applications: Organic acid and vitamin C in the juice (other the maleic acid)
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer(pH 2.4)
Frow rate: 0.8 mL/min
Column temp.: ambient

View detail

LC
Samples: Nicotinic acid , Nicotinic acid amide , Calcium pantothenate , Pyridoxine hydrochloride , Riboflavin phosphate , Thiamine , Folic acid , Biotin , Riboflavin
Applications: The water-soluble vitamin
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM H3PO4/5 mM Sodium 1-hexanesulfonate = 91/9
Frow rate: 1.0 mL/min
Column temp.: 45°C

View detail

LC
Samples: Predonisone , Cortisone , Hydrocortisone , Cortisone acetate , Hydrocortisone acetate
Applications: Separation of the steroid
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: H2O/CH3OH/THF = 70/10/20
Frow rate: 1.0 mL/min
Column temp.: 40°C

View detail

LC
Samples: Uric acid, Hypoxanthine, Xanthine, Inosine
Applications: Uric acid, Hypoxanthine, Xanthine, Inosine
Column: ULTRON VX-ODS
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM Phosphoric acid buffer(pH 6.7)/CH3OH = 99/1
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Estrone , Estradiol , Estriol
Applications: Female sex hormone
Column: ULTRON VX-SIL
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: n-Hexane/C2H5OH = 90/10
Frow rate: 1.0 mL/min
Column temp.: ambient

View detail

LC
Samples: Bepotastine besilate
Applications: Bepotastine besilate
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 75/25
Frow rate: 0.7 mL/min
Column temp.: 40°C

View detail

LC
Samples: 2-(4-Hydroxyphenoxy)propionic acid
Applications: 2-(4-Hydroxyphenoxy)propionic acid
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: 2-(4-Hydroxyphenoxy)propionic acid
Applications: 2-(4-Hydroxyphenoxy)propionic acid
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Aminoglutethimide
Applications: Aminoglutethimide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 92/8
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Amlodipine
Applications: Amlodipine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Benidipine hydrochloride
Applications: Benidipine hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bepotastine besilate
Applications: Bepotastine besilate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bepridil hydrochloride
Applications: Bepridil hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bicalutamide
Applications: Bicalutamide
Column: ULTRON ES-CD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bicalutamide
Applications: Bicalutamide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/CH3CN = 87/13
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bromacil
Applications: Bromacil
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Brompheniramine maleate
Applications: Brompheniramine maleate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Candesartan cilexetil
Applications: Candesartan cilexetil
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4/CH3CN = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Duloxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Duloxetine hydrochloride
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4(pH 3.0)/CH3CN = 65/35
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: EDDP perchlorate
Applications: EDDP perchlorate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Omeprazole
Applications: Omeprazole
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 95/5
Frow rate: 0.9 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ornidazole
Applications: Ornidazole
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3OH = 95/5
Frow rate: 0.5 mL/min
Column temp.: 25°C

View detail

LC
Samples: Amlodipine
Applications: Amlodipine
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Atomoxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Atomoxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Azelnidipine
Applications: Azelnidipine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/C2H5OH = 72/28
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Bupropion hydrochloride
Applications: Bupropion hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/C2H5OH = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Candesartan cilexetil
Applications: Candesartan cilexetil
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4/CH3CN = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Carvedilol
Applications: Carvedilol
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 7.0)/CH3OH = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Carvedilol
Applications: Carvedilol
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 7.0)/CH3OH = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Cetirizine hydrochloride
Applications: Cetirizine hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2 µL
Diluent: mobile phase

View detail

LC
Samples: Cetirizine hydrochloride
Applications: Cetirizine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Doxylamine succinate
Applications: Doxylamine succinate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 6.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Duloxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Escitalopram oxalate
Applications: Escitalopram oxalate
Column: ULTRON ES-OVM , ULTRON ES-OVM-E
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 50 mM KH2PO4 + 0.2 N NaOH(pH 7.0)/CH3CN = 85/15
Frow rate: 0.6 mL/min
Column temp.: 30°C

View detail

LC
Samples: Formoterol fumarate
Applications: Formoterol fumarate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 7.0)/C2H5OH = 94/6
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Formoterol fumarate
Applications: Formoterol fumarate
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4(pH 7.0)/C2H5OH = 94/6
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ibuprofen
Applications: Ibuprofen
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH 4.6)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Ipratropium bromide
Applications: Ipratropium bromide
Column: ULTRON ES-PhCD
Column Size: 150 mm L × 6.0 mm I.D.
Mobile phase: 20 mM KH2PO4(pH4.6)/CH3CN = 65/35
Frow rate: 1.0 mL/min
Column temp.: 25°C

View detail

LC
Samples: Acetyl-L-carnitine, L-Carnitine
Applications: Acetyl-L-carnitine, L-Carnitine
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 20 mM CH3CO2NH4(pH 4.7)/CH3CN = 20/80
Frow rate: 0.4 mL/min
Column temp.: 30°C
Injection volume: 0.1 µL

View detail

LC
Samples: Nicotinamide , Pyridoxine , Isoascorbic acid , Riboflavin , Nicotinic acid , Ascorbic acid , Biotin , Pantothenic acid , Folic acid , Cyanocobalamin , Thiamine
Applications: Water-soluble vitamins
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: A: 20 mM CH3CO2NH4(pH 6.8)/CH3CN = 10/90, B: 20 mM CH3CO2NH4(pH 6.8)/CH3CN = 70/30
Frow rate: 0.25 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL

View detail

LC
Samples: Allantoin , Xanthine , Hypoxanthine , Uric acid
Applications: Uric acid metabolites
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10 mM CH3CO2NH4(pH 4.7)/CH3CN = 10/90
Frow rate: 0.35 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL

View detail

LC
Samples: Ethyl α-D-glucoside , Fructose , Glucose , Sucrose , Maltose , Lactose
Applications: Sugars in food
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10 mM CH3CO2NH4(pH 6.8)/CH3CN = 12/88
Frow rate: 0.3 mL/min
Column temp.: 40°C
Injection volume: 1.0 µL (each 1 mg/mL)

View detail

LC
Samples: Theophylline , 1.7-Dimethylxanthine , Theobromine
Applications: Xanthines
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10 mM CH3CO2NH4(pH 6.8)/CH3CN = 13/87
Frow rate: 0.15 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL

View detail

LC
Samples: Urea , Xanthine , Lactic acid , Creatinine , Uric acid
Applications: Sweat Composition
Column: ULTRON AF-HILIC-CD (PLSS)
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10 mM HCO2NH4(pH 3.0)/CH3CN = 10/90
Frow rate: 0.30 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL

View detail

LC
Samples: Caffeine , Theobromine , Purine , Xanthine , Hypoxanthine , Adenine , Guanine , Uric acid , Isoguanine
Applications: Purine and purine bases
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 15 mM CH3CO2NH4(pH 4.7)/CH3CN = 10/90
Frow rate: 0.35 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL

View detail

LC
Samples: (CYS)2 , LYS , ARG , HIS , ASP , GLU , GLN , ASN , GLY , SER , ALA , THR , PRO , TYR , VAL , PHE , MET , TRP , LEU+ILE
Applications: Analysis of underivatized amino acids by LC/MS/MS
Column: ULTRON AF-HILIC-CD (PLSS)
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: A: 100 mM HCO2NH4(pH 3.0)/CH3CN = 10/90, B: 100 mM HCO2NH4(pH 3.0)/CH3CN = 70/30
Frow rate: 0.36 mL/min
Column temp.: 40°C
Injection volume: 1.0 µL (5.0 µg/mL)

View detail

LC
Samples: Fucose , Xylose , GalNAc , Mannose , Glucose , GluNAc , Galactose , Neu5Ac , Glucuronic acid
Applications: Glycan-constituting monosaccharides
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: A: 200 mM CH3CO2NH4(pH 6.8)/CH3CN = 10/90 (for peak 1 to 7), B: 200 mM CH3CO2NH4(pH 6.8)/CH3CN = 18/82 (for peak 8 and 9)
Frow rate: 0.26 mL/min
Column temp.: 45°C
Injection volume: 1.0 µL

View detail

LC
Samples: Cyanuric acid , Ammelide , Melamine , Ammeline
Applications: Melamine-related compounds
Column: ULTRON AF-HILIC-CD
Column Size: 100 mm L × 2.0 mm I.D.
Mobile phase: 20 mM HCO2NH4(pH 6.8)/CH3CN = 18/82
Frow rate: 0.15 mL/min
Column temp.: 30°C
Injection volume: 0.8 µL

View detail

LC
Samples: Mirabegron
Applications: β3 adrenergic receptor agonist
Column: ULTRON ES-PhCD
Column Size: 250 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/50mM KH2PO4(pH 4.0) = 200/750
Frow rate: 0.9 mL/min
Column temp.: 50°C
Injection volume: 20 µL

View detail

LC
Samples: Formaldehyde , Methanol , Acetone
Applications: Formaldehyde , Methanol , Acetone
Column: ULTRON PS-80H
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: HClO4 aq
Frow rate: 1.0 mL/min
Column temp.: 60°C
Injection volume: 10 µL
Diluent: mobile phase

View detail

LC
Samples: Toluene , Uridine , 2'-Deoxyuridine , 5-Methyluridine , Adenosine , Vidarabine , 2'-Deoxyguanosine , 3'-Deoxyguanosine , 4-Nitrophenyl-α-glucopyranoside , 4-Nitrophenyl-β-glucopyranoside , Theophylline , Theobromine ,
Applications: Analysis of polar compounds
Column: ULTRON AF-HILIC-CD
Column Size: 100 mm L × 4.6 mm I.D.
Mobile phase: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90
Frow rate: 0.50 mL/min
Column temp.: 30°C
Injection volume: 4.0 µL
Diluent: mobile phase

View detail

LC
Samples: Toluene , Uridine , 2'-Deoxyuridine , 5-Methyluridine , Adenosine , Vidarabine , 2'-Deoxyguanosine , 3'-Deoxyguanosine , 4-Nitrophenyl-α-glucopyranoside , 4-Nitrophenyl-β-glucopyranoside , Theophylline , Theobromine ,
Applications: Analysis of polar compounds
Column: ULTRON AF-HILIC-DA
Column Size: 100 mm L × 4.6 mm I.D.
Mobile phase: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90
Frow rate: 0.50 mL/min
Column temp.: 30°C
Injection volume: 4.0 µL
Diluent: mobile phase

View detail

LC
Samples: L-DOPA , Dopamine , Adrenaline , Noradrenaline
Applications: Analysis of catecholamines
Column: ULTRON AF-HILIC-DA
Column Size: 100 mm L × 4.6 mm I.D.
Mobile phase: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90
Frow rate: 0.50 mL/min
Column temp.: 30°C
Injection volume: 4.0 µL
Diluent: mobile phase

View detail

LC
Samples: 1-Methylpyrazole , Fomepizole , Pyrazole , 1H-1,2,3-Triazole , Pyrazoline , Imidazole ,
Applications: Analysis of heterocyclic compounds
Column: ULTRON AF-HILIC-DA
Column Size: 100 mm L × 4.6 mm I.D.
Mobile phase: 20mM HCO2NH4 (pH3.2) /CH3CN = 10/90
Frow rate: 0.50 mL/min
Column temp.: 30°C
Injection volume: 4.0 µL
Diluent: mobile phase

View detail

LC
Samples: Glucose , Maltose , Maltotriose , Maltotetraose , Maltopentaose , Maltohexaose , Maltoheptaose ,
Applications: Analysis of maltooligosaccharides
Column: ULTRON AF-HILIC-CD
Column Size: 100 mm L × 2.0 mm I.D.
Mobile phase: A: H2O /CH3CN = 10/90, B: H2O /CH3CN = 70/30
Frow rate: 0.26 mL/min: 69% A /31% B (71.4% CH3CN)
Column temp.: 40°C
Injection volume: 1.0 µL
Diluent: H2O

View detail

LC
Samples: Xylose , Fructose , Glucose , Mannitol , Xylobiose , Sucrose , Lactulose , Lactose , Trehalose , Xylotriose , 1-Kestose(GF2) , Raffinose , Nystose(GF3) ,
Applications: Analysis of monosaccharides, disaccharides, and oligosaccharides
Column: ULTRON AF-HILIC-CD
Column Size: 100 mm L × 2.0 mm I.D.
Mobile phase: A: H2O /CH3CN = 10/90, B: H2O /CH3CN = 70/30
Frow rate: 0.26 mL/min
Column temp.: 40°C
Injection volume: 1.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Xylose , Fructose , Glucose , Mannitol , Xylobiose , Sucrose , Lactulose , Lactose , Trehalose , Xylotriose , 1-Kestose(GF2) , Raffinose , Nystose(GF3) ,
Applications: Analysis of monosaccharides, disaccharides, and oligosaccharides
Column: ULTRON AF-HILIC-CD
Column Size: 100 mm L × 2.0 mm I.D.
Mobile phase: A: 20mM CH3CO2NH4 (pH6.8) /CH3CN = 10/90, B: 20mM CH3CO2NH4 (pH6.8) /CH3CN = 70/30
Frow rate: 0.26 mL/min
Column temp.: 40°C
Injection volume: 2.5 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Erythritol , Xylitol , Fructose , Glucose , Sorbitol , Sucrose , Inositol , Maltose , Maltitol , Lactose , Lactitol
Applications: Analysis of saccharides and sweeteners
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: A: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 10/90, B: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 70/30
Frow rate: 0.32 mL/min
Column temp.: 40°C
Injection volume: 1.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Erythritol , Psicose , Tagatose , Allose , Glucose , Sucrose
Applications: Analysis of rare sugar, Glucose, and Sucrose
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 10/90
Frow rate: 0.36 mL/min
Column temp.: 40°C
Injection volume: 1.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Theophylline , 1-Methylxanthine , 1,3-Dimethyluric acid
Applications: Analysis of Theophyline and metabolites
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10mM CH3CO2NH4 (pH6.8) /CH3CN = 13/87
Frow rate: 0.15 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL
Diluent: Dissolved samples in 0.1% NaOH aq and add acetonitrile into ratio to 90%

View detail

LC
Samples: Maleic acid , Pyruvic acid , Ascorbic acid , Gluconic acid , Adipic acid , Fumaric acid , Tartaric acid , Malic acid , Citric acid
Applications: Analysis of organic acid
Column: ULTRON AF-HILIC-CD (PLSS)
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 25/75
Frow rate: 0.20 mL/min
Column temp.: 40°C
Injection volume: 2.0 µL
Diluent: mobile phase

View detail

LC
Samples: Acesulfame K , Saccharin , Caffeine , Sorbic acid , Benzoic acid , Quinine , Aspartame
Applications: Analysis of food additives
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 3.0 mm I.D.
Mobile phase: A: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90, B: 20mM CH3CO2NH4 (pH4.7) /CH3CN = 70/30
Frow rate: Refer to the picture
Column temp.: 30°C
Injection volume: 2.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Allantoin , Xanthine , Hypoxanthine , Uric acid
Applications: Analysis of Uric acid metabolite
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10mM CH3CO2NH4 (pH4.7) /CH3CN = 10/90
Frow rate: 0.35 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL
Diluent: Dissolved samples in 0.1% NaOH aq and add acetonitrile into ratio to 50%

View detail

LC
Samples: Turanose , Palatinose , Maltulose , Maltose , Lactose , Trehalose
Applications: Analysis of disaccharides with different glycosidic linkages
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 10/90
Frow rate: 0.45 mL/min
Column temp.: 40°C
Injection volume: 1.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Val-Tyr-Val , Leucine Enkephalin , Methionine Enkephalin , Gly-Tyr
Applications: Analysis of peptide standards
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: A: 10mM HCO2NH4 (pH3.0) /CH3CN = 10/90, B: 10mM HCO2NH4 (pH3.0) /CH3CN = 70/30
Frow rate: 0.26 mL/min: 67% A/ 33% B (70.0% CH3CN)
Column temp.: 40°C
Injection volume: 2.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Cyanuric acid , Ammelide , Melamine , Ammeline
Applications: Analysis of melamine compounds
Column: ULTRON AF-HILIC-CD
Column Size: 100 mm L × 2.0 mm I.D.
Mobile phase: 20mM HCO2NH4 (pH6.8) /CH3CN = 18/82
Frow rate: 0.15 mL/min
Column temp.: 30°C
Injection volume: 2.0 µL
Diluent: Dissolved samples in 0.1% NaOH aq and add acetonitrile into ratio to 50%

View detail

LC
Samples: Caffeine , Theophylline , Theobromine , 1-Methylxanthine , Xanthine
Applications: Analysis of Xanthines
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 10mM CH3CO2NH4 (pH6.8) /CH3CN = 13/87
Frow rate: 0.15 mL/min
Column temp.: 30°C
Injection volume: 1.0 µL
Diluent: Dissolved samples in 0.1% NaOH aq and add acetonitrile into ratio to 90%

View detail

LC
Samples: Cetirizine hydrochloride
Applications: Analyses of Cetirizine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Carvedilol
Applications: Analyses of Carvedilol in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Amlodipine
Applications: Analyses of Amlodipine in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Analyses of Atomoxetine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Candesartan cilexetil
Applications: Analyses of Candesartan cilexetil in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4/CH3CN = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analyses of Tolterodine in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analyses of Prilocaine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Analyses of Duloxetine hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analyses of Rabeprazole sodium salt in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analyses of Ibuprofen in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Formoterol fumarate
Applications: Analyses of Formoterol fumarate in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analyses of Tolperisone hydrochloride in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL (2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Tadalafil
Applications: Analyses of Tadalafil in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Cetirizine hydrochloride
Applications: Analyses of Cetirizine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 90/10
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Carvedilol
Applications: Analyses of Carvedilol in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 75/25
Frow rate: (1)1.0 mL/min (2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Amlodipine
Applications: Analyses of Amlodipine in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Analyses of Atomoxetine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Candesartan cilexetil
Applications: Analyses of Candesartan cilexetil in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4/CH3CN = 75/25
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analyses of Tolterodine in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analyses of Prilocaine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Analyses of Duloxetine hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analyses of Rabeprazole sodium salt in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analyses of Ibuprofen in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Formoterol fumarate
Applications: Analyses of Formoterol fumarate in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analyses of Tolperisone hydrochloride in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: ethanol

View detail

LC
Samples: Tadalafil
Applications: Analyses of Tadalafil in ULTRON ES-OVM series.(Greater analytical performance with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate: (1)1.0 mL/min　(2)0.28 mL/min
Column temp.: 25°C
Injection volume: (1)2.0 µL　(2)0.5 µL
Diluent: methanol

View detail

LC
Samples: Lenalidomide
Applications: Analysis of Lenalidomide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 95/5
Frow rate: 0.7 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Nitrendipine
Applications: Analysis of Nitrendipine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Sertraline hydrochloride
Applications: Analysis of Sertraline hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Tosufloxacin tosilate hydrate
Applications: Analysis of Tosufloxacin tosilate hydrate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Nefopam hydrochloride
Applications: Analysis of Nefopam hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analysis of Tolperisone hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Nisoldipine
Applications: Analysis of Nisoldipine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 88/12
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Rabeprazole
Applications: Analysis of Rabeprozole
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Rotigotine
Applications: Analysis of Rotigotine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL
Diluent: methanol

View detail

LC
Samples: Cinacalcet hydrochloride
Applications: Analysis of Cinacalcet hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 93/7
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Atorvastatin calcium
Applications: Analysis of Atorvastatine calcium
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM K2HPO4 + H3PO4 (pH 7.5)/CH3OH = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Cisapride
Applications: Analysis of Cisapride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/C2H5OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Sitagliptin
Applications: Analysis of Sitagliptin
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20mM K2HPO4 (pH 6.8)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 10.0 µL
Diluent: water

View detail

LC
Samples: Lafutidine
Applications: Analysis of Laftidine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL
Diluent: methanol

View detail

LC
Samples: Montelukast sodium
Applications: Analysis of Montelukast sodium
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3OH = 60/40
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Escitalopram oxalate
Applications: Analyses of Escitalopram oxalate in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 50 mM KH2PO4 + 0.2 N NaOH(pH 7.0)/CH3CN = 85/15
Frow rate: 0.6 mL/min
Column temp.: 30°C
Injection volume: (1)15.0 µL (2)0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rebamipide
Applications: Analysis of Rebamipide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 87/13
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 1.0 µL
Diluent: methanol

View detail

LC
Samples: Efavirentz
Applications: Analysis of Efavirentz
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Sulfinpyrazone
Applications: Analysis of Sulfinpyrazone
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM CH3COONH4 (pH 6.8)/CH3CH(OH)CH3 = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Trihexyphenidyl hydrochloride
Applications: Analysis of Trihexyphenidyl hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: mobile phase

View detail

LC
Samples: Sulconazole nitrate
Applications: Analysis of Sulconazole nitrate
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3OH = 86/14
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Tamsulosin
Applications: Analysis of Tamsulosin
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/C2H5OH = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: 2-(4-Hydroxyphenoxy)propionic acid
Applications: Analysis of 2-(4-Hydroxyphenoxy)propionic acid
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: 3,3-Dimethyl-4-phenyl-2-azetidinone
Applications: Analysis of 3,3-Dimethyl-4-phenyl-2-azetidinone
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Pronethalol hydrochloride
Applications: Analysis of Pronethalol hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: Thalidomide
Applications: Analysis of Thalidomide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 0.7 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: 2-Phenoxypropionic acid
Applications: Analysis of 2-Phenoxypropionic acid
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/C2H5OH = 90/10
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: Benfluorex
Applications: Analysis of Benfluorex
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 88/12
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: water

View detail

LC
Samples: Glycopyrronium bromide
Applications: Analysis of Glycopyrronium bromide
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL

View detail

LC
Samples: Ropivacaine
Applications: Analysis of Ropivacaine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 5.0 µL

View detail

LC
Samples: Clopidogrel Related Compound A , Clopidogrel Related Compound B , Clopidogrel Related Compound C , Clopidogrel bisulfate
Applications: Analyses of Clopidogrel Related Compounds in ULTRON ES-OVM series.(Faster analyses with 3µm particles)
Column: ULTRON ES-OVM
Column Size: (1)150 mm L × 4.6 mm I.D.　(2)100 mm L × 3.0 mm I.D.
Mobile phase: 10 mM KH2PO4/CH3CN = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: (1)10.0 µL (2)3.0 µL

View detail

LC
Samples: Voriconazole , Voriconazole Related Compound B
Applications: Analysis of Voriconazole
Column: ULTRON ES-CD-2
Column Size: 250 mm L × 4.6 mm I.D.
Mobile phase: 10 mM CH3CO2NH4 (pH 5.0)/CH3CN = 82/18
Frow rate: 1.0 mL/min
Column temp.: 30°C
Injection volume: 20.0 µL
Diluent: mobile phase

View detail

LC
Samples: Sertraline hydrochloride , Sertraline Hydrochloride Related Compound A
Applications: Analysis of Sertraline hydrochloride
Column: ULTRON ES-CD
Column Size: 250 mm L × 4.6 mm I.D.
Mobile phase: 50.4mM NH4H2PO4 (pH 4.2)/CH3OH = 52/48
Frow rate: 1.0 mL/min
Column temp.: 30°C
Injection volume: 20.0 µL
Diluent: mobile phase

View detail

LC
Samples: Lamivudine
Applications: Analysis of Lamivudine
Column: ULTRON ES-CD-2
Column Size: 250 mm L × 4.6 mm I.D.
Mobile phase: 100mM CH3COONH4/CH3OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 10.0 µL
Diluent: water

View detail

LC
Samples: Glycopyrrolate , Glycopyrrolate erythro isomer
Applications: Analysis of Glycopyrrolate
Column: ULTRON ES-CD
Column Size: 250 mm L × 4.6 mm I.D.
Mobile phase: 23.3 mM NaH2PO4(pH 6.5)/CH3OH/CH3CN = 40/50/10
Frow rate: 1.0 mL/min
Column temp.: 30°C
Injection volume: 10.0 µL
Diluent: mobile phase

View detail

LC
Samples: Fexofenadine Related Compound B , Fexofenadine hydrochloride
Applications: Analysis of Fexofenadine
Column: ULTRON ES-CD-F
Column Size: 250 mm L × 4.6 mm I.D.
Mobile phase: Glacial acetic acid and water(2.3:2000)/CH3CN = 80/20
Frow rate: 0.5 mL/min
Column temp.: 25°C
Injection volume: 20.0 µL
Diluent: mobile phase

View detail

LC
Samples: Epinephrine
Applications: Analysis of Epinephrine
Column: ULTRON ES-CD-EP
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10mM CH3CO2NH4(pH 4.0)/CH3CN = 99/1
Frow rate: 0.3 mL/min
Column temp.: 25°C
Injection volume: 10.0 µL
Diluent: 10mM CH3CO2NH4(pH 4.0)

View detail

LC
Samples: Methotrexate
Applications: Analysis of Methotrexate
Column: ULTRON ES-BSA-2
Column Size: 150 mm L × 4.0 mm I.D.
Mobile phase: 50mM sodium phosphate buffer (pH6.9)/1-Propanol = 92/8
Frow rate: 1.5 mL/min
Column temp.: 25°C
Injection volume: 20.0 µL
Diluent: mobile phase

View detail

LC
Samples: Sulindac
Applications: Analysis of Sulindac
Column: ULTRON ES-BSA-2
Column Size: 150 mm L × 4.0 mm I.D.
Mobile phase: 50mM sodium phosphate buffer (pH6.9)/1-Propanol = 92/8
Frow rate: 0.75 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL

View detail

LC
Samples: Ketoprofen
Applications: Analysis of Ketoprofen
Column: ULTRON ES-BSA-2
Column Size: 150 mm L × 4.0 mm I.D.
Mobile phase: 20mM sodium phosphate buffer (pH6.9)/1-Propanol/caprylic acid = 98/2/0.005
Frow rate: 0.75 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: 1-Propanol

View detail

LC
Samples: Mandelic acid
Applications: Analysis of Mandelic acid
Column: ULTRON ES-BSA-2
Column Size: 150 mm L × 4.0 mm I.D.
Mobile phase: 20mM sodium phosphate buffer (pH6.9)
Frow rate: 0.75 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: mobile phase

View detail

LC
Samples: Clopidogrel Related Compound A , Clopidogrel Related Compound B , Clopidogrel Related Compound C , Clopidogrel bisulfate
Applications: Analysis of Clopidogrel Related Compounds
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM KH2PO4/CH3CN = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 10.0 µL

View detail

LC
Samples: Clopidogrel Related Compound A , Clopidogrel Related Compound B , Clopidogrel Related Compound C , Clopidogrel bisulfate
Applications: Analysis of Clopidogrel Related Compounds
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 10 mM KH2PO4/CH3CN = 75/25
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 3.0 µL

View detail

LC
Samples: Escitalopram oxalate
Applications: Analysis of Escitalopram oxalate
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 50 mM KH2PO4 + 0.2 N NaOH(pH 7.0)/CH3CN = 85/15
Frow rate: 0.6 mL/min
Column temp.: 30°C
Injection volume: 0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Cetirizine hydrochloride
Applications: Analysis of Cetirizine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 90/10
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Tolterodine
Applications: Analysis of Tolterodine
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analysis of Tolterodine
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analysis of Prilocaine hydrochloride
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analysis of Prilocaine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analysis of Rabeprazole sodium salt
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analysis of Ibuprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: ethanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analysis of Tolperisone hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Tadalafil
Applications: Analysis of tadalafil
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2.0 µL
Diluent: methanol

View detail

LC
Samples: Tadalafil
Applications: Analysis of Tadalafil
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Carvedilol
Applications: Analysis of Carvedilol
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 7.0)/CH3CN = 75/25
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Amlodipine
Applications: Analysis of Amlodipine
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 90/10
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Atomoxetine hydrochloride
Applications: Analysis of Atomoxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Candesartan cilexetil
Applications: Analysis of Candesartan cilexetil
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4/CH3CN = 75/25
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolterodine
Applications: Analysis of Tolterodine
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 92/8
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Prilocaine hydrochloride
Applications: Analysis of Prilocaine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3CN = 95/5
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Duloxetine hydrochloride
Applications: Analysis of Duloxetine hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3CN = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: mobile phase

View detail

LC
Samples: Rabeprazole sodium salt
Applications: Analysis of Rabeprazole sodium salt
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 6.0)/CH3OH = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Ibuprofen
Applications: Analysis of Ibuprofen
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 (pH 4.6)/CH3OH = 80/20
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Formoterol fumarate
Applications: Analysis of Formoterol fumarate
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM K2HPO4 + 20 mM KH2PO4 (pH 7.0)/C2H5OH = 94/6
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Tolperisone hydrochloride
Applications: Analysis of Tolperisone hydrochloride
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + 20 mM K2HPO4 (pH 5.5)/C2H5OH = 95/5
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: ethanol

View detail

LC
Samples: Tadalafil
Applications: Analysis of Tadalafil
Column: ULTRON ES-OVM
Column Size: 100 mm L × 3.0 mm I.D.
Mobile phase: 20 mM KH2PO4 + H3PO4 (pH 3.0)/CH3CN = 85/15
Frow rate: 0.28 mL/min
Column temp.: 25°C
Injection volume: 0.5 µL
Diluent: methanol

View detail

LC
Samples: Sucralose , Fructose , Glucose , Sucrose , Lactose
Applications: Analysis of artificial sweetener and sugars
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 15/85
Frow rate: 1.0 mL/min
Column temp.: 40°C
Injection volume: 10.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Sucralose , Fructose , Glucose , Sucrose , Lactose
Applications: Analysis of artificial sweetener and sugars
Column: ULTRON PS-80N
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 80°C
Injection volume: 10.0 µL

View detail

LC
Samples: Sucralose , Fructose , Glucose , Sucrose , Lactose
Applications: Analysis of artificial sweetener and sugars
Column: ULTRON PS-80C
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 80°C
Injection volume: 10.0 µL

View detail

LC
Samples: Sucralose , Fructose , Glucose , Sucrose , Lactose
Applications: Analysis of artificial sweetener and sugars
Column: ULTRON PS-80P
Column Size: 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 1.0 mL/min
Column temp.: 80°C
Injection volume: 10.0 µL

View detail

LC
Samples: Acesulfame K , Saccharin , Sucralose , Advantame , Neotame , Aspartame
Applications: Analysis of artificial sweetener
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 10/90
Frow rate: 1.4 mL/min
Column temp.: 30°C
Injection volume: 4.0 µL
Diluent: H2O /CH3CN = 50/50

View detail

LC
Samples: Dehydroascorbic acid , Ascorbic acid
Applications: Analyses of Ascorbic acid
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 100mM CH3CO2NH4 (pH6.8) /CH3CN = 30/70
Frow rate: 0.2 mL/min
Column temp.: 30°C
Injection volume: 10.0 µL
Diluent: H2O /CH3CN = 10/90

View detail

LC
Samples: Amlodipine
Applications: Analysis of Amlodipine for LCMS
Column: ULTRON ES-OVM
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: 20 mM CH3CO2NH4/CH3CN = 80/20
Frow rate: 0.2 mL/min
Column temp.: 25°C
Injection volume: 0.4 µL
Diluent: H2O /CH3CN = 50/50 (v/v)

View detail

LC
Samples: Oligo deoxythymidine primers , Oligo dT primers
Applications: Analyses of Oligo deoxythymidine primers
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 2.0 mm I.D.
Mobile phase: A: CH3CN　B: 100 mM CH3CO2NH4 (pH 6.7)
Frow rate: 0.15 mL/min
Column temp.: 30°C
Injection volume: 5.0 µL
Diluent: CH3CN/TE buffer* = 70/30

View detail

LC
Samples: Ethanol , Acetic Acid , 1,4-Sorbitan , Fructose , Glucose , Sorbitol , Sucrose , Maltitol , Maltotriose
Applications: Analysis of ethanol, acetic acid, and sugars
Column: ULTRON AF-HILIC-CD
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 10 mM HCO2NH4 (pH 4.0)/CH3CN = 17/83
Frow rate: 0.5 mL/min
Column temp.: 40°C
Injection volume: 10 µL
Diluent: mobile phase

View detail

LC
Samples: Dexketoprofen
Applications: Analysis of Dexketoprofen
Column: ULTRON ES-OVM
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: 20 mM CH3CO2NH4 (pH 3.0)/CH3CN = 95/5
Frow rate: 1.0 mL/min
Column temp.: 25°C
Injection volume: 2 µL
Diluent: 10% acetonitrile

View detail

LC
Samples: Glucose , Galactose , Arabinose , Mannose
Applications: Analysis of Glucose, Galactose, Arabinose and Mannose
Column: ULTRON PS-80P
Column Size: 300 mm L × 8.0 mm I.D. + 300 mm L × 8.0 mm I.D.
Mobile phase: H2O
Frow rate: 0.5 mL/min
Column temp.: 80°C
Injection volume: 10 µL
Diluent: water

View detail

LC
Samples: Linolenic acid , Myristic acid , Palmitoleic acid , Arachidonic acid , Linoleic acid , Palmitic acid , Oleic acid
Applications: Analysis of Long-chain fatty acid
Column: STR ODS-Ⅱ
Column Size: 150 mm L × 4.6 mm I.D.
Mobile phase: CH3CN/0.1% H3PO4 aq = 80/20
Frow rate: 1.0 mL/min
Column temp.: 40°C
Injection volume: 5 µL
Diluent: ethyl acetate

View detail

LC/GC Search / Application Note

Shinwa Chemical Industries
Application Search

Keyword index

Search result
"2" Filtered 580 Item.

Shinwa Chemical Industries Application Search

Keyword index

Search result "2" Filtered 580 Item.

Shinwa Chemical Industries
Application Search

Search result
"2" Filtered 580 Item.
